Cisco ASR 903 Router Hardware
Installation Guide
June 2013
Cisco Systems, Inc.
www.cisco.com
Cisco has more than 200 offices worldwide.
Addresses, phone numbers, and fax numbers
are listed on the Cisco website at
www.cisco.com/go/offices.
Text Part Number: OL-25178-04

Advertisement

Table of Contents
loading

Related Manuals for Cisco ASR 903

Summary of Contents for Cisco ASR 903

  • Page 1 Cisco ASR 903 Router Hardware Installation Guide June 2013 Cisco Systems, Inc. www.cisco.com Cisco has more than 200 offices worldwide. Addresses, phone numbers, and fax numbers are listed on the Cisco website at www.cisco.com/go/offices. Text Part Number: OL-25178-04...
  • Page 2 OR ITS SUPPLIERS HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. Cisco and the Cisco logo are trademarks or registered trademarks of Cisco and/or its affiliates in the U.S. and other countries. To view a list of Cisco trademarks, go to this URL: www.cisco.com/go/trademarks.

  • Page 3: Table Of Contents

    Gigabit Ethernet RJ45 Interface Module 1-10 10 Gigabit Ethernet XFP Interface Module 1-11 T1/E1 Interface Module 1-13 OC-3 Interface Module 1-14 Temperature Sensor 1-15 Serial Number Label Location 1-15 Interface Numbering 1-15 Regulatory Compliance 1-16 Cisco ASR 903 Router Hardware Installation Guide OL-25178-04...
  • Page 4 Installing the Cisco ASR 903 Router C H A P T E R Prerequisites Installing the Router in a Rack Installing the Chassis Brackets Installing the Router Chassis in the Rack Attaching the Cable Management Brackets Cisco ASR 903 Router Hardware Installation Guide OL-25178-04...
  • Page 5 Installing the AC Power Supply Module 3-25 Activating the AC Power Supply 3-26 Removing and Replacing the AC Power Supply 3-26 Connecting the Cisco ASR 903 Router to the Network 3-27 Connecting Console Cables 3-27 Connecting to the Serial Port using Microsoft Windows 3-28...
  • Page 6 Powering Up the Cisco ASR 903 Router Verifying the Front Panel LEDs Verifying the Hardware Configuration Checking Hardware and Software Compatibility Configuring the Cisco ASR 903 Router at Startup Using the Console Interface Configuring Global Parameters Checking the Running Configuration Settings...
  • Page 7 OC-3 Interface Module LEDs T1/E1 Interface Module LEDs Power Supply LEDs 5-10 Fan Tray LEDs 5-10 Alarm Conditions 5-11 Site Log C H A P T E R N D E X Cisco ASR 903 Router Hardware Installation Guide OL-25178-04...
  • Page 8 Contents Cisco ASR 903 Router Hardware Installation Guide viii OL-25178-04...

  • Page 9: About This Book

    First release published. Document Audience This guide is intended for users who are responsible for installing the Cisco ASR 903 Series Aggregation Services Router. It is intended for users who may not be familiar with the initial configuration and troubleshooting tasks, the relationship among tasks, or the Cisco IOS software commands necessary to perform particular tasks.

  • Page 10: Document Organization

    This chapter provides site preparation guidelines Installation” for installing the Cisco ASR 903 Router. Chapter 3, “Installing the Cisco ASR This chapter describes the Cisco ASR 903 Router 903 Router” and how to install it. Chapter 4, “Cisco ASR 903 Router This chapter describes how to start the Initial Configuration”...

  • Page 11: Obtaining Documentation And Submitting A Service Request

    Cisco technical documentation, at: http://www.cisco.com/en/US/docs/general/whatsnew/whatsnew.html Subscribe to the What’s New in Cisco Product Documentation as an RSS feed and set content to be delivered directly to your desktop using a reader application. The RSS feeds are a free service. Cisco currently supports RSS Version 2.0.
  • Page 12 Chapter Cisco ASR 903 Router Hardware Installation Guide -xii OL-25178-04...

  • Page 13: Cisco Asr 903 Router Features

    The Cisco ASR 903 Router expands the Cisco service provider product portfolio by providing a rich and scalable feature set of Layer 2 VPN (L2VPN) and Layer 3 VPN (L3VPN) services in a compact package.

  • Page 14: Chapter 1 Cisco Asr 903 Router Overview

    Temperature range of -40 to 149 degrees F (-40 to 65 degrees C) with DC power supply • Temperature range of -32 to 104 degrees F (0 to 40 degrees C) with AC power supply • Figure 1-1 illustrates the Cisco ASR 903 Router chassis design. Figure 1-1 Cisco ASR 903 Router Chassis Design GE-0 GE-1...

