Page 1 Océ cm3522/ cm2522 Printing for Professionals User’s Guide Enlarge Display Operations...
Page 2 The Océ cm3522/cm2522 User’s Guide [Enlarge Display Operations] contains details on the operation of the various functions available in the Enlarge Display mode of the Océ cm3522/cm2522 and on the various operating precautions. In order to ensure that this machine is used correctly and efficiently, carefully read the Enlarge Display Mode Operations volume of the User’s Guide before using the machine.
Page 3 Names highlighted as shown above indicate keys on the control panel and buttons in the touch panel. Océ cm3522/cm2522...
Page 4: Table Of Contents
2.3 Selecting the Paper settings ............2-6 2.3.1 Automatically selecting the paper size ("Auto" Paper setting) ..2-6 2.3.2 Manually selecting the desired paper size ........2-8 2.4 Specifying a Zoom setting ............2-9 2.4.1 Selecting a zoom ratio ...............2-10 Océ cm3522/cm2522...
Page 5 3.2.2 Selecting a destination from the job log ........3-7 3.2.3 Selecting a destination with an LDAP search ......3-8 3.2.4 Directly typing in the number .............3-10 3.3 Specifying scanning settings (Scan Settings) ......3-13 3.3.1 Simplex/Duplex ................3-13 3.3.2 Original Type ................3-15 Océ cm3522/cm2522...
Page 6 4 Logging on and logging off 4.1 When a logon screen appears ........... 4-2 4.1.1 When the screen to enter the user name appears ......4-2 4.1.2 When the screen to enter the account name and password appears ..................4-5 Océ cm3522/cm2522...
Page 7 Océ cm3522/cm2522...
Page 8: Before Use
Before use...
Page 9: Names Of Control Panel Parts And Their Functions
[Mode Memory] key Programmed fax/scan settings can be recalled to be used again. (See 3-30) [Utility/Counter] key Press to display the Meter Count screen and the Utility screen. Océ cm3522/cm2522...
Page 10 [Fax/Scan] key lights up in green. [Copy] key Press to enter Copy mode. (As a default, the standard- sized Copy mode screen is displayed.) While the machine is in Copy mode, the indicator on the [Copy] key lights up in green. Océ cm3522/cm2522...
Page 11: Adjusting The Angle Of The Control Panel
Upper position (base position) Middle position Lower position Left tilt position 1.2.1 To adjust the angle of the control panel Pull the control panel release lever toward you to raise or lower the control panel. Control panel release lever Océ cm3522/cm2522...
Page 12 To tilt the control panel to the left, hold the bottom of the control panel, and then tilt the panel to the left. – Do not grab the touch panel when turning the control panel to the left or right. Océ cm3522/cm2522...
Page 13: Screens In Enlarge Display Mode
The screen is displayed in Enlarge Display mode. While screens are displayed in Enlarge Display mode, pressing the [Copy] or [Fax/Scan] key displays the normal screen. To return to the standard-sized screens from the screens in Enlarge Display mode, press the [Enlarge Display] key in the control panel. Océ cm3522/cm2522...
Page 14 [Accessibility] key. On the Accessibility Setting screen 2/2, touch [Default Enlarge Display Settings], press the [Copy] key or the [Fax/Scan] key, and then specify "Current Setting". The default settings can be also changed in Utility mode. For details, refer to the User’s Guide [Copy Operations]. Océ cm3522/cm2522...
Page 15: Touch Panel
Touch this icon to view a screen containing a warning code. This button appears when there is a message indicating that consumables must be replaced or the machine requires maintenance. Touch this button to display the message, and then perform the replacement or maintenance procedure. Océ cm3522/cm2522...
Page 16: Paper Type Icons
Thick 1 Thick 2 Thick 3 Thick 4 Single Side Only Transparency Envelope Letterhead Special Paper Colored Paper Duplex 2nd Side/Plain Paper Duplex 2nd Side/Thick 1 Duplex 2nd Side/Thick 2 Duplex 2nd Side/Thick 3 Duplex 2nd Side/Thick 4 Océ cm3522/cm2522...
Page 17: Paper Supply Icons
"Selecting the Paper settings" on page 2-6. Paper supply icons that appear Icon Description This icon indicates that very little paper remains in the paper tray. This icon indicates that paper is not loaded in the paper tray. Océ cm3522/cm2522 1-10...
