Page 13: Introduction
Introduction Introduction We Want You to Be a Satisfied Customer Thank you for choosing a Konica Minolta Copier System. To ensure the best performance and effective use of your copier, this manual will provide information on the following topics: Getting to Know Your Copier Initial Steps .
Page 14: Explanation Of Manual Conventions
Text formatted in this style provides additional assistance. § Text formatted in this style describes the action that will ensure the desired results are achieved. [Copy] key The names of keys on the control panel are written as shown above. Di2510/Di3010/Di3510...
Page 15: Explanation Of Basic Concepts And Symbols
“Width” and “Length” Whenever paper dimensions are mentioned in this manual, the first value always refers to the width of the paper (shown as “Y” in the illustration) and the second to the length (shown as “X”). Di2510/Di3010/Di3510...
Page 16: Paper Orientation
(X), the paper has a horizontal or landscape orientation, indicated by either “C” or Portrait and Landscape Portrait With the “portrait” orientation, the paper is vertical, like a portrait. Landscape With the “landscape” orientation, the paper is horizontal, like a landscape. Di2510/Di3010/Di3510...
Page 17: Display Icons
Introduction Display Icons Plain paper Thick paper Overhead projector transparencies Envelope Paper Supply Icons The icons shown below may appear, indicating that no more paper remains. The paper is empty. Di2510/Di3010/Di3510...
Page 18: Energy Star
“low-power mode” after a period of inactivity. An ® ENERGY STAR product uses energy more efficiently, saves you money on utility bills and helps protect the environment. Di2510/Di3010/Di3510...
Page 19: Components And Their Functions
Referred to as the “duplex unit” throughout the manual. When using the duplex unit, the switchback unit is required. Switchback Unit SB-1 When copying to both sides of a page, this turns over the paper. Required when using the duplex unit. Di2510/Di3010/Di3510...
Page 20 If this option is attached to the finisher, the printed pages (optional) can be divided and fed into the appropriate bin assigned to a specific individual or group. • This option can only be used with computer printouts. Referred to as the “mail bin kit” throughout the manual. Di2510/Di3010/Di3510...
Page 21 When this copier is used as a printer, printing can be performed through a parallel connection (IEEE1284). • When the Parallel Interface Kit is installed, the optional Printer Controller Pi3505e or Pi3505e/PS and the Network Interface Card NC-4 are necessary. * The internal options are not shown. Di2510/Di3010/Di3510...
Page 22 Introduction How to use the Job Separator (JS-203)? Allows printed pages to be separated Pull the lever when taking out the paper. 1-10 Di2510/Di3010/Di3510...
Page 23: Part Names And Their Functions
Prevents printed pages from falling out of the paper output tray Used when the optional sorter is installed. Touch panel Liquid crystal display in the control panel. Used to specify various copy settings and program or change functions. Di2510/Di3010/Di3510 1-11...
Page 24 Holds up to 500 sheets of paper. The paper size can be adjusted freely, see page 9-8 Control panel Used to start copying or to specify various settings Document scales Used to align the document * The internal unit is not shown. 1-12 Di2510/Di3010/Di3510...
Page 25 Part Name Description Duplexing Document Used for connecting the duplexing document feeder Feeder connector hookup cord. Power switch Used to turn the copier on and off, see page 4-12 Power cord socket Used for connecting the printer’s power cord. Di2510/Di3010/Di3510 1-13...
Page 26: Options
Each drawer can hold up to 500 sheets of paper. The paper size can be adjusted freely. 4th paper drawer * PF-210: Equipped with a paper drawer that can supply 500 sheets of paper, for upper paper feed unit only. 1-14 Di2510/Di3010/Di3510...
Page 27 Opened when clearing paper misfeeds. Precautions for using the finisher, saddle kit and mail bin kit Do not place objects on top of the saddle kit or mail bin kit. Do not place objects under the paper output trays of the finisher. Di2510/Di3010/Di3510 1-15...
Page 28 Additional Bin Kit (AK-1) Part Name Description 3rd paper output tray Collects printed pages. Saddle Kit (SK-1) Part Name Description Paper output tray Collects printed pages. Misfeed-clearing door Opened when clearing paper misfeeds that occurred in the finisher. 1-16 Di2510/Di3010/Di3510...
Page 29: Safety Information
This symbol warns against cause burns. A diagonal line indicates a prohibited course of action. This symbol warns against dismantling the device. A black circle indicates an imperative course of action. This symbol indicates you must unplug the device. Di2510/Di3010/Di3510...
Page 30: Warning
If you keep on using it as is, a fire or electrical shock could result. Do not throw the toner cartridge or toner into an open flame. The hot toner may scatter and cause burns or other damage. Di2510/Di3010/Di3510...
Page 31: Caution
Dust that accumulates between the plug terminals may cause a fire. • When unplugging the power cord, be sure to hold onto the plug. Pulling on the power cord could damage the cord, resulting in a fire or electrical shock. Di2510/Di3010/Di3510...