  • Page 15: Power Supply Features

    < 55 dBa @ 27 degrees C Power Supply Features The Cisco ASR 903 Router support AC and DC power supplies. For more information about installing the Cisco ASR 903 Router power supplies, see the Installing the Power Supply, page 3-17 section.

  • Page 16: Redundancy

    Cisco ASR 903 Router supports current sharing between the power supplies. If you install a redundant power supply on the Cisco ASR 903 Router, we recommend that you connect each power supply to a separate input power source in order to ensure that the router maintains power in the event of a power interruption caused by an electrical failure, a wiring fault, or a tripped circuit breaker.

  • Page 17: Ac Power Specifications

    600 W Fan Tray The Cisco ASR 903 Router uses a modular fan tray that is separate from the power supply. The fan tray contains twelve fans and provides sufficient capacity to maintain operation indefinitely in the event of an individual fan failure.

  • Page 18: Rsp Modules

    5-7. RSP Modules The Cisco ASR 903 Router is designed to use up to two RSP modules to handle the data plane, network timing, and control plane functionalities for the router. The RSP configuration allows you to use Cisco IOS software to control chassis management, redundancy, external management, and system status indications on the router.

  • Page 19: Supported Rsps

    • RSP Redundancy The Cisco ASR 903 Router chassis includes two RSP slots to allow for redundant RSPs. When the router uses redundant RSPs, one RSP operates in the active mode and the other operates in the hot standby mode. Removal or failure of the active RSP results in an automatic switchover to the standby RSP.

  • Page 20: Network Timing Interfaces

    Time of Day (ToD) timing port BITS timing port Ethernet management port For more information about installing the RSP, see RSP Installation, page 3-10. For more information about the RSP LEDs, see RSP LEDs, page 5-7. Cisco ASR 903 Router Hardware Installation Guide OL-25178-04...

  • Page 21: Interface Modules

    Chapter 1 Cisco ASR 903 Router Overview Cisco ASR 903 Router Features Interface Modules In addition to the ports provided on an RSP, the Cisco ASR 903 Router supports the following interface modules: • Gigabit Ethernet SFP Interface Module, page 1-9 •...

  • Page 22: Gigabit Ethernet Rj45 Interface Module

    Figure 1-5 8 x 1 GE Gigabit Ethernet RJ45 (Copper) Interface Module For more information about installing an RJ45 Gigabit Ethernet module, see the “Interface Module Installation” section on page 3-14. Cisco ASR 903 Router Hardware Installation Guide 1-10 OL-25178-04...

  • Page 23: Gigabit Ethernet Xfp Interface Module

    • DWDM-XFP-31.90 • DWDM-XFP-32.68 • DWDM-XFP-34.25 • DWDM-XFP-35.04 • DWDM-XFP-35.82 • • DWDM-XFP-36.61 • DWDM-XFP-38.19 • DWDM-XFP-38.98v • DWDM-XFP-39.77 • DWDM-XFP-40.56 • DWDM-XFP-42.14 DWDM-XFP-42.94 • DWDM-XFP-43.73 • DWDM-XFP-44.53 • DWDM-XFP-46.12 • Cisco ASR 903 Router Hardware Installation Guide 1-11 OL-25178-04...
  • Page 24 XFP-10GER-OC192IR-RGD • XFP10GLR-192SR-L • XFP-10GLR-OC192SR • XFP-10GLR-OC192SR-RGD • XFP-10G-MM-SR • XFP-10GZR-OC192LR • XFP-10GZR-OC192LR-RGD For more information about installing a 10GE XFP module, see the “Interface Module Installation” section on page 3-14. Cisco ASR 903 Router Hardware Installation Guide 1-12 OL-25178-04...

  • Page 25: T1/E1 Interface Module

    Figure 1-7 shows the interface module. Figure 1-7 16 x T1/E1 Interface Module For more information about installing a T1/E1 interface module, see the “Interface Module Installation” section on page 3-14. Cisco ASR 903 Router Hardware Installation Guide 1-13 OL-25178-04...

  • Page 26: Oc-3 Interface Module

    The optical interface module supports the following optical transceivers: ONS-SC-155-EL • • ONS-SI-155-I1 • ONS-SI-155-L1 • ONS-SI-155-L2 • ONS-SI-155-SR-MM For more information about installing an optical interface module, see the “Interface Module Installation” section on page 3-14. Cisco ASR 903 Router Hardware Installation Guide 1-14 OL-25178-04...

  • Page 27: Temperature Sensor

    Two RSP module slots • Two power supply slots • One fan tray slot • Each network interface on a Cisco ASR 903 Router is identified by a slot number and a port number. Cisco ASR 903 Router Hardware Installation Guide 1-15 OL-25178-04...