Page 18: Feeding The Original
Place the original in the original feed tray in the order to be scanned with the side to be scanned faces up. – Load the original pages so that the top of the original is toward the back or the right side of the machine. Océ cm3522/cm2522 1-11...
Page 19: Placing The Original On The Original Glass
– Load the original pages so that the top of the original is toward the back or the left side of the machine. When loaded in the v orientation: When loaded in the w orientation: 20° 20° Océ cm3522/cm2522 1-12...
Page 20 Before use Align the original with the mark in the back-left corner of the original scales. Original scales Close the ADF or the original cover. Océ cm3522/cm2522 1-13...
Page 21: Specifying Original Settings
Originals of different sizes can be loaded together into the ADF to be fed and scanned one by one automatically. Slide the lateral guides of the ADF to fit the size of the largest page. Align the originals as the references so that the side to be scanned faces up. Océ cm3522/cm2522 1-14...
Page 22 – Load the original pages into the ADF so that the top of the pages is toward the left side of the machine. Lateral guides In the main screen, touch the Original/Density tab. The Original/Density screen appears. Océ cm3522/cm2522 1-15...
Page 23: Loading Folded Originals ("Z-Folded Original" Setting)
The length of the first page of the original is detected, and all pages of the original are scanned at that size. Reminder Unfold folded originals before loading them into the ADF. If the original is copied without being unfolded, a paper misfeed may occur. Position the original to be copied. Océ cm3522/cm2522 1-16...
Page 24 Before use In the main screen, touch the Original/Density tab. The Original/Density screen appears. Touch [Z-Folded Original]. – To cancel the "Z-Folded Original" setting, touch [Z-Folded Original] again to deselect it. Océ cm3522/cm2522 1-17...
Page 25: Selecting The Original Orientation (Original Direction Settings)
Position the original to be copied. – For details on positioning the original, refer to "Feeding the original" on page 1-11. In the Basic screen, touch [Duplex/Combine]. Otherwise, touch the Original/Density tab. Océ cm3522/cm2522 1-18...
Page 26 From the Duplex/Combine screen From the Original/Density screen The Original Direction screen appears. Touch the button for the orientation of the loaded original, and then touch [OK]. – To return to the main screen, touch [Main Screen]. Océ cm3522/cm2522 1-19...
Page 27: Selecting The Position Of The Binding Margin (Original Binding Position/Binding Position Settings)
Position the original to be copied. – For details on positioning the original, refer to "Feeding the original" on page 1-11. In the Basic screen, touch [Duplex/Combine]. Otherwise touch the Original/Density tab. Océ cm3522/cm2522 1-20...
Page 28 In the Duplex/Combine screen, touch [Original Binding Pos.]. Otherwise, touch [Binding Position] in the Original/Density screen. From the Duplex/Combine screen From the Original/Density screen Touch the button for the desired binding margin position, and then touch [OK]. From the Original Binding Position screen Océ cm3522/cm2522 1-21...
Page 29 Before use From the Binding Position screen – To return to the main screen, touch [Main Screen]. Océ cm3522/cm2522 1-22...
Page 30: Using Copy Functions
Using copy functions...
Page 31: General Copy Operation
– For details on selecting a Combine setting, refer to page 2-14. – For details on selecting Finishing settings, refer to page 2-16. – For details on specifying settings to not rotate the image, refer to page 2-22. Océ cm3522/cm2522...
Page 32 Using the keypad, type in the desired number of copies. – If the number of copies was incorrectly entered, press the [C] (clear) key in the keypad, and then specify the correct number of copies. Press the [Start] key. Océ cm3522/cm2522...
Page 33: Selecting A Color Setting
Select this setting to print the copy in black and white, regardless of whether the scanned original is in color or in black and white. Follow the procedure described below to select the Color setting. In the Basic screen, touch [Color]. The Color screen appears. Océ cm3522/cm2522...
Page 34 Select the desired Color setting. – To return to the main screen, touch [Main Screen]. – If the "2 Color" setting was selected, touch the button for the desired color, and then touch [OK]. Touch [OK]. The Basic screen appears again. Océ cm3522/cm2522...