Page 32: Precautions For Routine Use
Do not touch or scratch the surface of the toner unit developing roller and the PC drum, as poor image quality could result. Use the supplies and consumables recommended by the dealer. Use of any supply or consumable not recommended could result in poor image quality and breakdown. Di2510/Di3010/Di3510...
Page 33: User Instructions
This equipment should not be used under any circumstances which may constitute a nuisance to other Telecom customers. Not all telephones will respond to incoming ringing when connected to the extension socket. Di2510/Di3010/Di3510...
Page 34: Laser Safety
Therefore, the print head unit should not be opened under any circumstances. Print Head Laser Aperture of the Print Head Unit There is a laser aperture at the location shown above, which must, however, NEVER be viewed directly by the user. Di2510/Di3010/Di3510...
Page 35: Cdrh Regulation
ADVARSEL Usynlig laserstråling ved åbning, når sikkerhedsafbrydere er ude af funktion. Undgå udsættelse for stråling. Klasse 1 laser produkt der opfylder IEC60825 sikkerheds kravene. Dansk: Dette er en halvlederlaser. Laserdiodens højeste styrke er 5mW og bølgelængden er 770-795 nm. Di2510/Di3010/Di3510...
Page 36: For Finland, Sweden Users
Dersom apparatet brukes på annen måte enn spesifisert i denne bruksanvisning, kan brukeren utsettes for unsynlig laserstråling som overskrider grensen for laser klass 1. Dette en halvleder laser. Maksimal effekt till laserdiode er 5mW og bølgelengde er 770-795 nm. Di2510/Di3010/Di3510...
Page 37: Laser Safety Label
Acoustic Noise For European Users Machine Noise Regulation 3 GSGV, 18.01.1991: The sound pressure level at the operator position according to EN 27779 is equal to or less than 70dB(A). Di2510/Di3010/Di3510...
Page 38: Installation Precautions
A location that is not near any kind of heating devices Power Source The power source requirements are as follows. Voltage fluctuation: Maximum ±10% Frequency fluctuation: Maximum ±0.3 Hz Use a power source with as little voltage or frequency fluctuations as possible. 2-10 Di2510/Di3010/Di3510...
Page 39: Space Requirements
1757 (69-1/4) 1312 (51-3/4) 710 (28) (4-3/4) (12-3/4) (13) (16-1/2) (24-1/4) Unit: mm (inch) Note Be sure to allow a clearance of 100 mm (4 in.) or more at the back of the copier for the ventilation duct. Di2510/Di3010/Di3510 2-11...
Page 40: Operation Precautions
CAUTION If the ventilation duct at the top of the copier becomes blocked, the inside of the copier will accumulate heat, resulting in a malfunction or fire. § Do not place any objects over the ventilation duct. 2-12 Di2510/Di3010/Di3510...
Page 41 Be especially careful not to touch parts marked with warning labels, and their surrounding areas. § If you get burnt, immediately cool the skin under cold water, and then seek professional medical advice. Di2510/Di3010/Di3510 2-13...
Page 42: Transporting The Copier
Copies that are to be kept for a long time should be kept where they are not exposed to light in order to prevent them from fading. Adhesive that contains solvent (e.g., spray glue) may dissolve the toner on copies. 2-14 Di2510/Di3010/Di3510...
Page 43: Legal Restrictions On Copying
Copyrighted works without permission of the copyright owner In addition, it is prohibited under any circumstances to copy domestic or foreign currencies, or works of art without permission of the copyright owner. When in doubt about the nature of a document, consult with legal counsel. Di2510/Di3010/Di3510 2-15...
Page 44 Safety Information 2-16 Di2510/Di3010/Di3510...
Page 45: Available Features
(one page per side) in the original page order. Original Document Copy Position the document on the original glass with the center aligned with the book mark on the document scale. Start copying from the lower numbered pages. Touch [Orig. > Copy], and then touch [Book]. Di2510/Di3010/Di3510...
Page 46 Available Features For book-binding, touch [Standard Book] or [RightBound], and then touch [Separation]. Next, touch [Enter]. Touch [Double-Sided], and then touch [Page Order]. Touch [Book Order], and then touch [Enter]. Press the [Start] key. Di2510/Di3010/Di3510...
Page 47 [Start] key. Repeat step 7, and when the last page has been scanned, touch [Finish]. Next, press the [Start] key. Di2510/Di3010/Di3510...
Page 48: Copying To Form A Booklet
In order to perform the following procedure, the optional duplexing document feeder must be installed. Load the document into the duplexing document feeder. The document can also be positioned on the original glass. Touch [Orig. > Copy], and then touch [4in1/Booklet]. Di2510/Di3010/Di3510...
Page 49 Press the [Start] key. After all copies are printed, fold the pages in half to form a booklet. If the optional saddle kit is installed, creasing or folding can be set. For details, refer to “Creasing and Folding” on page 11-9. Di2510/Di3010/Di3510...