  • Page 28: Regulatory Compliance

    Chapter 1 Cisco ASR 903 Router Overview Regulatory Compliance Figure 1-10 shows interface numbering in a Cisco ASR 903 Router. Figure 1-10 Cisco ASR 903 Router Slot Numbers GE-0 GE-1 GE-2 GE-3 GE-4 GE-5 GE-6 GE-7 RUDY RSP FAN TEMP...

  • Page 29: Safety Guidelines

    C H A P T E R Preparing for Installation The following sections describe how to prepare for the installation of the Cisco ASR 903 Router at your site: Safety Guidelines, page 2-1 • • Site Planning, page 2-9 •...

  • Page 30: Chapter 2 Preparing For Installation

    This is a class A product. In a domestic environment this product may cause radio interference in Warning which case the user may be required to take adequate measures. Statement 340 This equipment is in compliance with the essential requirements and other relevant provisions of Warning Directive 1999/5/EC. Cisco ASR 903 Router Hardware Installation Guide OL-25178-04...

  • Page 31: Safety Guidelines For Personal Safety And Equipment Protection

    Statement 1029 Hazardous voltage or energy is present on the backplane when the system is operating. Use caution Warning when servicing. Statement 1034 Cisco ASR 903 Router Hardware Installation Guide OL-25178-04...

  • Page 32: Safety With Electricity

    This unit is intended for installation in restricted access areas. A restricted access area can be Warning accessed only through the use of a special tool, lock and key, or other means of security. Statement 1017 Cisco ASR 903 Router Hardware Installation Guide OL-25178-04...
  • Page 33 Statement 1032 Warning Connect the unit only to DC power source that complies with the safety extra-low voltage (SELV) requirements in IEC 60950 based safety standards. Statement 1033 Cisco ASR 903 Router Hardware Installation Guide OL-25178-04...
  • Page 34 Be sure that power is removed or the area is nonhazardous before proceeding. To verify switch operation, perform POST on the switch in a nonhazardous location before installation. Statement 1065 Warning Installation of the equipment must comply with local and national electrical codes. Statement 1074 Cisco ASR 903 Router Hardware Installation Guide OL-25178-04...
  • Page 35 Never install telephone jacks in wet locations unless the jack is specifically designed for it. • Never touch uninsulated telephone wires or terminals unless the telephone line is disconnected at • the network interface. When installing or modifying telephone lines, use caution. • Cisco ASR 903 Router Hardware Installation Guide OL-25178-04...

  • Page 36: Power Supply Considerations

    Never attempt to remove the printed circuit board from the metal carrier. For the safety of your equipment, periodically check the resistance value of the antistatic wrist strap. It Note should be between 1 and 10 Mohm. Cisco ASR 903 Router Hardware Installation Guide OL-25178-04...

  • Page 37: Site Planning

    The site’s air conditioning system can compensate for the heat dissipation of the • Cisco ASR 903 Router. The floor space that the Cisco ASR 903 Router occupies can support the weight of the system. • Electrical service to the site complies with the requirements.

  • Page 38: Site Selection Guidelines

    “System Specifications” section on page Physical Characteristics Be familiar with the physical characteristics of the Cisco ASR 903 Router to assist you in placing the system in the proper location. For more information, see the “System Specifications” section on page...

  • Page 39: Air Flow Guidelines

    Site Planning Air Flow Guidelines Cool air is circulated through the Cisco ASR 903 Router by a fan tray located along the right side of the router. Air flow is side-to-side, right to left, as shown in “Cisco ASR 903 Router Chassis Air Flow”.

  • Page 40: Air Flow Guidelines For Enclosed Rack Installation

    Air Flow Guidelines for Enclosed Rack Installation To install a Cisco ASR 903 Router in a 4-post enclosed cabinet, the front and rear doors of the cabinet must be removed or be perforated with a minimum of 65% open area (70% for ETSI 800mm racks).

  • Page 41: Electrical Circuit Requirements

    The Cisco ASR 903 Routers can be powered by a DC source or an AC source. Ensure that equipment grounding is present and observe the power strip ratings. Make sure that the total ampere rating of all products plugged into the power strip does not exceed 80% of the rating.

  • Page 42: Asynchronous Terminal Connections

    Strong EMI can destroy the signal drivers and receivers in the Cisco ASR 903 Router and even create an electrical hazard by causing power surges through the power lines into installed equipment. These problems are rare but could be catastrophic.

  • Page 43: Rack-Mounting Guidelines

    Do not step on or stand on any component or system when servicing other systems or components • in a rack. When mounting the Cisco ASR 903 Router in a partially filled rack, load the rack from the bottom • to the top, with the heaviest component at the bottom of the rack.