Page 35: Selecting The Paper Settings
If the "Auto Paper Select" was selected at the "Auto Zoom" setting, the Zoom screen appears. Touch the button for the desired zoom ratio. In the Basic screen, touch [Paper]. The Paper screen appears. Océ cm3522/cm2522...
Page 36 Using copy functions Touch [Auto]. – To return to the main screen, touch [Main Screen]. Touch [OK]. The Basic screen appears again. Océ cm3522/cm2522...
Page 37: Manually Selecting The Desired Paper Size
In the Basic screen, touch [Paper]. The Paper screen appears. Select the paper tray loaded with paper of the desired size. – To return to the main screen, touch [Main Screen]. Touch [OK]. The Basic screen appears again. Océ cm3522/cm2522...
Page 38: Specifying A Zoom Setting
The zoom ratio of the "Minimal" setting can be changed (between 90.0% and 99.9%). For details, refer to the User’s Guide [Copy Operations]. The programmed zoom ratios can be changed. For details, refer to the User’s Guide [Copy Operations]. Follow the procedure described below to specify the Zoom setting. Océ cm3522/cm2522...
Page 39: Selecting A Zoom Ratio
– If "Zoom" was selected, use the keypad to type in the desired zoom ratio, and then touch [OK]. – Touch [+] to enlarge the zoom ratio, and touch [-] to reduce the zoom ratio in 0.1% increments. Touch [OK]. The Basic screen appears again. Océ cm3522/cm2522 2-10...
Page 40: Selecting Original And Copy Settings
When the original is scanned from the original glass using the "1 > 2", "2 > 1" or "2 > 2" settings, the scanned pages are stored and printed together. Follow the procedures described below to select original and copy settings. Océ cm3522/cm2522 2-11...
Page 41: Selecting Single-Sided Or Double-Sided Copies
Using copy functions 2.5.1 Selecting single-sided or double-sided copies In the Basic screen, touch [Duplex/Combine]. The Duplex/Combine screen appears. Touch [Original > Copy]. – To return to the main screen, touch [Main Screen]. The Duplex Settings screen appears. Océ cm3522/cm2522 2-12...
Page 42 If the original length is more than 297 mm, a binding position along the short side of the paper is selected. Touch [Close]. The Basic screen appears again. Océ cm3522/cm2522 2-13...
Page 43: Selecting A Combined Copy Setting
Two original images can be combined and printed on a single page, reducing paper use. In the Basic screen, touch [Duplex/Combine]. The Duplex/Combine screen appears. Touch [Combine]. – To return to the main screen, touch [Main Screen]. The Combine screen appears. Océ cm3522/cm2522 2-14...
Page 44 Using copy functions Touch [2in1], and then touch [OK]. Touch [Close]. The Basic screen appears again. Océ cm3522/cm2522 2-15...
Page 45: Selecting Finishing Settings
The "Offset" setting cannot be selected at the same time that a Staple setting is selected. The Staple settings are available only if the optional finisher is installed. The Punch settings are available only if punch kit is installed on optional finisher. Océ cm3522/cm2522 2-16...
Page 46: Selecting The Finishing Method
2.7.1 Selecting the finishing method In the Basic screen, touch [Finishing]. The Finishing screen appears. Select the desired Finishing settings. – To return to the main screen, touch [Main Screen]. Touch [OK]. The Basic screen appears again. Océ cm3522/cm2522 2-17...
Page 47: Selecting Staple/Punch Settings
Using copy functions 2.7.2 Selecting Staple/Punch settings In the Basic screen, touch [Finishing]. Touch [Staple/Punch]. – To return to the main screen, touch [Main Screen]. The Staple/Punch screen appears. Océ cm3522/cm2522 2-18...
Page 48 297 mm. When the "2 Position" Staple setting is selected Touch [OK], and then touch [OK] in the next two screens that appear. Otherwise, touch [Main Screen]. The Basic screen appears again. Océ cm3522/cm2522 2-19...
Page 49: Selecting A Folding Or Binding Setting
Touch [Center Staple/Fold] or [Center Staple & Fold]. When the saddle stitcher is installed on finisher 9356 When finisher 9355 is installed – To return to the main screen, touch [Main Screen]. A screen appears, allowing folding or binding settings to be specified. Océ cm3522/cm2522 2-20...