Page 50: Automatically Stapling Pages While Copying
Original Document Copy Note In order to perform the following procedure, the optional duplexing document feeder, finisher must be installed. Load the document into the duplexing document feeder. The document can also be positioned on the original glass. Touch [Finishing]. Di2510/Di3010/Di3510...
Page 51 Available Features Touch [Sort]. Touch [2-Point Staple]. Press the [Start] key. Di2510/Di3010/Di3510...
Page 52: Printing Multiple Copies Of Tickets
If the document is placed directly on the original glass and the size is detected automatically, the document will be scanned with a standard size. If the document has a non-standard size, first measure the size of the document. Position the document to be copied. Di2510/Di3010/Di3510...
Page 53 Touch the button for the multiple bypass tray, and then touch [Mode Change]. Touch [Card], and then touch [Enter]. If paper with a non-standard size is loaded, touch [Custom Size], and then specify the paper size. (For details, refer to page 9-14.) Di2510/Di3010/Di3510...
Page 54 Available Features Touch [Zoom]. Touch [× 0.5]. Touch [Auxiliary], and then touch [Image Repeat]. Touch [Size Input]. 3-10 Di2510/Di3010/Di3510...
Page 55 Pad, type in the length of side Y for the document. For this example, set the length of side Y to “74”. Press the [Start] key. Sixteen 105 mm × 37 mm tickets are copied onto one sheet of paper. Di2510/Di3010/Di3510 3-11...
Page 56: Copying While Erasing An Area Around The Document
The width of the erased area refers to how much of the document will be erased. If enlarged or reduced copies are made, the same width is erased and an enlarged or reduced copy is printed. Position the document to be copied. 3-12 Di2510/Di3010/Di3510...
Page 57 Available Features Touch [Auxiliary], and then touch [Edge/Frame Erase]. Select the desired position of the erased area. (Example: Erasing a frame) Touch the big arrow keys to specify the width of the erased area. Touch [Enter]. Di2510/Di3010/Di3510 3-13...
Page 58 Available Features Press the [Start] key. 3-14 Di2510/Di3010/Di3510...
Page 59: Reducing Paper Usage
Double-sided 2in1 copying and single-sided 4in1 copying reduce the paper usage by one fourth, and double-sided 4in1 copying reduces paper usage by one eighth. Load the document into the duplexing document feeder. The document can also be positioned on the original glass. Di2510/Di3010/Di3510 3-15...
Page 60 Available Features Touch [Orig. > Copy], and then touch [4in1/Booklet]. Touch [Double-2in1]. Press the [Start] key. 3-16 Di2510/Di3010/Di3510...
Page 61: Reducing Electricity Usage
Press the [Utility] key. Touch [User’s Choice]. Touch [3/6]. To specify settings for the Energy Save mode, continue with step 4. To specify settings for the Sleep mode, skip to step 7. Touch [Energy Save Mode]. Di2510/Di3010/Di3510 3-17...
Page 62 Key Pad to specify the desired length of time until the copier enters Energy Save mode. Touch [Enter]. Touch [Sleep Mode Setting]. Use the 10-Key Pad to specify the desired length of time until the copier enters Sleep mode. 3-18 Di2510/Di3010/Di3510...
Page 63 Available Features Touch [Enter]. Di2510/Di3010/Di3510 3-19...
Page 64 Available Features 3-20 Di2510/Di3010/Di3510...
Page 65: Before Making Copies
[C] (clear) key • Press to reset the number of copies to “1”. • Press to erase a setting (such as the zoom ratio or size) selected using the 10-Key Pad..continued on next page Di2510/Di3010/Di3510...
Page 66 [Accessibility] key Press to activate or deactivate the user accessibility functions. [Enlarge Display] key Press to enlarge the screens that appear in the touch panel. [Contrast] dial Use to adjust the contrast of the touch panel. Di2510/Di3010/Di3510...
Page 67: Checking The Settings
Touch [Exit] to return to the Basics screen. To change a setting, touch the button for the function that you wish to change. The screen to change the setting for the selected function appears. In the screen that appeared, change the setting as desired. Di2510/Di3010/Di3510...
Page 68: To Change The Settings
To change the screens, touch [Next] and [Back]. Touch the button for the setting that you wish to change. The screen for specifying the setting appears. Change the setting according to the corresponding procedure. Di2510/Di3010/Di3510...
Page 69: User Accessibility Operations
Touch either [Set] or [Reset]. The user accessibility functions can be enabled or disabled. When the user accessibility functions are enabled, the [Accessibility] key lights up in green. When the user accessibility functions are disabled, the [Accessibility] key is not lit. Di2510/Di3010/Di3510...
Page 70: To Change The Screen Display Setting ("Screen Mode" Function)
Press the [Accessibility] key in the control panel. Touch [Screen Mode]. Touch [Inverted Screen] to display the screens in white on black. To return the screens to the normal display, touch [Normal Screen]. Touch [Enter]. Inverted screen Normal screen Di2510/Di3010/Di3510...