  • Page 44: Equipment Rack Guidelines

    Locating for Safety If the Cisco ASR 903 Router is the heaviest or the only piece of equipment in the rack, consider installing it at or near the bottom to ensure that the rack’s center of gravity is as low as possible.
  • Page 45 Locating for Proper Airflow Ensure that the Cisco ASR 903 Router location has enough airflow to keep the system operating within the environmental characteristics and the air temperature is sufficient to compensate for the heat dissipated by the system.

  • Page 46: Installation Checklist

    Site Planning Installation Checklist To assist you with your installation and to provide a record of what was done by whom and when, photocopy the Cisco ASR 903 Router Installation Checklist shown in Table 2-1. Use this to record the completion and verification of each procedure.

  • Page 47: Creating A Site Log

    Site Log as well as a sample Site Log that can be used to make copies.) Receiving the Cisco ASR 903 Router Each Cisco ASR 903 Router chassis is shipped in a container that is strapped to a pallet, as illustrated in Figure 2-2.

  • Page 48: Chassis-Lifting Guidelines

    To remove the cover if you are upgrading the memory or other components – • #12-24 pan-head screws to secure the router to the equipment rack • Cables for connecting to the WAN and LAN ports (depending on the configuration) Cisco ASR 903 Router Hardware Installation Guide 2-20 OL-25178-04...

  • Page 49: Unpacking And Verifying The Shipped Contents

    Table 2-2 to check the contents of the Cisco ASR 903 Router shipping container. Do not discard the shipping container. You will need the container if you move or ship the Cisco ASR 903 Router in the future. Table 2-2...
  • Page 50 Cisco ASR 903 Router includes the Regulatory Compliance and Safety Information for the Cisco ASR 903 Router document, and the Cisco ASR 903 Router Documentation Roadmap that contains information about the various documents that are available online and the links to them.

  • Page 51: Prerequisites

    • • Gathering the tools and test equipment required to properly install the Cisco ASR 903 Router For more instructions on how to prepare for the installation of the Cisco ASR 903 Router, see Chapter 2, “Preparing for Installation.” Installing the Router in a Rack The following sections describe how to install the Cisco ASR 903 Router in a rack: •...

  • Page 52: Chapter 3 Installing The Cisco Asr 903 Router

    Figure 3-1 Attaching Mounting Brackets for a 19-inch EIA Rack Figure 3-2 shows how to attach the brackets on the Cisco ASR 903 Router for a 300 mm ETSI cabinet. Figure 3-2 Attaching Mounting Brackets for a 300 mm ETSI Cabinet Step 2 Position one of the brackets against the chassis side, and align the screw holes.

  • Page 53: Installing The Router Chassis In The Rack

    Do not use interface module and power supply ejector handles to lift the chassis; using the handles to lift the chassis can deform or damage the handles. Figure 3-3 Installing the Chassis in a 19-inch EIA Rack Figure 3-4 Installing the Chassis to support the Japanese JIS Rack Standard Cisco ASR 903 Router Hardware Installation Guide OL-25178-04...

  • Page 54: Attaching The Cable Management Brackets

    Step 1 as shown in Figure 3-6. Figure 3-6 Cable Management Bracket Installation Step 2 Secure the cable management brackets with four M4 screws. The recommended maximum torque is 10 in.-lb (1.12 N-m). Cisco ASR 903 Router Hardware Installation Guide OL-25178-04...

  • Page 55: Installing The Chassis Ground Connection

    Installing the Chassis Ground Connection Installing the Chassis Ground Connection Before you connect the power or turn on the power to the Cisco ASR 903 Router, you must provide an adequate chassis ground (earth) connection to your router. This section describes how to ground the Cisco ASR 903 Router chassis. The router provides two locations for attaching a 2-hole grounding lug according to the rack-mounting brackets you use to install the router.
  • Page 56 This unit is to be installed in a restrictive access location and must be permanently grounded to minimum 6 AWG copper ground wire. Perform the following procedure to ground the Cisco ASR 903 Router using a 2-hole lug and the corresponding mounting point. Most carriers require a minimum 6 AWG ground connection. Verify your carrier’s requirements for the ground connection.
  • Page 57 2 pan-head Phillips head screws. For a 19-inch EIA rack, attach the 2-hole ground lug to the rear of the router. Step 5 Connect the other end of the ground wire to a suitable grounding point at your site. Cisco ASR 903 Router Hardware Installation Guide OL-25178-04...