Page 50 Erase setting. To erase the area along the center, touch [Erase]. To not erase the area along the center, touch [None]. – To cancel the setting, touch [No]. Touch [OK], and then touch [OK] in the next screen that appears. Otherwise, touch [Main Screen]. The Basic screen appears again. Océ cm3522/cm2522 2-21...
Page 51: Selecting Not To Rotate The Image
Depending on the paper size and zoom ratio, some parts of the image may be lost. Follow the procedure described below to select the setting to not rotate the image. Touch [Auto Rotate OFF]. – To cancel the setting for not rotating the image, touch [Auto Rotate OFF] again. Océ cm3522/cm2522 2-22...
Page 52: Selecting The Quality Of The Original
Select this setting for printed photos, such as in books or magazines. Follow the procedure described below to select an Original Type setting. Position the original to be copied. – For details on positioning the original, refer to "Feeding the original" on page 1-11. Océ cm3522/cm2522 2-23...
Page 53 Using copy functions Touch the Original/Density tab. The Original/Density screen appears. Touch [Original Type]. The Original Type screen appears. Touch the button for the quality setting most appropriate for the loaded original. Océ cm3522/cm2522 2-24...
Page 54 Using copy functions – If "Text/Photo" or "Photo" is selected, select the photo type, and then touch [OK]. – To return to the main screen, touch [Main Screen]. Touch [OK]. The Original/Density screen appears again. Océ cm3522/cm2522 2-25...
Page 55: Selecting The Density Settings
Follow the procedures described below to select the density settings. 2.10.1 Adjusting the print density (Density settings) Touch the Original/Density tab. The Original/Density screen appears. Touch [Density]. The Density screen appears. Océ cm3522/cm2522 2-26...
Page 56: 2Adjusting The Background Density (Background Removal Settings)
– To select the center setting (default setting), touch [Standard]. – To return to the main screen, touch [Main Screen]. Touch [OK]. The Original/Density screen appears again. 2.10.2 Adjusting the background density (Background Removal settings) Touch the Original/Density tab. The Original/Density screen appears. Océ cm3522/cm2522 2-27...
Page 57 – To select the third setting from the right (default setting), touch [Standard]. – Touch [Auto] to automatically adjust the level of the background density according to the original being printed. – To return to the main screen, touch [Main Screen]. Touch [OK]. The Original/Density screen appears again. Océ cm3522/cm2522 2-28...
Page 58: Selecting The Paper Settings
Reminder If special paper is loaded into a paper tray, be sure to select the corresponding paper type for that tray, otherwise a paper misfeed may occur. In the Basic screen, touch [Paper]. The Paper screen appears. Océ cm3522/cm2522 2-29...
Page 59 – If a setting for special paper is selected for a paper tray, that tray is not selected automatically with the "Auto" Paper setting. However, if the "Single Side Only" setting is selected for the paper tray, that tray is given priority with single-sided printing. Touch [Paper Type]. Océ cm3522/cm2522 2-30...
Page 60 Touch the button for the desired paper type. – To print on letterheads, colored paper or envelopes, touch [↓] or [↑]. Touch [OK], and then touch [OK] in the next two screens that appear. Otherwise, touch [Main Screen]. The Basic screen appears again. Océ cm3522/cm2522 2-31...
Page 61: 2Printing Double-Sided Copies Manually
A paper tray set to "Duplex 2nd Side" is not selected when the "Auto" Paper setting is selected. In the Basic screen, touch [Paper]. The Paper screen appears. Touch the button for the bypass tray, and then touch [Change Settings]. – To return to the main screen, touch [Main Screen]. Océ cm3522/cm2522 2-32...
Page 62 Touch [Paper Type]. Select the type of paper to be loaded and touch [Duplex 2nd Side]. Touch [OK], and then touch [OK] in the next two screens that appear. Otherwise, touch [Main Screen]. The Basic screen appears again. Océ cm3522/cm2522 2-33...
Page 63: 3Selecting A Paper Size Setting
For example, if A3 wide paper is used, an area up to 311.1 mm × 457.2 mm can be printed, allowing the entire area of an A3-size original to be printed. The following procedure describes how to specify the size of the paper loaded into the bypass tray. Océ cm3522/cm2522 2-34...