Page 71: To Change The Key Settings ("Key Speed Settings" Function)
Length of time (in seconds) that a key must be held down before repeatedly entering characters and numbers Example: When the [1] key is held down: Interval Time Delay Touch [CHECK] to check the Time specified settings. Touch [Enter]. Di2510/Di3010/Di3510...
Page 72: To Change The Auto Panel Reset Time ("Confirming Screen" Function)
Touch [30 sec.], [60 sec.], [90 sec.] or [120 sec.]. To immediately display the Basics screen without displaying a screen requesting confirmation to reset the copier, touch [None]. Touch [Enter]. Di2510/Di3010/Di3510...
Page 73: To Change The Display Time For The "The Job Is Accepted." Screen ("Notification Screen" Function)
Press the [Accessibility] key in the control panel. Touch [Notification Screen]. Select the desired time setting. Touch [3 sec.], [10 sec.] or [60 sec.]. To leave the “The job is accepted.” screen displayed until [Enter] is touched, touch [No Limit]. Touch [Enter]. Di2510/Di3010/Di3510...
Page 74: To Change The Volume Of Touch Panel Beeps And Alarms ("Sound Setting" Function)
Basic volume setting can be set in User Management. For details, refer to “To adjust beep volumes (“Confirmation Beep” and “Alarm Volume” functions)” on page 7-37. Press the [Accessibility] key in the control panel. Touch [Sound Setting]. Select the desired volume setting. Touch [Enter]. 4-10 Di2510/Di3010/Di3510...
Page 75: Enlarging The Touch Panel Screens
Touch in this area to Touch this arrow to scroll down through the Touch in this area to scroll toward the screen scroll toward the lower-left corner of lower-right corner of the screen. the screen. Di2510/Di3010/Di3510 4-11...
Page 76: Turning The Copier On And Off
[Start] lights up in green. When the indicator on the [Start] key lights up in green, a job can be queued. When the power switch is on, and the sub power switch is in the off position, copies can not be taken. 4-12 Di2510/Di3010/Di3510...
Page 77: To Turn Off The Copier
Settings that have not been programmed will be cleared. Jobs that are queued to be printed are deleted. Data scanned using the “Scan to Memory” function is deleted. Scanned data that could be printed using the “Memory Recall” function is deleted. Di2510/Di3010/Di3510 4-13...
Page 78: Auto Panel Reset
The copier will not enter Energy Save Mode while printing is paused. The settings specifying whether or not and the time until the copier enters Energy Save mode can be changed. For details, refer to “Changing Default Settings” on page 7-6. 4-14 Di2510/Di3010/Di3510...
Page 79: Sleep Mode
To recover from Sleep mode, press any key in the control panel or touch the touch panel. The settings specifying whether or not and the time until the copier enters Sleep mode can be changed. For details, refer to “Changing Default Settings” on page 7-6. Di2510/Di3010/Di3510 4-15...
Page 80: Adjusting The Angle Of The Control Panel
The control panel can be adjusted to any of three angles. Adjust the control panel to the angle that allows for easy operation. § Pull the control panel release lever, and then adjust the angle of the control panel. Upper position (base position) Middle position Lower position 4-16 Di2510/Di3010/Di3510...
Page 81: Using The Touch Panel
To change the default settings, refer to “Changing Default Settings” on page 7-6. Number of copies: 1 Finishing: Non-Sort Zoom: 1.000 (Full Size) Paper: AutoPaper Density: Auto Exposure (Text/Photo mode) Orig. Ö Copy: Single-Sided Ö Single-Sided Di2510/Di3010/Di3510 4-17...
Page 82: Operating The Touch Panel
“Language Selected for LCD” function on the User’s Choice screen. For details, refer to “Changing Default Settings” on page 7-6. The default settings can be changed using the various functions on the User’s Choice screen. For details, “Changing Default Settings” on page 7-6. 4-18 Di2510/Di3010/Di3510...
Page 83: Description Of The Screens
The current settings are shown with graphics. Additional message • The status of the job is shown with graphics. display • The remaining amount of memory and graphics warning about empty toner or an empty paper drawer are displayed here. Di2510/Di3010/Di3510 4-19...
Page 84: Job List Screen
Displays a list of operations that are being performed Print Order: Displays the order of documents that are being copied or printed or waiting to be copied or printed Print: Displays the print status of documents being copied or printed Com.: Not used Doc.: Not used 4-20 Di2510/Di3010/Di3510...
Page 85: To Check The Status Of A Job
The statuses of up to four jobs are displayed. Touch the arrow keys to view the status of a job that is not displayed. Check the details, and then touch [Enter]. To delete the currently selected job, select that job and touch [Delete]. Di2510/Di3010/Di3510 4-21...
Page 86: To Check The Printing Order
Touch [Job List]. Touch [Print Order]. Check the printing order. Touch the arrow keys to view other parts of the list. Up to 8 items in the printing order can be displayed. After checking the necessary information, touch [Enter]. 4-22 Di2510/Di3010/Di3510...
