Edimax AR-7286WnA User Manual

Adsl2+ router
Hide thumbs Also See for AR-7286WnA:
Table of Contents

Advertisement

Quick Links

AR-7286WnA / AR-7286WnB
User Manual
6-2013 / v1.0
1

Advertisement

Table of Contents
loading

Related Manuals for Edimax AR-7286WnA

Summary of Contents for Edimax AR-7286WnA

  • Page 1 AR-7286WnA / AR-7286WnB User Manual 6-2013 / v1.0...
  • Page 2 COPYRIGHT Copyright  Edimax Technology Co., Ltd. all rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission from Edimax Technology Co.,...

  • Page 3: Table Of Contents

    Contents 1. PRODUCT INTRODUCTION ........................5 1.1. P ..........................5 ACKAGE ONTENTS 1.2. S ........................5 YSTEM EQUIREMENTS 1.3. S .......................... 5 AFETY RECAUTIONS 1.4. LED S & B ..................... 6 TATUS UTTON EFINITIONS 1.5. F ............................9 EATURES 2. HARDWARE INSTALLATION ........................10 3.
  • Page 4 5.4.3. Wireless ..........................60 5.5. A ..........................62 DVANCED ETUP 5.5.1. Firewall..........................63 5.5.2. Routing ..........................63 5.5.3. NAT ............................64 5.5.4. QoS ............................68 5.5.5. VLAN ............................ 73 5.5.6. ADSL ............................. 75 5.6. A ........................76 CCESS ANAGEMENT 5.6.1. ACL ............................76 5.6.2.

  • Page 5: Product Introduction

    Before you start using this product, please check if there is anything missing in the package and contact your dealer to claim the missing item(s): ADSL2+ router (AR-7286WnA or AR-7286WnB)  12V power adapter  1 meter RJ-45 Ethernet cable ...

  • Page 6: Led Status & Button Definitions

     Do not put this device close to heat sources or high temperatures. Keep the device out of direct sunshine.  Do not put this device close to a place where it is damp or wet. Do not spill any fluid on this device. ...
  • Page 7 Internet Green Internet connected in router mode Flashing Internet activity (transferring/receiving data) in router mode. Device in bridged mode. Internet not connected in router mode (Please refer to Note ii. below). LAN1–4 Green LAN port connected. Flashing LAN activity (transferring/receiving data). LAN port not connected.
  • Page 8 Rear Panel Item Description Power On/Off Button Switches the router on or off. Power Power port for included 12V power adapter. Wireless On/Off Button Switch the wireless signal on or off. WPS Button Activate WPS (Wi-Fi Protected Setup) LAN 1–4 RJ-45 Ethernet ports 1–4.

  • Page 9: Features

    1.5. Features The device supports the following features:  Various line modes  External PPPoE dial-up access  Internal PPPoE/PPPoA dial-up access  1483Bridged/1483Routed with dynamic ip or static ip  Multiple PVCs (8 PVCs supported)  DHCP server/relay  Static route ...

  • Page 10: Hardware Installation

    2. Hardware Installation Connect the ADSL line. Connect the line port of the router of the device to the modem interface of a splitter using a telephone cable. Connect a telephone to the Phone interface of the splitter using a telephone cable. Connect the Line interface of the splitter to your existing, incoming line.
  • Page 11 Connect the power adapter to the router. Plug one end of the power adapter into a wall outlet and connect the other end to the 12V interface of the device. The following diagrams show how to correctly connect the router, PC, splitter and the telephone sets under two different configurations: Configuration 1 0 shows the correct connection of the router, PC, splitter and the telephone...
  • Page 12 Configuration 2 0 shows the correct connection when a telephone set is installed before the splitter. Figure 2 - Connection diagram (Connecting a telephone set before the splitter) Note: When Configuration 2 is used, the filter must be installed close to the telephone cable.
  • Page 13 Firewall settings. Please turn off all personal firewalls before you continue the setup – firewalls can block communication between your PC and router. Note: You must use the power adapter included in the package with the router, do NOT attempt to use a third-party power adapter. PC LAN IP configuration.
  • Page 14 Locate the “Network Connections” icon and double-click to open network connection settings. Select the “Local Area Connection” icon and right-click it to open the sub-menu, then select “Properties”.
  • Page 15 Select “Internet Protocol (TCP/IP)” and then click “Properties” Ensure that “Obtain an IP address automatically” and “Obtain DNS server address automatically” are selected and then press “OK”.