Page 64 Touch the button for the bypass tray, and then touch [Change Settings]. – To return to the main screen, touch [Main Screen]. – To change the setting of special paper for any paper tray other than the bypass tray, touch the button for the corresponding paper tray. Océ cm3522/cm2522 2-35...
Page 65 – If a button other than [Auto Detect] was touched, select the desired paper size, and then touch [OK]. Touch [OK], and then touch [OK] in the next two screens that appear. Otherwise, touch [Main Screen]. The Basic screen appears again. Océ cm3522/cm2522 2-36...
Page 66: Scanning The Next Original To Be Copied While A Copy Job Is Being Printed (Next Job Reservation)
Copy Job] in the screen that appears during printing to display the Basic screen. – For details on positioning the original, refer to "Feeding the original" on page 1-11. Press the [Start] key. After the current job is finished, the next copy job begins. Océ cm3522/cm2522 2-37...
Page 67: Pausing Scanning/Printing
To continue all temporarily stopped jobs, press the [Start] key. – To delete a temporarily stopped job, select the job that you wish to delete, and then touch [Delete]. – Select only one job at a time to be deleted. Océ cm3522/cm2522 2-38...
Page 68: Printing A Proof To Check The Settings (Proof Copy)
– If the original was loaded on the original glass, touch [Finish], and then press the [Start] key. A single proof copy is printed. Check the proof copy. – To change the copy settings, press the [C] (clear) key or the [Reset] key, and then change the settings. Océ cm3522/cm2522 2-39...
Page 69 Using copy functions Touch [Print]. The remaining copies are queued as a copy job. Océ cm3522/cm2522 2-40...
Page 70: Using Fax/Scan Functions
Using fax/scan functions...
Page 71: General Fax/Scan Operation
The Fax/Scan mode screen appears in Enlarge Display mode. Position the original to be copied. – For details on positioning the original, refer to page 1-11. Specify the destination. – For details on specifying destinations, refer to page 3-4. Océ cm3522/cm2522...
Page 72 If the "Destination Check Display Function" parameter was set to "ON", the Destination Settings screen appears. Check the destinations, and then touch [Send]. If the machine is set to print the transmission result report, the transmission result report is printed if the transmission could not be completed. Océ cm3522/cm2522...
Page 73: Specifying A Destination
Faxes can be sent on an IP network. Scan data can be sent to transmission the IP address or host name specified for the destination. This operation can only be used through an intranet. Color faxes cannot be sent or received. Océ cm3522/cm2522...
Page 74: Selecting A Destination From The Address Book
Touch the button for the desired destination in the Address Book screen to select a destination. A destination can be searched for by the destination type or the destination name. In the Address Book screen, touch [Other Dest.]. The Other Destinations screen appears. Océ cm3522/cm2522...
Page 75 – To select a destination from registered group, touch [Group]. To select all destinations registered with the selected group, touch [Select All] in the Group Details screen. To cancel all of the selected destinations, touch [Reset]. – To return to the Address Book screen, touch [Main Screen]. Océ cm3522/cm2522...
Page 76: Selecting A Destination From The Job Log
Touch the Job History tab. The Job History list appears. Select the desired destination. – The last five destinations where a transmission was sent are displayed. – To cancel a selection, touch the button for a selected destination again. Océ cm3522/cm2522...
Page 77: Selecting A Destination With An Ldap Search
For details on specifying the setting for the "Manual Destination Input" parameter, refer to the User’s Guide [Network Administrator]. Touch the Address Search tab. – If multiple LDAP servers are specified, select the server to be searched, and then touch [OK]. Océ cm3522/cm2522...
Page 78 – When there is only one LDAP server – When there are multiple LDAP servers – Authentication may be necessary, depending on the LDAP server that is specified. Specify the search conditions, and then touch [Start Search]. For a simple search Océ cm3522/cm2522...
Page 79: Directly Typing In The Number
If "Manual Destination Input" in Administrator mode is set to "Restrict", a fax number cannot be entered. For details on specifying the setting for the "Manual Destination Input" parameter, refer to the User’s Guide [Network Administrator]. Touch [Fax Number]. The Fax Number screen appears. Océ cm3522/cm2522 3-10...
Page 80 This has no effect on the dialing. "–" appears in the screen. – To change a character in the entered text, touch [←] and [→] to move the cursor to the character to be changed, and then touch [Delete]. Océ cm3522/cm2522 3-11...