Page 87: To Check/Delete Listed Items From The Print Screen
Select the job whose status you wish to check. Touch the arrow keys to view other parts of the list. After checking the necessary information, touch [Enter]. Note To delete the job, select that job and touch [Delete]. Di2510/Di3010/Di3510 4-23...
Page 88: Memory Recall
The memory recall feature cannot be used if any of the following have occurred: A new document has been scanned. (The [Start] key has been pressed.) The copier has been turned off. The [Panel Reset] key was pressed while printing was stopped. 4-24 Di2510/Di3010/Di3510...
Page 89: To Use The Memory Recall Feature
[Delete]. At this time, the Finishing setting and the number of copies can be changed. Press the [Start] key. The copies are printed. After copying confidential documents, press the [Delete] key to erase the data from the memory. Di2510/Di3010/Di3510 4-25...
Page 90 Before Making Copies 4-26 Di2510/Di3010/Di3510...
Page 91: Basic Copy Operations
To copy a book or copy while using less paper, touch [Orig. > Copy]. For details, refer to “Selecting the Orig. > Copy Settings” (page 11-18). To change the density of the copy, touch [Density]. For details, refer to “Selecting a Copy Density” (page 11-31). Di2510/Di3010/Di3510...
Page 92 [C] key, and then enter the correct setting. A limit on the number of copies can be specified from the Administrator Management screen of the Utility mode. For details, refer to chapter “8 Administrator Management Operations”. Press the [Start] key. The copies are printed. Di2510/Di3010/Di3510...
Page 93: Stopping Copying
The message “Copy cycle temporarily suspended.” appears. To restart a job that has been stopped, press the [Start] key. Copying continues. To delete the stopped copy job, select the button for the job that you wish to delete. The job is deleted. Di2510/Di3010/Di3510...
Page 94: Interrupting A Copy Job
When the interrupt mode copy has completed, press the [Interrupt] key. The indicator on the [Interrupt] key goes off and the Interrupt mode is cancelled. The copy settings for the job before copying was interrupted appear, and copying of the job that was interrupted automatically continues. Di2510/Di3010/Di3510...
Page 95: Making Copies Using Accounts
If [100 Account 1] has been specified, the screen shown at right is displayed. If [100 Account 2] has been specified, pressing the [Access] key will display the screen shown at right. Enter the 6-digit access code using the 10-Key Pad. Di2510/Di3010/Di3510...
Page 96 Screen, and press the [Access] key. The Basics screen is displayed. Copying will take place using the desired copy mode. When copying has finished, press the [Access] key again. The Settings Screen is displayed on the Account Number Input Screen. Di2510/Di3010/Di3510...
Page 97: Auxiliary Functions
Load paper for the cover pages with the same orientation and size as the paper for the document. The optional duplexing document feeder must be installed. Cover Mode settings Front Cover: Blank Back Cover: None Original Document Copy Front Cover: Blank Back Cover: Blank Di2510/Di3010/Di3510...
Page 98 Auxiliary Functions Front Cover: Blank Back Cover: With Image Front Cover: With Image Back Cover: None Front Cover: With Image Back Cover: Blank Front Cover: With Image Back Cover: With Image Di2510/Di3010/Di3510...
Page 99: To Make Settings For The "Cover Mode" Function
“Cover Paper”. Select the paper drawer that contains the paper for the cover pages, and then touch [Enter]. Touch [Enter]. If [Cancel] is touched, the setting is cancelled. Press the [Start] key. The copies are printed. Di2510/Di3010/Di3510...
Page 100: Page Insertion" Function
This function cannot be used together with the “Cover Mode” function. This function cannot be used together with booklet-printing and mixed original sizes. Note The optional duplexing document feeder must be installed. Paper Insertion settings Blank With Image Di2510/Di3010/Di3510...
Page 101: To Make Settings For The "Page Insertion" Function
“Insert Paper”. Select the paper drawer that contains the paper for the interleaves, and then touch [Enter]. Touch [Enter]. If [Cancel] is touched, the setting is cancelled. Press the [Start] key. The copies are printed. Di2510/Di3010/Di3510...
Page 102: Ohp Interleaving" Function
When copying overhead projector transparencies, paper (interleaves) can be inserted between copies of the transparencies. Load the paper for the interleaves into a paper drawer, and load the overhead projector transparencies into the multiple bypass tray. OHP Interleaving settings Blank With Image Di2510/Di3010/Di3510...
Page 103: To Make Settings For The "Ohp Interleaving" Function
“Insert Paper”. Select the paper drawer that contains the paper for the transparency interleaves, and then touch [Enter]. Touch [Enter]. If [Cancel] is touched, the setting is cancelled. Press the [Start] key. The copies are printed. Di2510/Di3010/Di3510...
Page 104: File Margin" Function
Copy Document edge of the copy. The image of the document is shifted to Original the bottom to make a margin along the Copy Document top edge of the copy. Di2510/Di3010/Di3510...
Page 105: To Make Settings For The "File Margin" Function
Touch the big arrow keys to specify the width of the binding margin, and then touch [Enter]. If [Cancel] is touched, the setting is cancelled. Press the [Start] key. The copies are printed. Di2510/Di3010/Di3510...