  • Page 17: Ip Address Setting

    3. IP Address Setting To use the router to access the Internet, the PCs in the network must have an Ethernet adapter installed and be connected to the router either directly or through a hub or switch. The TCP/IP protocol of each PC must be installed and the IP Address of each PC has to be set in the same subnet as the router.
  • Page 18 2. Click the Network icon and then select Open Network and Sharing Center to open the Network and Sharing Center window. 3. Click Ethernet to open the Ethernet Status window, and then select Properties. The Local Area Connection window will appear.
  • Page 19 4. Check your list of Network Components. Select Internet Protocol Version 4 (TCP/IPv4) and click the Properties button. 5. In the Internet Protocol Version 4 (TCP/IPv4) Properties window, select Obtain an IP address automatically and Obtain DNS server address automatically as shown on the following screen.

  • Page 20: Windows 7

    6. Click OK (shown above) to confirm the setting. Your PC will now obtain an IP address automatically from your router’s DHCP server. Note: Please make sure that the router’s DHCP server is the only DHCP server available on your LAN. 3.2.

  • Page 21: Windows Vista

    4. In the Internet Protocol Version 4 (TCP/IPv4) Properties window, select Obtain an IP address automatically and Obtain DNS server address automatically as shown on the following screen. 5. Click OK to confirm the setting. Your PC will now obtain an IP address automatically from your router’s DHCP server.

  • Page 22: Windows Xp

    3. Check your list of Network Components. You should see Internet Protocol Version 4 (TCP/IPv4) on your list. Select it and click the Properties button. 4. In the Internet Protocol Version 4 (TCP/IPv4) Properties window, select Obtain an IP address automatically and Obtain DNS server address automatically as shown on the following screen.
  • Page 23 3. Check your list of Network Components. You should see Internet Protocol [TCP/IP] on your list. Select it and click the Properties button. 4. In the Internet Protocol (TCP/IP) Properties window, select Obtain an IP address automatically and Obtain DNS server address automatically as shown on the following screen.

  • Page 24: Ezmax Setup Wizard

    4. EZmax Setup Wizard You can configure the router by running the setup wizard on the CD-ROM included in the package contents. The wizard enables you to configure your Internet connection, upgrade the firmware and change the router’s password. Please follow the instructions below. Alternatively, if you lose the CD-ROM or prefer a web based setup, you can login to the ADSL router using Internet Explorer, and configure the router from there using the web-based interface.
  • Page 25 Please select your product.
  • Page 26 Please ensure all hardware is correctly installed. Check the box and click “Next”.
  • Page 27 Select your country and ISP. If your ISP is not listed, select “Other” from the list and refer to 4.2. Internet Connection Type. Enter your ISP’s username and password and click “Apply”. On the next screen, click “Apply” again.
  • Page 28 Please wait while the router connects to the Internet. When the router is connected successfully, you will see the screen below.

  • Page 29: Internet Connection Type

    4.2. Internet Connection Type If your country or ISP is not listed, please select “Other” from the list.
  • Page 30 Then select your Internet connection type and click “Next”. If you are not sure, please contact your Internet Service Provider (ISP). Depending on your selection, please refer to the appropriate chapter: 4.2.1. PPPoE/PPPoA 4.2.2. Bridge Mode 4.2.3. Dynamic IP Address 4.2.4.

  • Page 31: Ppoe/Pppoa

    Static IP Address Uses a static IP address. Your service provider gives a static IP address to access Internet services. 4.2.1. PPoE/PPPoA Parameter Description User Name Enter the username exactly as your ISP assigned. Password Enter the password that your ISP has assigned to you. Virtual path identifier (VPI) is the virtual path between two points in an ATM network.

  • Page 32: Bridge Mode

    between two points in an ATM network. Its valid value is in the range of 32 to 65535 (0 to 31 is reserved for local management of ATM traffic). Enter the correct VCI provided by your ISP. By default, VCI is set to 35.