  • Page 58: Installing The Fan Tray

    Installing the Cisco ASR 903 Router Installing the Fan Tray Installing the Fan Tray The fan tray is a modular unit that provides cooling to the Cisco ASR 903 Router. Follow these steps to install the fan tray in the chassis: Step 1 Orient the fan tray so that the captive screws are on the left side of the fan tray’s front panel.
  • Page 59 Caution tray has been removed or replaced. Follow these steps to remove and replace the fan tray on the Cisco ASR 903 Router: Using a No. 2 Phillips screwdriver or your fingers, loosen the captive installation screw that secures the Step 1 fan tray to the chassis.

  • Page 60: Rsp Installation

    To install the new fan tray, follow the steps in “Installing the Fan Tray” section on page 3-8. RSP Installation Follow these steps on handling an RSP module in the Cisco ASR 903 Router: Installing an RSP Module, page 3-11 • Removing an RSP Module, page 3-12 •...

  • Page 61: Installing An Rsp Module

    Tighten the two captive installation screws on the module. The recommended maximum torque is 5.5 in.-lb (.62 N-m). Note Make sure that the ejector levers are fully closed before tightening the captive installation screws. Cisco ASR 903 Router Hardware Installation Guide 3-11 OL-25178-04...

  • Page 62: Removing An Rsp Module

    Before you remove an RSP from the router, you should save the current configuration using the write {host file | network | terminal} command. This saves you time when bringing the module back online. If the module is running Cisco IOS software, save the current running configuration by entering the copy running-config startup-config command.

  • Page 63: Hot-Swapping An Rsp Module

    1029 Hot-Swapping an RSP Module The Cisco ASR 903 Router provides a feature that allows you to remove and replace a redundant RSP module without powering down the router. This feature, called hot-swapping or OIR, allows you to remove and replace a redundant module without disrupting router operation.

  • Page 64: Interface Module Installation

    Tighten the locking thumbscrews on both sides of the interface module. The recommended maximum torque is 5.5 in.-lb (.62 N-m). Step 5 Connect all the cables to each interface module. 10 Gigabit Ethernet interface modules are not supported in slots 4 and 5. Note Cisco ASR 903 Router Hardware Installation Guide 3-14 OL-25178-04...

  • Page 65: Removing An Interface Module

    Hot-Swapping an Interface Module The Cisco ASR 903 Router provides a feature that allows you to remove and replace an interface module without powering down the router. This feature, called hot-swapping or OIR, allows you to remove and replace a redundant module without disrupting router operation.
  • Page 66 This time is recommended in order to allow for synchronization between components within the interface module and for synchronization with the standby RSP. Cisco ASR 903 Router Hardware Installation Guide 3-16 OL-25178-04...

  • Page 67: Installing The Power Supply

    In some systems, you can use an UPS to protect against power failures at your site. Avoid UPS types • that use ferroresonant technology. These UPS types can become unstable with systems like the Cisco ASR 903 Router, which can have substantial current draw fluctuations due to bursty data traffic patterns. Cisco ASR 903 Router Hardware Installation Guide...

  • Page 68: Power Connection Guidelines

    “DC Power Specifications” section on page 1-4 to estimate the power requirements and heat dissipation of a Cisco ASR 903 Router based on a given configuration of the router. Determining power requirements is useful for planning the power distribution system needed to support the router.

  • Page 69: Installing The Dc Power Supply

    Installing the Cisco ASR 903 Router Installing the Power Supply Installing the DC Power Supply The following sections describe how to install a DC power supply in the Cisco ASR 903 Router: Installing the DC Power Supply Module, page 3-19 •...

  • Page 70: Installing The Terminal Block

    Identify the ground, positive, and negative feed positions for the terminal block connection. The recommended wiring sequence is: Ground lead wire (right) Negative (-) lead wire (left) Positive (+) lead wire (middle) Cisco ASR 903 Router Hardware Installation Guide 3-20 OL-25178-04...
  • Page 71 Make sure that you cannot see any wire lead. Only wire with insulation should extend from the terminal block. Caution Do not overtorque the plug captive screws of the terminal block. The recommended maximum torque is from 4.425 in.-lb (.5 N-m) to 5.310 in-lb (.6 N-m). Cisco ASR 903 Router Hardware Installation Guide 3-21 OL-25178-04...
  • Page 72 24 V — 60 V 28 A AL AR M DC power supply ground lead wire DC power supply positive (+) lead wire DC power supply negative (-) lead wire — — Cisco ASR 903 Router Hardware Installation Guide 3-22 OL-25178-04...

  • Page 73: Activating The Dc Power Supply

    This completes the procedure for connecting the DC power supply in the Cisco ASR 903 Router. If you are installing a redundant DC power supply, repeat these steps for the second power source.