Page 106: Edge/Frame Erase" Function
When copying documents with punch holes, the pages can be printed with part of the document erased. Edge/Frame Erase settings The left side of the document is Original erased. Copy Document The top edge of the document is erased. A frame around the document is erased. 6-10 Di2510/Di3010/Di3510...
Page 107: To Make Settings For The "Edge/Frame Erase" Function
Select the desired Edge/Frame Erase setting. Touch the big arrow keys to specify the width of the erased area, and then touch [Enter]. If [Cancel] is touched, the setting is cancelled. Press the [Start] key. The copies are printed. Di2510/Di3010/Di3510 6-11...
Page 108: Image Repeat" Function
To make settings for the “Image Repeat” function Load the document into the duplexing document feeder or position it on the original glass. Touch [Auxiliary], and then touch [Image Repeat]. Touch [Size Input]. To automatically detect the document size, touch [Auto Detect]. 6-12 Di2510/Di3010/Di3510...
Page 109 Touch [Y]. Use the 10-Key Pad to type in the length of side Y for the paper that is loaded. Touch [Enter]. If [Cancel] is touched, the setting is cancelled. Press the [Start] key. The copies are printed. Di2510/Di3010/Di3510 6-13...
Page 110: Distribution #" Function
After “999” is printed, the number returns to “000”. To make settings for the “Distribution #” function Load the document into the duplexing document feeder or position it on the original glass. Touch [Auxiliary], and then touch [Image Settings]. Touch [Distribution #]. 6-14 Di2510/Di3010/Di3510...
Page 111 If [All Pages] is selected, the distribution number is printed on all pages of each copy set. Touch [Darker], [Normal] or [Lighter] to specify the print density for the distribution number. Touch [Enter]. If [Cancel] is touched, the setting is cancelled. Press the [Start] key. The copies are printed. Di2510/Di3010/Di3510 6-15...
Page 112: Watermark" Function
If [All Pages] is selected, the watermark is printed on all pages. Touch [Enter]. If [Cancel] is touched, the setting is cancelled. Press the [Start] key. The copies are printed. 6-16 Di2510/Di3010/Di3510...
Page 113: Image Stamping" Function
Touch [Auxiliary], and then touch [Image Settings]. Touch [Image Stamping]. Touch [Set], select the registration number to be used, and then touch [Enter]. You can check this by selecting [Check], pressing the [Start] key, and copying the registered image. Di2510/Di3010/Di3510 6-17...
Page 114 If [All Pages] is selected, the image is printed on all pages. Touch [Enter]. If [Cancel] is touched, the setting is cancelled. Press the [Start] key. The copies are printed. 6-18 Di2510/Di3010/Di3510...
Page 115: Black-White Reverse" Function
To set the “Black-White Reverse” function Load the document into the duplexing document feeder or position it on the original glass. Touch [Auxiliary], and then touch [Black-White Reverse]. Press the [Start] key. The copies are printed. Di2510/Di3010/Di3510 6-19...
Page 116: Separate Scan" Function
[Start] key. After all document batches have been scanned, touch [Finish]. Press the [Start] key. The copies are printed. 6-20 Di2510/Di3010/Di3510...
Page 117: Utility Mode Operations
Utility mode. Utility screen This screen appears when the [Utility] key is pressed. The following screens appear when the corresponding button is touched. User’s Choice screen This screen provides functions for specifying various default settings for the copier. Di2510/Di3010/Di3510...
Page 118: Meter Count Screen
This screen shows the total number of copies printed since the copier was installed. Copy Job Program Recall screen From this screen, a programmed copy job can be recalled. User Management screen This screen provides various functions for safely and correctly using the copier. Di2510/Di3010/Di3510...
Page 119: Administrator Management Screens
There are two screens: Administrator Management 1 and Administrator Management 2. The administrator access code must be entered before these screens can be displayed. For details on the functions available from the Administrator Management screens, refer to “8 Administrator Management Operations”. Di2510/Di3010/Di3510...
Page 120: User's Choice Functions
Default Copy Output Auto (Lighter, Normal, Darker) Levels Manual One of nine settings between “Lighter” and “Darker” can be selected. Printing Density -2, -1, 0, 1, 2 Non-Sort, Sort, Group, Corner Staple*, Output Priority 2-Point Staple*, Hole Punch* *Options Di2510/Di3010/Di3510...
Page 121 Specify the bin of the finisher (option). ON, OFF “Small” Originals Scanner Dry Specify the time for dehumidifying the scanner. Crease/Center Staple Crease (-10 to +10, 0) Center staple (-10 to +10, 0) Mode 1, Mode 2 Density (ADF only) Di2510/Di3010/Di3510...
Page 122: Changing Default Settings
If [ON] is selected, the previously copied image data can be printed again, even after copying has finished or while the copier is stand-by. Touch [END] to return to the Utility screen, and then touch [Exit] to return to the Basics screen. Di2510/Di3010/Di3510...
