USER’'S MANUAL
Advertisement
Table of Contents
Related Manuals for Epic Fitness A30t Treadmill
Summary of Contents for Epic Fitness A30t Treadmill
- Page 1 www.epicfit.com Model No. EPTL99112.2 USER’’S MANUAL Serial No. Write the serial number in the space above for reference. Serial Number Decal ACTIVATE YOUR WARRANTY To register your product and activate your warranty today, go to www.epicfit.com/registration. CUSTOMER CARE VISIT OUR WEBSITE: www.epicfit.com Chat: Mon.––Fri.
-
Page 2: Table Of Contents
TABLE OF CONTENTS WARNING DECAL PLACEMENT ............. . . 2 IMPORTANT PRECAUTIONS . -
Page 3: Important Precautions
IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read all important precautions and instructions in this manual and all warnings on your treadmill before using your treadmill. ICON assumes no responsibility for personal injury or property damage sus- tained by or through the use of this product. - Page 4 20. The heart rate monitor is not a medical 24. Never insert any object into any opening on device. Various factors, including the user’’s the treadmill. movement, may affect the accuracy of heart rate readings. The heart rate monitor is 25.
-
Page 6: Before You Begin
Thank you for selecting the revolutionary EPIC™™ reading this manual, please see the front cover of this A30T treadmill. The A30T treadmill offers an impres- manual. To help us assist you, please note the product sive selection of features designed to make your model number and serial number before contacting us. -
Page 7: Part Identification Chart
PART IDENTIFICATION CHART Use the drawings below to identify small parts used for assembly. The number in parentheses below each draw- ing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity used for assembly. -
Page 8: Assembly
ASSEMBLY •• To watch an assembly there is an oily substance on the treadmill, wipe video, go to it off with a soft cloth and a mild, non-abrasive http://productvideo.co/ cleaner. assembly/dsg/epic or use your mobile phone •• Left parts are marked ““L”” or ““Left”” and right parts or smartphone to read are marked ““R””... - Page 9 3. Identify the Left Upright Cover (100) and the Right Upright Cover (98). Slide the Left Upright Cover (100) onto the left side of the Upright (96). Press the Left Upright Cover onto the lower part of the Upright and the left leg extension assembly (B) until it snaps into place.
- Page 10 5. With the help of a second person, hold the con- sole assembly (E) near the Upright (96). Connect the Upright Wire (92) to the console wire. See the inset drawing. The connectors should slide together easily and snap into place.
- Page 11 7. Identify the Left and Right Trays (107, 109). Press the Left and Right Trays (107, 109) into the console assembly (E). 8. Raise the Frame (61) to the position shown. Have a second person hold the Frame until this step is completed. Remove the 3/8"...
-
Page 12: Operation And Adjustment
OPERATION AND ADJUSTMENT HOW TO CONNECT THE POWER CORD nominal 120-volt circuit capable of carrying 15 or more amps. To avoid overloading the circuit, do Use a Surge Suppressor not plug other electrical devices, except for low- power devices such as cell phone chargers, into Your treadmill, like other electronic equipment, can be the surge suppressor or into an outlet on the same damaged by sudden voltage changes in your home’’s... - Page 13 CONSOLE DIAGRAM MP3 Jack FEATURES OF THE CONSOLE When you use the manual mode, you can change the speed and incline of the treadmill with the touch of a The treadmill console offers an impressive array of button. features designed to make your workouts more effec- tive and enjoyable.
- Page 14 HOW TO TURN ON THE POWER HOW TO SET UP THE CONSOLE IMPORTANT: If the treadmill has been exposed to Before using the treadmill for the first time, set up the cold temperatures, allow it to warm to room tem- console.
- Page 15 HOW TO USE THE MANUAL MODE numbered Quick Incline buttons. Each time you press one of the buttons, the treadmill will gradually 1. Insert the key into the console. adjust to the selected incline setting. See HOW TO TURN ON THE POWER on page 14. 5.
- Page 16 As you exercise, the workout 6. Measure your heart rate if desired. intensity level bar will indicate the approximate intensity level Before using of your exercise. the heart rate monitor, remove the The display will also show a track that represents sheets of plas- 1/4 mile (400 m).
- Page 17 HOW TO USE AN ONBOARD WORKOUT The workout will continue in this way until the last segment of the pro le ashes in the display and the 1. Insert the key into the console. last segment ends. The walking belt will then slow to a stop.