  • Page 74: Removing And Replacing The Dc Power Supply

    Installation of the equipment must comply with local and national electrical codes. Statement 1074 Warning Follow these steps to remove and replace the DC power supply on the Cisco ASR 903 Router: Step 1 Before servicing the power supply, switch off the circuit breaker in your equipment area. As an additional precaution, tape the circuit-breaker switch in the Off position.

  • Page 75: Installing The Ac Power Supply

    (Cisco part number A900-PWR-BLANK) over the opening, and secure it with the captive installation screws. Installing the AC power Supply The following sections describe how to install a AC power supply in the Cisco ASR 903 Router: • Installing the AC Power Supply Module, page 3-25 •...

  • Page 76: Activating The Ac Power Supply

    Removing and Replacing the AC Power Supply This section describes how to remove and replace the AC power supply. The Cisco ASR 903 Router power supplies are hot-swappable. If you have installed redundant power Note supply modules, you can replace a single power supply without interrupting power to the router.

  • Page 77: Connecting The Cisco Asr 903 Router To The Network

    Step 4 other hand underneath the power supply, and slide it completely out of the chassis. If the power supply bay is to remain empty, install a blank filler plate (Cisco part number Step 5 A900-PWR-BLANK) over the opening, and secure it with the captive installation screws.
  • Page 78 “Connecting to the Auxiliary Port” section on page 3-33. When the USB port is used it takes priority over the RJ45 EIA port. The USB Type A-to-Type A cable is not included with the Cisco ASR 903 Router; it is ordered Note separately.
  • Page 79 Chapter 3 Installing the Cisco ASR 903 Router Connecting the Cisco ASR 903 Router to the Network Figure 3-22 Connecting the USB Console Cable to the Cisco ASR 903 Router 1PPS CONSOLE GE-0 GE-1 GE-2 GE-3 GE-4 GE-5 GE-6 GE-7...

  • Page 80: Connecting To The Console Port Using Mac Os X

    Chapter 3 Installing the Cisco ASR 903 Router Connecting the Cisco ASR 903 Router to the Network Connecting to the Console Port using Mac OS X This procedure describes how to connect a Mac OS X system USB port to the console using the built in OS X Terminal utility.

  • Page 81: Installing The Cisco Microsoft Windows Usb Device Driver

    Step 7 Installing the Cisco Microsoft Windows 2000 USB Driver This procedure shows how to install the Microsoft Windows 2000 USB driver. Obtain the file Cisco_usbconsole_driver.zip from the Cisco.com web site and unzip it. Step 1 Double-click the file setup.exe.

  • Page 82: Uninstalling The Cisco Microsoft Windows Usb Driver

    The USB console is ready for use. Step 7 Uninstalling the Cisco Microsoft Windows USB Driver This section provides instructions for how to uninstall the Cisco Microsoft Windows USB device driver. “Uninstalling the Cisco Microsoft Windows XP and 2000 USB Driver” •...

  • Page 83: Connecting To The Auxiliary Port

    Chapter 3 Installing the Cisco ASR 903 Router Connecting the Cisco ASR 903 Router to the Network Run the setup.exe for Windows 32-bit or setup(x64).exe for Windows-64bit. Click Next. Step 1 The InstallShield Wizard for Cisco Virtual Com appears. Click Next.
  • Page 84 Chapter 3 Installing the Cisco ASR 903 Router Connecting the Cisco ASR 903 Router to the Network To connect a modem to the router, follow these steps: Step 1 Connect the RJ45 end of the adapter cable to the black AUX port on the router, as shown in Figure 3-23.

  • Page 85: Connecting A Management Ethernet Cable

    Connecting a USB Flash Device To connect a USB flash device to the Cisco ASR 903 Router, insert the memory stick in the USB port labeled MEM. The Flash memory module can be inserted in only one way, and can be inserted or removed regardless of whether the router is powered up or not.

  • Page 86: Removing A Usb Flash Device

    M E M C O N S O L Removing a USB Flash Device To remove and then replace a USB flash token memory stick from a Cisco ASR 903 Router, follow these steps: Step 1 Pull the memory stick from the USB port.
  • Page 87 Chapter 3 Installing the Cisco ASR 903 Router Connecting the Cisco ASR 903 Router to the Network Connect the other end to the BTS patch or demarcation panel at your site. Step 3 Turn on power to the router. Step 4 For information about the BITS port pinouts, see Chapter 5, “Troubleshooting.”...

  • Page 88: Connecting Cables To A Gps Interface

    Connecting the Cisco ASR 903 Router to the Network Connecting Cables to a GPS Interface The following sections describe how to connect cables from the Cisco ASR 903 Router to a GPS unit for input or output timing of frequency: Connecting Cables to the Input 10Mhz or 1PPS Interface, page 3-38 •...