Page 123: To Set The "Mixed Original Detection" Function
Press the [Utility] key. Touch [User’s Choice]. Touch [1/6], and then touch [Mixed Original Detection]. Touch [ON] or [OFF], and then touch [Enter]. Touch [END] to return to the Utility screen, and then touch [Exit] to return to the Basics screen. Di2510/Di3010/Di3510...
Page 124: To Set The "Language Selected For Lcd" Function
Press the [Utility] key. Touch [User’s Choice]. Touch [1/6], and then touch [Language Selected for LCD]. Select the desired language, and then touch [Enter]. Touch [END] to return to the Utility screen, and then touch [Exit] to return to the Basics screen. Di2510/Di3010/Di3510...
Page 125: To Set The "Original > Copy Default" Function
Press the [Utility] key. Touch [User’s Choice]. Touch [2/6], and then touch [Original > Copy Default]. Select the desired setting, and then touch [Enter]. Touch [END] to return to the Utility screen, and then touch [Exit] to return to the Basics screen. Di2510/Di3010/Di3510...
Page 126: To Set The "Auto Paper/Auto Size" Function
Press the [Utility] key. Touch [User’s Choice]. Touch [2/6], and then touch [Auto Paper/Auto Size]. Select the desired setting, and then touch [Enter]. Touch [END] to return to the Utility screen, and then touch [Exit] to return to the Basics screen. 7-10 Di2510/Di3010/Di3510...
Page 127: To Set The "Drawer Priority" Function
Press the [Utility] key. Touch [User’s Choice]. Touch [2/6], and then touch [Drawer Priority]. Select the desired paper drawer, and then touch [Enter]. Touch [END] to return to the Utility screen, and then touch [Exit] to return to the Basics screen. Di2510/Di3010/Di3510 7-11...
Page 128: To Set The "Special Paper" Function
: Not for 2 Sided paper Selecting this mode will mean that double sided copies on paper in that paper tray will not be possible. 7-12 Di2510/Di3010/Di3510...
Page 129 When using colored paper for cover pages or interleaves, selecting this setting reduces operating errors. Touch [END] to return to the Utility screen, and then touch [Exit] to return to the Basics screen. Di2510/Di3010/Di3510 7-13...
Page 130: To Set The "Multiple-In-1 And Booklet Copy Zoom" Function
Touch [ON] or [OFF], and then touch [Enter]. If [OFF] is selected, specify the Zoom settings for the 2in1 and 4in1 Copy settings. Touch [END] to return to the Utility screen, and then touch [Exit] to return to the Basics screen. 7-14 Di2510/Di3010/Di3510...
Page 131: To Set The "Energy Save Mode" Function
Use the 10-Key Pad to specify the desired length of time, and then touch [Enter]. (Specify a length of time between 1 and 240 minutes.) Touch [END] to return to the Utility screen, and then touch [Exit] to return to the Basics screen. Di2510/Di3010/Di3510 7-15...
Page 132: To Set The "Sleep Mode Setting" Function
(Specify a length of time between 1 and 240 minutes.) Selecting the [No Reset] key means that sleep functions will no longer operate. Touch [END] to return to the Utility screen, and then touch [Exit] to return to the Basics screen. 7-16 Di2510/Di3010/Di3510...
Page 133: To Set The "Lcd Back-Light Off" Function
If the preheat and sleep settings are short because of the LCD Back-light being set to off, then the Backlight will be turned off after the specified preheat or sleep time. Touch [END] to return to the Utility screen, and then touch [Exit] to return to the Basics screen. Di2510/Di3010/Di3510 7-17...
Page 134: To Set The "Auto Panel Reset" Function
The length of time until the Basics screen is displayed can be set to 30 seconds, 1, 2, 3 or 5 minutes, or “No Reset”. Touch [END] to return to the Utility screen, and then touch [Exit] to return to the Basics screen. 7-18 Di2510/Di3010/Di3510...
Page 135: To Set The "Plug-In Counter, Id Key Reset" Function
Touch [User’s Choice]. Touch [3/6], and then touch [Plug-In Counter, ID key Reset]. Touch [ON] or [OFF], and then touch [Enter]. Touch [END] to return to the Utility screen, and then touch [Exit] to return to the Basics screen. Di2510/Di3010/Di3510 7-19...
Page 136: To Set The "4In1 Copy Order" Function
Touch [4/6], and then touch [4in1 Copy Order]. Select the page orientation for making 4in1 copies, and then touch [Enter]. Touch [END] to return to the Utility screen, and then touch [Exit] to return to the Basics screen. 7-20 Di2510/Di3010/Di3510...
Page 137: To Set The "Density Priority" Function
[Auto] or [Manual]. The default Original Image Type can be set to [Text], [Photo] or [Text/Photo]. Touch [END] to return to the Utility screen, and then touch [Exit] to return to the Basics screen. Di2510/Di3010/Di3510 7-21...