  • Page 33: Dynamic Ip Address

    Virtual channel identifier (VCI) is the virtual channel between two points in an ATM network. Its valid value is in the range of 32 to 65535 (0 to 31 is reserved for local management of ATM traffic). Enter the correct VCI provided by your ISP. By default, VCI is set to 35.

  • Page 34: Static Ip

    default, VPI is set to 8. Virtual channel identifier (VCI) is the virtual channel between two points in an ATM network. Its valid value is in the range of 32 to 65535. (0 to 31 is reserved for local management of ATM traffic) Enter the correct VCI provided by your ISP.

  • Page 35: Firmware Upgrade

    4.3. Firmware Upgrade The wizard includes a tool to upgrade the router’s firmware. Firmware can be downloaded from the Edimax website; if you wish to upload new firmware, select “Firmware Upgrade” from the menu across the top of the screen.

  • Page 37: Web Configuration

    5. Web Configuration The router can also be configured using the web-based configuration interface. Follow the instructions below. 5.1. Accessing the Router To access the web-based configuration interface: 1. Open the Internet Explorer (IE) browser and enter http://192.168.2.1. 2. In the Login page that is displayed, enter the username and password. ...

  • Page 38: System Log

    5.2.2. System Log Choose Status > System Log, the page shown in the following figure appears. In this page, you can view, clear or save the system log.

  • Page 39: Statistics

    5.2.3. Statistics Choose Status > Statistics. The Statistics page that is displayed contains Ethernet Statistics, ADSL Statistics and WLAN Statistics. 5.2.3.1. Ethernet Statistics In the Traffic Statistics page, click Ethernet and the page shown in the following figure appears. In this page, you can view the statistics such as total Bytes, Collision, Error Frames and CRC Errors.

  • Page 40: Quick Start

    5.2.3.1. WLAN Statistics In the Traffic Statistic page, click WLAN and the page shown in the following figure appears. In this page, you can view the WLAN statistics such as transmit/receive frames count, errors count and drops count. 5.3. Quick Start The Quick Start page will guide you to configure the ADSL router to connect to your ISP (Internet Service Provider).
  • Page 41 1. Click RUN WIZARD, there will pop up a new page as shown in the following figure appears. 2. Click EXIT, this page will be closed. Click NEXT, the page as shown in the following figure appears.

  • Page 42: Auto Setup By Isp List

    In this page, enter a new password for the admin account. After finishing all quick start settings, it will be saved and effect immediately. 3. Click NEXT, the page as shown in the following figure appears. In this page, you can select a local time zone. 4.

  • Page 43: Bridge Mode

    The following table describes the parameters in this page: Field Description Country Select the country you are in. Select your Internet Service Provider (ISP). Virtual path identifier (VPI) is the virtual path between two points in an ATM network. Its valid value is between 0 and 255.

  • Page 44: Dynamic Ip Address

    The following table describes the parameters in this page: Field Description Virtual path identifier (VPI) is the virtual path between two points in an ATM network. Its valid value is between 0 and 255. Enter the correct VPI provided by your ISP. By default, VPI is set to 8.
  • Page 45 Field Description two points in an ATM network. Its valid value is between 1 and 65535. Enter the correct VCI provided by your ISP. Select a connection type from the dropdown list. You may Connection select PPPoE/ PPPoA/ Dynamic IP/ Static IP/ Routered IP/ Type Bridge.

  • Page 46: Pppoe/Pppoa

    Field Description Mask Enter the default gateway provided by your ISP. Gateway Connection You can select LLC or VC-Mux. In this example, the Type encapsulation mode is set to 1483 Bridged IP LLC. 5.3.4. PPPoE/PPPoA Select PPPoE/PPPoA, click NEXT, and the page as shown in the following figure will appear.