  • Page 89: Connecting Ethernet Cables

    For more information about GPS port pinouts, see Chapter 5, “Troubleshooting.” Note Connecting Ethernet Cables The Cisco ASR 903 Router interface modules support RJ45 or SFP Ethernet ports. For instructions on how to connect cables to Ethernet SFP ports, see Connecting Cables to SFP Modules, page 3-40.

  • Page 90: Connecting Cables To Sfp Modules

    For information on connecting cables to Cisco optical and Ethernet SFP interfaces, see http://www.cisco.com/en/US/partner/products/hw/modules/ps5455/prod_installation_guides_list.html. Connecting T1/E1 cables The physical layer interface for the Cisco ASR 903 Router T1/E1 port is a customer-installed high-density connector. The high-density connector has thumbscrews which should be screwed into the interface when the cable is installed.

  • Page 91: Rj45 Cable Pinouts

    Chapter 3 Installing the Cisco ASR 903 Router Connecting the Cisco ASR 903 Router to the Network Figure 3-26 shows how the cable is connected between the T1/E1 interface module and the patch panel. Figure 3-26 Cable Installation between T1/E1 Interface and Patch Panel...

  • Page 92: Recommended Patch Panel

    OSP wiring. Only Pins 1, 2, 4, 6, and 8 are available for customer use. The remaining pins are for Cisco manufacturing test, and should not be connected. Use a shielded cable for connection to this port for EMC protection.

  • Page 93: Connector And Cable Specifications

    Chapter 3 Installing the Cisco ASR 903 Router Connecting the Cisco ASR 903 Router to the Network Connector and Cable Specifications For more information on cable specifications and pinouts, see Chapter 5, “Troubleshooting”. Cisco ASR 903 Router Hardware Installation Guide...
  • Page 94 Chapter 3 Installing the Cisco ASR 903 Router Connecting the Cisco ASR 903 Router to the Network Cisco ASR 903 Router Hardware Installation Guide 3-44 OL-25178-04...

  • Page 95: Chapter 4 Cisco Asr 903 Router Initial Configuration

    Cisco hardware. To configure the Cisco ASR 903 Router from a console, you need to connect a terminal to the router console port. This chapter contains the following sections: •...

  • Page 96: Powering Up The Cisco Asr 903 Router

    Statement 1029 After installing your Cisco ASR 903 Router and connecting cables, start the router and follow these steps: Activate the DC power supply using the steps described in “Activating the DC Power Supply”...
  • Page 97 "License Notice" file accompanying the IOS-XE software, or the applicable URL provided on the flyer accompanying the IOS-XE software. A summary of U.S. laws governing Cisco cryptographic products may be found at: http://www.cisco.com/wwl/export/crypto/tool/stqrg.html If you require further assistance please contact us by sending email to export@cisco.com.
  • Page 98 Chapter 4 Cisco ASR 903 Router Initial Configuration Powering Up the Cisco ASR 903 Router *Feb 19 17:34:29.720: %PARSER-4-BADCFG: Unexpected end of configuration file. *Feb 19 17:34:29.809: %NETCLK-5-NETCLK_MODE_CHANGE: Network clock source not available. The network clock has changed to freerun *Feb 19 17:34:10.138: %CPPHA-7-SYSREADY: F0: cpp_ha:...

  • Page 99: Verifying The Front Panel Leds

    Configuring the Cisco ASR 903 Router at Startup This section explains how to create a basic running configuration for your Cisco ASR 903 Router. You need to acquire the correct network addresses from your system administrator or consult...

  • Page 100: Using The Console Interface

    To configure a Cisco ASR 903 Router from the console, you must connect a terminal or terminal server to the console port on the Cisco ASR 903 Router RSP. To configure the Cisco ASR 903 Router using the management Ethernet port, you must have the router’s IP address available.

  • Page 101: Checking The Running Configuration Settings

    Basic management setup configures enough connectivity for managing the system; extended setup will ask you to configure each interface on the system. For detailed information about setting global parameters, refer to the Cisco ASR 903 Router Software Configuration Guide. Checking the Running Configuration Settings...

  • Page 102: Safely Powering Off The Cisco Asr 903 Router

    Safely Powering Off the Cisco ASR 903 Router This section explains how to shut down the Cisco ASR 903 Router. It is recommended that before turning off all power to the chassis, you issue the reload command. This insures that the operating system cleans up all the file systems.

  • Page 103: Chapter 5 Troubleshooting

    C H A P T E R Troubleshooting The following sections provide information for troubleshooting problems on the Cisco ASR 903 Router. • Pinouts, page 5-1 • LED Summary, page 5-7 Pinouts The following sections describe the pinouts for the Cisco ASR 903 Router interfaces: BITS Port Pinout, page 5-1 •...