Page 81 Using fax/scan functions Touch [OK]. – If a destination registration number is entered, touch [OK], and then touch [OK] in the next screen that appears. Océ cm3522/cm2522 3-12...
Page 82: Specifying Scanning Settings (Scan Settings)
Select this setting to scan a double-sided original. Cover + 2-Sided Select this setting to scan an original where the first page is single-sided and the remaining pages are double-sided. Touch [Scan Settings] in the Fax/Scan mode screen. The Scan Settings screen appears. Océ cm3522/cm2522 3-13...
Page 83 Touch [Simplex/Duplex]. – To return to the Address Book screen, touch [Main Screen]. The Simplex/Duplex screen appears. Select the scanning method. Touch [OK], and then touch [OK] in the next screen that appears. Otherwise, touch [Main Screen]. Océ cm3522/cm2522 3-14...
Page 84: Original Type
Photo Paper Select this setting for photos printed on photo paper. Printed Photo Select this setting for printed photos, such as in books or magazines. Touch [Scan Settings] in the Fax/Scan mode screen. The Scan Settings screen appears. Océ cm3522/cm2522 3-15...
Page 85 – To return to the Address Book screen, touch [Main Screen]. The Original Type screen appears. Touch the button for the quality setting most appropriate for the loaded original. – If "Text/Photo" or "Photo" is selected, select the photo type, and then touch [OK]. Océ cm3522/cm2522 3-16...
Page 86: Resolution
400 × 400 (Super Fine) Select this setting when scanning originals with small print or with illustrations. 600 × 600 Select this setting when scanning originals with particularly fine (Ultra Fine) print or with detailed illustrations. Touch [Scan Settings] in the Fax/Scan mode screen. The Scan Settings screen appears. Océ cm3522/cm2522 3-17...
Page 87 – If "600 × 600 (Ultra Fine)" or "400 × 400 (Super Fine)" is selected, the fax is sent with a resolution appropriate for the recipient’s machine if it cannot receive a fax with the specified resolution. Touch [OK], and then touch [OK] in the next screen that appears. Otherwise, touch [Main Screen]. Océ cm3522/cm2522 3-18...
Page 88: Density
The density can be adjusted to one of nine levels. Touch [Scan Settings] in the Fax/Scan mode screen. The Scan Settings screen appears. Touch [Density]. – To return to the Address Book screen, touch [Main Screen]. The Density screen appears. Océ cm3522/cm2522 3-19...
Page 89: File Type
Some format settings for the file to be saved may not be available, depending on the selected Color setting and fax destination. Note For fax transmissions and Internet fax transmissions, the file type is fixed to the TIFF format. Océ cm3522/cm2522 3-20...
Page 90 Touch [Scan Settings] in the Fax/Scan mode screen. The Scan Settings screen appears. Touch [File Type]. – To return to the Address Book screen, touch [Main Screen]. The File Type screen appears. Select the file format and the page setting. Océ cm3522/cm2522 3-21...
Page 91: Color (Image Adjust)
Some Color settings may not be available, depending on the selected File Type setting. Note For fax transmissions and Internet fax transmissions, the color is fixed to 2 color of black and white. Touch [Scan Settings] in the Fax/Scan mode screen. Océ cm3522/cm2522 3-22...
Page 92 Touch [Image Adjust]. – To return to the Address Book screen, touch [Main Screen]. The Image Adjust screen appears. Select the color type. Touch [OK], and then touch [OK] in the next screen that appears. Otherwise, touch [Main Screen]. Océ cm3522/cm2522 3-23...
Page 93: Background Removal (Image Adjust)
In that case, the density of the background can be adjusted. Touch [Scan Settings] in the Fax/Scan mode screen. The Scan Settings screen appears. Touch [Image Adjust]. – To return to the Address Book screen, touch [Main Screen]. The Image Adjust screen appears. Océ cm3522/cm2522 3-24...
Page 94 – To select the third setting from the right (default setting), touch [Standard]. – Touch [Auto] to automatically adjust the level of the background density according to the original being copied. Touch [OK], and then touch [OK] in the next two screens that appear. Otherwise, touch [Main Screen]. Océ cm3522/cm2522 3-25...