- Page 18 HOW TO USE A SET-A-GOAL WORKOUT HOW TO CREATE A USER-DEFINED WORKOUT 1. Insert the key into the console. 1. Insert the key into the console. See HOW TO TURN ON THE POWER on page 14. See HOW TO TURN ON THE POWER on page 14. 2.
- Page 19 HOW TO USE A USER-DEFINED WORKOUT To stop the workout at any time, press the Stop button. The time will begin to flash in the display. 1. Insert the key into the console. To resume the workout, press the Start button or the Speed increase button.
- Page 20 HOW TO USE AN IFIT WORKOUT If you select a competition workout, the display may count down to the beginning of the race. Note: To use an iFit workout, you must have access to a wireless network (see page 21). An iFit account is 5.
- Page 21 HOW TO CHANGE CONSOLE SETTINGS Units——The selected unit of measurement will appear in the matrix. To change the unit of mea- The console features a settings mode that allows you surement, press the Enter button. To view distance to view usage information, to personalize console set- in miles, select ENGLISH.
- Page 22 iFit User Setup——To set up a different iFit account, Press the up, down, left, and right buttons to high- but maintain the existing wireless connection, light the desired letter or number. Then, press the follow the instructions in the matrix. Note: This Enter button to select the letter, number, or symbol.
- Page 23 6. Use WiFi––Advanced to set up a wireless HOW TO USE THE STEREO SOUND SYSTEM connection. To play music or audio books through the console’’s This option will allow you to set up a wireless stereo speakers, you must connect your MP3 player, network connection using your computer, smart CD player, or other personal audio player to the con- phone, tablet, or other Wi-Fi device.
-
Page 24: How To Fold And Move The Treadmill
HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL HOW TO MOVE THE TREADMILL To avoid damaging the treadmill, adjust the incline Before moving the treadmill, fold it as described at the to the lowest position before you fold the treadmill. left. -
Page 25: Troubleshooting
TROUBLESHOOTING Most treadmill problems can be solved by follow- c. Remove the key from the console, and then ing the simple steps below. Find the symptom that reinsert it. applies, and follow the steps listed. If further assis- tance is needed, see the front cover of this manual. d. - Page 26 Lower the treadmill (see HOW TO LOWER THE will automatically rise to the maximum incline level TREADMILL FOR USE on page 24). Remove the and then return to the minimum level. This will ve #8 x 3/4" Screws (10). Carefully raise the ends recalibrate the incline system.
-
Page 27: Maintenance
SYMPTOM: The walking belt is off-center or slips b. If the walking belt slips when walked on, first when walked on remove the key and UNPLUG THE POWER CORD. Using the hex key, turn both idler roller a. If the walking belt is off-center, first remove the screws clockwise, 1/4 of a turn. -
Page 28: Exercise Guidelines
EXERCISE GUIDELINES Burning Fat——To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy. -
Page 29: Part List
PART LIST Model No. EPTL99112.2 R0113A Key No. Qty. Description Key No. Qty. Description 5/16" x 3/4" Screw Idler Roller 3/8" x 3 1/4" Screw Warning Decal 3/8" Star Washer Walking Platform 3/8" External Star Washer Walking Belt 3/8" x 2" Bolt Belt Guide 5/16"... - Page 30 Key No. Qty. Description Key No. Qty. Description Base Pad Console Clamp Rear Sensor Wire Console Bushing Base Leg Console Ground Wire Left Wheel Housing Console Base Back Right Wheel Housing Console Wheel Console Frame Left Tray Access Door Console Base Console Back Right Tray Bottom Adjustment Tube...
-
Page 31: Exploded Drawing
EXPLODED DRAWING A Model No. EPTL99112.2 R0113A... - Page 32 EXPLODED DRAWING B Model No. EPTL99112.2 R0113A...
- Page 33 EXPLODED DRAWING C Model No. EPTL99112.2 R0113A...
- Page 34 EXPLODED DRAWING D Model No. EPTL99112.2 R0113A...
- Page 35 EXPLODED DRAWING E Model No. EPTL99112.2 R0113A...
-
Page 36: Ordering Replacement Parts
ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to pro- vide the following information when contacting us: •• the model number and serial number of the product (see the front cover of this manual) ••...
