▀ Structure-Agnostic TDM over Packet (SAToP)
ASR903-R3# show controllers sonet 0/4/0
SONET 0/4/0 is up.
Hardware is A900-IMA4OS
Applique type is Channelized Sonet/SDH
Clock Source is Line, AUG mapping is AU4.
Medium info:
Type: SDH, Line Coding: NRZ,
Regenerator Section:
LOS = 1
SONET/SDH Section Tables
INTERVAL
22:48-22:57
22:33-22:48
Total of Data in Current and Previous Intervals
22:33-22:57
Multiplex Section:
AIS = 1
Active Defects: None
Detected Alarms: None
Asserted/Active Alarms: None
Alarm reporting enabled for: SLOS SLOF SF B1-TCA B2-TCA
BER thresholds:
TCA thresholds:
Rx: S1S0 = 00
K1 = 00,
J0 = 01
RX S1 = 00
Tx: S1S0 = 02
K1 = 00,
J0 = 01
SONET/SDH Line Tables
INTERVAL
22:48-22:57
22:33-22:48
Total of Data in Current and Previous Intervals
22:33-22:57
High Order Path:
PATH 1:
AIS = 1
LOP = 0
LOM = 0
Active Defects: None
Detected Alarms: None
Asserted/Active Alarms: None
▄ Cisco ASR 903 Router Design and Deployment Guide
86
LOF = 1
CV ES SES SEFS
0 0 0
0 0 0
0 0 0
RDI = 0
SF = 10e-3 SD = 10e-6
B1 = 10e-6 B2 = 10e-6
K2 = 00
K2 = 00
CV ES SES UAS
0 0 0
0 0 0
0 0 0
RDI = 0
PSE = 0
PLM = 1
BIP(B1) = 0
0
0
0
REI = 0 BIP(B2) = 0
0
0
0
REI = 0 BIP(B3) = 0
NSE = 0 NEWPTR = 0
UNEQ = 0