  • Page 104: Gps Port Pinout

    Signal Name Direction Description 1PPS_P Output or Input 1PPS RS422 signal 1PPS_N Output or Input 1PPS RS422 signal RESERVED Output Do NOT connect Time of Day character RESERVED Input Do NOT connect Cisco ASR 903 Router Hardware Installation Guide OL-25178-04...

  • Page 105: Alarm Port Pinout

    Signal Name Direction Description Output Request to send Output Data Terminal Ready (always On). Output Transmit data Ring Indicator Input Receive data DSR/DCD Input Data set ready/Data Carrier detect Input Clear to send Cisco ASR 903 Router Hardware Installation Guide OL-25178-04...

  • Page 106: T1/E1 Port Pinout

    Troubleshooting Pinouts T1/E1 Port Pinout Table 5-6 summarizes the pinouts of the cable (Tyco part number 2163442-1, Cisco part number 72-5184-01) used to connect the T1/E1 interface module to the rear of the patch panel. Table 5-6 T1/E1 Interface Pinouts...

  • Page 107: Management Ethernet Port Pinout

    Wiring Schematic of Cable between T1/E1 Interface and Patch Panel Management Ethernet Port Pinout Table 5-7 summarizes the Management Ethernet port pinout. Table 5-7 Fan Tray Alarm Port Pinout Signal Name Description TRP0+ TRP0- TRP1+ TRP2+ TRP2- TRP1- TRP3+ TRP3- Cisco ASR 903 Router Hardware Installation Guide OL-25178-04...

  • Page 108: Usb Console Port Pinout

    Within the single-mode category, three transmission types are defined: short reach, intermediate reach, and long reach. Within the multimode category, only short reach is available. For information about optical SFP modules, see the documentation for the SFP module at http://www.cisco.com/en/US/partner/products/hw/modules/ps5455/prod_installation_guides_list.html. Cisco ASR 903 Router Hardware Installation Guide OL-25178-04...

  • Page 109: Led Summary

    Chapter 5 Troubleshooting LED Summary LED Summary The following sections describe the meanings of the LEDs on the Cisco ASR 903 Router. RSP LEDs, page 5-7 • Interface Module LEDs, page 5-8 • Power Supply LEDs, page 5-10 • •...

  • Page 110: Interface Module Leds

    Amber Booting (if local CPU) Green Operational Link status Inactive or no connection Amber Fault/loop condition Green Ok with no activity Flashing OK with activity green Speed (S) 100/10 Mbps/Slow Green 1Gbps/Full Cisco ASR 903 Router Hardware Installation Guide OL-25178-04...

  • Page 111: Oc-3 Interface Module Leds

    One or more configured ports are down Blinking One or more configured ports are down and at least one configured port amber is in a loopback state All ports disabled or shut down Cisco ASR 903 Router Hardware Installation Guide OL-25178-04...

  • Page 112: Power Supply Leds

    Green Fan (FAN) Green Fan rotation in range Amber Fan fault Two or more fan faults Minor No minor alarm (MIN) Amber Minor alarm Major No major alarm (MAJ) Major alarm Cisco ASR 903 Router Hardware Installation Guide 5-10 OL-25178-04...

  • Page 113: Alarm Conditions

    No critical alarm (CRIT) Critical alarm (defaults to ON upon RSP reset) Alarm Conditions Table 5-17 summarizes the meaning of alarm conditions on the Cisco ASR 903 Router. Table 5-17 Alarm Condition Summary Alarm Type Alarm Meaning Critical RSP OIR...
  • Page 114 Chapter 5 Troubleshooting LED Summary Cisco ASR 903 Router Hardware Installation Guide 5-12 OL-25178-04...

  • Page 115: Site Log

    • Upgrade, removal, and maintenance procedures—Use the Site Log as a record of ongoing router maintenance and expansion history. Each time a task is performed on the Cisco ASR 903 Router, update the Site Log to reflect the following: –...
  • Page 116 Appendix A Site Log Table A-1 Site Log Date Description of Action Performed or Symptom Observed Initials Cisco ASR 903 Router Hardware Installation Guide OL-25178-04...
  • Page 117 IP, router address show startup-config configuring global parameters reviewing changes connecting site router to a PC ?? to 3-28 console port modifications to configuration, reviewing electrical wiring requirements 2-12 Cisco ASR 903 Router Hardware Installation Guide IN-1 OL-25178-04...
  • Page 118 PC ?? to 3-28 RS-232 asynchronous data 2-14 safety information 1-16 sample configurations, global parameters show commands show running-config show startup-config show environment command 2-17 site site requirements, rack-mounting 2-15 Cisco ASR 903 Router Hardware Installation Guide IN-2 OL-25178-04...

Table of Contents