Page 95: Scan Size
Select a preset paper size and orientation in a size other than metric or inch sizes. Touch [Scan Settings] in the Fax/Scan mode screen. The Scan Settings screen appears. Touch [Scan Size]. – To return to the Address Book screen, touch [Main Screen]. The Scan Size screen appears. Océ cm3522/cm2522 3-26...
Page 96: Original Settings
Auto: The binding margin is on the long side if the page is 297 mm or less, or it is on the short side if the page is more than 297 These functions can be used together. Océ cm3522/cm2522 3-27...
Page 97 [Original Direction] is not available with fax function. Touch [Scan Settings] in the Fax/Scan mode screen. The Scan Settings screen appears. Touch [Original Settings]. – To return to the Address Book screen, touch [Main Screen]. The Original Settings screen appears. Océ cm3522/cm2522 3-28...
Page 98 – Touching [Binding Position] displays the Binding Position screen. Touch the button for the desired original binding position, and then touch [OK]. Touch [Close], and then touch [OK] in the next screen that appears. Otherwise, touch [Main Screen]. Océ cm3522/cm2522 3-29...
Page 99: Using A Program
– Touch [Page List] to select the page of programs to be displayed. – Touch [←Previous Page] or [Next Page→] to display the previous or next page of programs. – To scroll through the page, touch [↑] or [↓]. Océ cm3522/cm2522 3-30...
Page 100 – To cancel the setting, touch the button again to deselect it. – Only one program can be selected. Touch [OK] or [Main Screen]. – To specify multiple destinations, add a destination. For details, refer to "Specifying a destination" on page 3-4. Océ cm3522/cm2522 3-31...
Page 101: Checking The Destinations
In the Fax/Scan mode screen, touch [Dest. Settings]. The Destination Settings screen appears, and the specified destinations can be checked. Select the desired destination from the list of destinations. – To return to the Address Book screen, touch [Main Screen]. Océ cm3522/cm2522 3-32...
Page 102 Using fax/scan functions Touch [Details], and then check the destination details. – To delete a destination, select a destination, and then touch [Delete] to display a message requesting confirmation to delete the destination. Touch [Close]. Océ cm3522/cm2522 3-33...
Page 103 Using fax/scan functions Océ cm3522/cm2522 3-34...
Page 104: Logging On And Logging Off
Logging on and logging off...
Page 105: When A Logon Screen Appears
(biometric type) to display the Basic screen. For details on performing authentication using the authentication unit (biometric type) and registering information, refer to the User’s Guide [Copy Operations] or the manual included with the authentication unit (biometric type). Océ cm3522/cm2522...
Page 106 [Delete], and then type in the desired letter or number. – To clear all entered text, press the [C] (clear) key. – To revert to the previously entered text, touch [Undo]. Océ cm3522/cm2522...
Page 107 However, if "Synchronize User Authentication & Account Track" in Administrator mode has been set to "Synchronize", the account track screen does not appear if the users and accounts are synchronized. The Basic screen appears. Océ cm3522/cm2522...
Page 108: When The Screen To Enter The Account Name And Password Appears
For an account name and password, contact the machine’s administrator. Detail If "Account Track Input Method" in Administrator mode was set to "Password Only", log on is possible by only entering the password. For details, refer to the User’s Guide [Copy Operations]. Océ cm3522/cm2522...
Page 109 [Delete], and then type in the desired letter or number. – To clear all entered text, press the [C] (clear) key. – To revert to the previously entered text, touch [Undo]. Océ cm3522/cm2522...
Page 110 Using the control panel keypad or the keyboard that appears in the touch panel, type in the password, and then touch [OK]. – To return to the main screen without changing the settings, touch [Cancel]. Touch [Login] or press the [Access] key. The Basic screen appears. Océ cm3522/cm2522...
Page 111 When you are finished performing the desired operations, press the [Access] key. A message appears, requesting confirmation to log off. Touch [Yes], and then touch [OK]. – The original screen appears again. The screen that appears differs depending on the Administrator mode settings that have been specified. Océ cm3522/cm2522...
Page 112 Beyond the Ordinary Printing for Professionals Océ North America Document Printing Systems 100 Oakview Drive Trumbull, CT 06611 Copyright 2008, Océ Imagistics Inc. www.oce.com All Rights Reserved...