  • Page 47: Interface Setup

    Field Description Type encapsulation mode is set to PPPoE LLC. After setting, click NEXT, the page as shown in the following figure appears. Click BACK to modify the settings. Click NEXT to save the settings. Click EXIT to cancel the settings. Note: After you saving the settings in the Quick Start page, you can view this wan connection settings in the Interface Setup >...
  • Page 48 The following table describes the parameters of this page: Field Description Select a virtual circuit from the drop-list. Click PVCs Virtual Circuit Summary to view eight PVCs (from PVC0 to PVC7), and only PVC0 status is activated by default. You can select Activated or Deactivated for currently Status selected virtual circuit.
  • Page 49 Field Description Peak cell rate (PCR) is the maximum rate at which cells can be transmitted along a connection in the ATM network. Sustain cell rate (SCR) is the maximum rate that traffic can pass over PVC without the risk of cell loss. Maximum burst size (MBS) is the maximum number of cells that can be transmitted at the PCR.
  • Page 50 The following table describes the parameters of this page: Field Description IP Common Options You can choose 1483 Bridged IP LLC, 1483 Bridged IP VC-Mux, 1483 Routed IP LLC(IPoA) or 1483 Routed Encapsulation IP VC-Mux. IP Unnumbered You can choose Activated or Deactivated. You can enable or disable the default route.
  • Page 51 Field Description IGMP version 1 (IGMP v1) and IGMP version 2 (IGMP v2). Select Disabled to disable it. IPv6 Address DHCP IPv6 Provide address assignment to hosts to include Enable DHCP in local pools. You can choose DHCP or SLAAC. IPv6 Prefix Delegation Options for DHCPv6.
  • Page 52 The following table describes the parameters of this page: Field Description IP Common Options You can choose 1483 Bridged IP LLC, 1483 Bridged IP Encapsulation VC-Mux, 1483 Routed IP LLC(IPoA) or 1483 Routed IP VC-Mux. Default Route You can enable or disable default route. You can set a TCP MTU value.
  • Page 53 Field Description You can enter the gate way IP for dial-up, which is Gateway provided by your ISP. Select whether enable Network Address Translation (NAT) function. If you do not enable NAT, you must add a route on the uplink equipment, otherwise Internet access will fail.
  • Page 54 connection. Select Static PPPoE to use a static IP address for your PPPoE connection. Please enter the information accordingly. The following table describes the parameters of this page: Field Description Servicename You can set the service name. Enter the username for PPPoE dial-up, which is Username provided by your ISP.
  • Page 55 Field Description Connection Setting You can choose Always On (Recommended), Connection Connect On-Demand or Connect Manually. You can set a TCP MSS value. The range is from 100 TCP MSS Option to 1452. The default is 1400. IP Common Options Default Route You can enable or disable default route.
  • Page 56 Field Description Enable DHCP in local pools. Choose DHCP or SLAAC. IPv6 Prefix Delegation Options for DHCPv6. You may DHCP PD Enable enable or disable DHCP PD. You may enable or disable MLD Proxy. MLD proxy is MLD Proxy enabled only for route mode. It works in an IPv6 environment.

  • Page 57: Lan

    After finishing, click SAVE to apply the settings of this PVC. 5.4.2. Choose Interface Setup > LAN. The LAN page that is displayed contains Router Local IP, DHCP Server, DNS, Radvd and DHCPv6. In this page, you can change the IP address of the router. The default IP address is 192.168.2.1, which is the private IP address of the router.
  • Page 58 Field Description Mask subnet mask is from 255.255.0.0 to 255.255.255.254. Alias IP You may enter the second IP Address. Address Alias Subnet You may enter a second subnet mask. Mask Dynamic You can select RIP1, RIP2-B or RIP2-M. Route Direction You can select None, Both, IN Only or OUT Only.
  • Page 59 Field Description Auto Discovered, the router accepts the firstly-received DNS assignment from one of the PPPoA, PPPoE or MER enabled PVC(s) during the connection establishment. If select User Discovered, enter the IP addresses of the primary and secondary DNS servers. Primary DNS DNS server FOR wan and LAN Server...
  • Page 60 In the DHCP field, choose DHCP Relay, the page shown in the following figure appears. Enter a server IP address running on WAN side.

  • Page 61: Wireless

    5.4.3. Wireless Choose Interface Setup > Wireless. The page as shown in the following figure appears. The Wireless page contains Access Point Settings, 11n Settings, Multiple SSIDs Settings, WPS Settings and Wireless MAC Address Filter. The following table describes the parameters of this page: Field Description Access Point Settings...
  • Page 62 Field Description power levels within these frequency ranges. The default is 2. Beacon Interval Beacon Interval range is from 20 to 1000. RTS/CTS RTS/CTS Threshold range is from 1500 to 2347. Threshold Fragmentation Enter a Fragmentation Threshold between 256 and Threshold 2346 (even numbers only).

  • Page 63: Advanced Setup

    Field Description wireless client searches. WPS technology allows new customers without a previously-established account to securely connect Use WPS to your network at the Wi-Fi hotspot, create and pay for an account, and access the Internet. WPS Settings WPS state WPS state is displayed here.

  • Page 64: Firewall

    5.5.1. Firewall Choose Advanced Setup > Firewall. The page shown in the following figure appears. You can select this option to automatically detect and block Denial of Service (DoS) attacks such as Ping of Death, SYN Flood, Port Scan and Land Attack.

  • Page 65: Nat

    The following table describes the parameters and buttons of this page: Field Description Destination Enter the IP address of the destination device. IP Address IP Subnet Enter the subnet mask of the destination device. Mask Gateway IP You can enter the IP address of the next hop in the IP route to Address the destination device, or bind with a PVC interface.
  • Page 66 Field Description This field is to specify how many IPs are provided by your ISP for the current VC. You can select Single or Multiple. When Number of you choose Single, you can set DMZ or Virtual Server. When you choose Multiple, You can set DMZ, Virtual Server or IP Address Mapping (for Multiple IP Service).
  • Page 67 The following table describes the parameters of this page: Field Description Select Enabled or Disabled to enable this function. Enter the specified IP Address for the DMZ host on the LAN Host IP side. Address In the NAT page, choose Virtual Server, and the page shown in the following figure appears.
  • Page 68 Field Description You can enter an application name, or select a name from the Application right drop-list menu like FTP or TELNET. Choose the transport layer protocol that the service type. You Protocol can choose ALL, TCP or UDP. Enter the specific start and end port number you want to Start/End forward.

  • Page 69: Qos

    The following table describes the parameters of this page: Field Description The Virtual server rule index for this VC. You can specify Rule Index 10 rules in maximum. All the VCs with single IP will use the same Virtual Server rules. Choose the One-to-One, Many-to-One, Many-to-Many Rule Type Overload, Many-to-Many No Overload, or Server.
  • Page 70 The following table describes the parameters of this page: Field Description Quality of Service IP Version In this example, the IP version is set to IPv4. You may select Activated or Deactivated. After activating QoS, you may set the upload bandwidth of the WAN interface.
  • Page 71 Field Description MGCP, SNMP, DNS, DHCP, RIP, RSTP, RTCP and RTP. Physical Ports Choose an Ethernet interface or WLAN Interface. The Destination MAC address of the rule. If data packets Destination include the MAC address, the data packets are placed into the group.
  • Page 72 Field Description video and voice. Data classes four through one range from controlled-load applications such as streaming multimedia and business-critical traffic - carrying SAP data, for instance - down to "loss eligible" traffic. Zero is used as a best-effort default priority, invoked automatically when no other value has been set.
  • Page 73 The following table describes the parameters of this page: Field Description Quality of Service Select IP version. In this example, the IP version is set to IP Version IPv6. Select Activated or Deactivated. After activating QoS, you may set the upload bandwidth of the WAN interface. Click the QoS Settings Summary button to view the table Summary of Qos rules and actions.

  • Page 74: Vlan

    Click Save at the bottom of the page to save the discipline. To view the rules and actions, click QoS Settings Summary to enter the page shown in the following figure appears. 5.5.5. VLAN Choose Advanced Setup > VLAN, the page shown in the following figure appears.
  • Page 75 Each physical port has a default VID called PVID (Port VID). PVID is assigned to untagged frames or priority tagged frames (frames with null (0) VID) received on this port. You can set a PVID for an ATM VC, Ethernet port or Wireless LAN.

  • Page 76: Adsl

    The following table describes the parameters of this page: Field Description VLAN Index Choose a VLAN index from 1 to 8. Select Yes or No to specify whether VLAN settings Active are active or not. VLAN ID VLAN ID is from 1 to 4094. ATM VCs Supports eights ATM VCs, which can be tagged.

  • Page 77: Access Management

    The router supports these modulations: G.Lite, T1.413, G.DMT, ADSL2, ADSL2+ and Auto-Syno Up. The router negotiates the modulation modes with the DSLAM. The following table describes the parameters and buttons of this page: Field Description Choose Auto Sync-Up, ADSL2+, ADSL2, G.DMT, T1.413 or ADSl Mode G.lite.

  • Page 78: Filter

    The following table describes the parameters and buttons of this page: Field Description ACL Rule Index You can establish sixteen ACL rules at most. Active Click to enable or disable the rule. Secure IP The rule is valid if the IP is in this range. Address Application Support Web, FTP, Telnet, SNMP, Ping or ALL.
  • Page 79 The following table describes the parameters and buttons of this page: Field Description Filter Type Support IP / MAC Filter, Application Filter and URL Selection Filter. IP/MAC Filter Set You can choose an IP / MAC Filter Set Index from 1 to 12. Index You can select an interface from the eight PVCs or the Interface...
  • Page 80 5.6.2.2. Application Filter Choose Access Management > Filter, select Application Filter from the drop- down list Filter Type Selection, and the page shown in the following figure appears. Select Application Filter type. The user can set Application rules to filter the ICQ, MSN, YMSG, Real Audio/Video packets. The following table describes the parameters and buttons of this page: Field Description...

  • Page 81: Snmp

    The following table describes the parameters and buttons of this page: Field Description Active Make URL Filter rule activated or deactivated. URL Index Can set an URL Filter Index from 1 to 16. Enter the URL that needs to be filtered. 5.6.3.

  • Page 82: Upnp

    The following table describes the parameters of this page: Field Description Get Community Select to set the password for the incoming Get- and GetNext requests from the management station. Set Community Select to set the password for incoming Set requests from the management station.

  • Page 83: Ddns

    5.6.5. DDNS Choose Access Management > DDNS, the page shown in the following figure appears. The Dynamic Domain Name System (DDNS) lets you use a static host name with a dynamic IP address. User should type the host name, user name and password assigned to your ADSL Router by your Dynamic DNS provider.
  • Page 84 The following table describes the parameters of this page: Field Description URL for the CPE to connect to the ACS using the CPE WAN Management Protocol. This parameter must be in the form of a valid http or https URL. User Username used to authenticate the CPE when making a Name...

  • Page 85: Maintenance

    5.7. Maintenance In the navigation bar, click Maintenance. The Maintenance page that is displayed contains Administration, Time Zone, Firmware, SysRestart and Diagnostics. 5.7.1. Administration Choose Maintenance > Administration, the page shown in the following figure appears. There is only one account that can access the Web- Management interface.

  • Page 86: Firmware

    The following table describes the parameters of this page: Field Description Synchronize You can choose NTP Server automatically, PC’s Clock or time with Manually. Choose the time zone in which area you are from the drop- Time Zone down list. Daylight You can enable the daylight saving time.

  • Page 87: Sysrestart

    The following table describes the parameters of this page: Field Description New Firmware Click Browse to select the firmware file. Location Click Browse and select a path to save the configuration Romfile Backup file of the router. After selecting the file, click UPGRADE to starting UPGRADE upgrading the file.

  • Page 88: Diagnostics

    5.7.5. Diagnostics Choose Maintenance > Diagnositics, the page shown in the following figure appears. The page shows the test results for the connectivity of the physical layer and protocol layer for both LAN and WAN sides. The following table describes the parameters of this page: Field Description Virtual Circuit...

  • Page 89: Trouble Shooting

    6. Trouble Shooting Question Answer Check the connection between the power  Why are all the indicators adapter and the power socket. off? Check whether the power switch is turned on.  Check the connection between the device and  Why is the LAN indicator your PC, hub or switch.

  • Page 90: Eu Declaration Of Conformity

    EU Declaration of Conformity English: This equipment is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC, 2009/125/EC. French: Cet équipement est conforme aux exigences essentielles et autres dispositions de la directive 1999/5/CE, 2009/125/CE Czechian: Toto zařízení je v souladu se základními požadavky a ostatními příslušnými ustanovení mi směrnic 1999/5/ES, 2009/125/ES.

  • Page 91: Declaration Of Conformity

    Declaration of Conformity We, Edimax Technology Co., LTD., declare under our sole responsibility, that the equipment described below complies with the requirements of the European Council directive (1995/5/EC, 2006/95/EC，EC/1275/2008). Equipment : N300 Wireless ADSL Modem Router Model No. : AR-7286WnA & AR-7286WnB...