Page 138: To Set The "Default Copy Output Levels" Function
[Lighter], [Normal] or [Darker]. The default Manual density level can be adjusted by one level at a time. Touch [END] to return to the Utility screen, and then touch [Exit] to return to the Basics screen. 7-22 Di2510/Di3010/Di3510...
Page 139: To Set The "Printing Density" Function
Press the [Utility] key. Touch [User’s Choice]. Touch [4/6], and then touch [Printing Density]. Select the desired settings, and then touch [Enter]. Touch [END] to return to the Utility screen, and then touch [Exit] to return to the Basics screen. Di2510/Di3010/Di3510 7-23...
Page 140: To Set The "Output Priority" Function
Press the [Utility] key. Touch [User’s Choice]. Touch [4/6], and then touch [Output Priority]. Select the desired settings, and then touch [Enter]. Touch [END] to return to the Utility screen, and then touch [Exit] to return to the Basics screen. 7-24 Di2510/Di3010/Di3510...
Page 141: To Set The "Intelligent Sorting" Function
Touch [END] to return to the Utility screen, and then touch [Exit] to return to the Basics screen. Di2510/Di3010/Di3510 7-25...
Page 142: To Set The "Output Tray" Function (Optional)
Touch [User’s Choice]. Touch [5/6], and then touch [Output Tray]. Select the appropriate output tray settings, and then touch [Enter]. Touch [END] to return to the Utility screen, and then touch [Exit] to return to the Basics screen. 7-26 Di2510/Di3010/Di3510...
Page 143: To Set The ""Small" Originals" Function
If [OFF] is selected, a message appears, indicating that the paper should be selected. Touch [END] to return to the Utility screen, and then touch [Exit] to return to the Basics screen. Di2510/Di3010/Di3510 7-27...
Page 144: To Set The "Scanner Dry" Function
[Enter]. Specify the time in the 24-hour format. To erase the value, press the [C] key. Touch [END] to return to the Utility screen, and then touch [Exit] to return to the Basics screen. 7-28 Di2510/Di3010/Di3510...
Page 145: To Set The "Crease/Center Staple" Function (Only When The Finisher Or Saddle Kit Are Installed)
Touch [User’s Choice]. Touch [5/6], and then touch [Crease/Center Staple]. Touch the arrow keys to adjust the setting, and then touch [Enter]. Touch [END] to return to the Utility screen, and then touch [Exit] to return to the Basics screen. Di2510/Di3010/Di3510 7-29...
Page 146: To Set The "Density (Adf Only)" Function (Only When The Duplexing Document Feeder Is Installed)
The setting on the right is most appropriate for scanning faint document (such as those written with pencil). Touch [END] to return to the Utility screen, and then touch [Exit] to return to the Basics screen. 7-30 Di2510/Di3010/Di3510...
Page 147: Registering An Image Stamp
To erase a stored image, touch [Delete], and then touch the number from where you wish to delete the image. To check a stored image, touch [Check], and then touch the number where the image that you wish to check is stored. Di2510/Di3010/Di3510 7-31...
Page 148 Y for the image document (between 25 and 297 mm). Touch [Enter]. Position the document on the glass, and then select the orientation of the document. Press the [Start] key. The image is scanned. The image stamp is registered. 7-32 Di2510/Di3010/Di3510...
Page 149: Viewing Counters ("Meter Count" Function)
To view the counters Press the [Utility] key. Touch [Meter Count]. After checking the various counters, touch [Exit]. There are two Meter Count screens. To view the other screen, touch [Next]. Touch [Exit] to return to the Basics screen. Di2510/Di3010/Di3510 7-33...
Page 150: Using Copy Programs
Touch [Check], and then touch a number button. Check the programmed settings. To display screen 2/2, touch [Next]. To return to screen 1/2, touch [Back]. Touch [Enter] to return to the Mode Check screen, and then touch [Exit] to return to the Basics screen. 7-34 Di2510/Di3010/Di3510...
Page 151: To Delete A Copy Program
[Delete]. The copy program is deleted, appears on the button. Touch [Exit] to return to the Mode Check screen, and then touch [Exit] to return to the Basics screen. Di2510/Di3010/Di3510 7-35...
Page 152: To Use A Copy Program
Touch the button assigned with the copy program that you wish to use. Only buttons that have been assigned a copy program are displayed. Check the settings, and then touch [Enter]. Set the document, and press the [Start] key. 7-36 Di2510/Di3010/Di3510...
Page 153: User Management Functions
Touch the arrow keys to select the desired volume, and then touch [Enter]. Touch [END] to return to the Utility screen, and then touch [Exit] to return to the Basics screen. Di2510/Di3010/Di3510 7-37...
Page 154: To Clean The Touch Panel ("Panel Cleaning" Function)
To clean the touch panel (“Panel Cleaning” function) By setting panel cleaning, you can clean the panel without accidentally pressing panel buttons. Press the [Utility] key. Touch [User Management], and then touch [Panel Cleaning]. To cancel the function, press the [Panel Reset] key. 7-38 Di2510/Di3010/Di3510...
Page 155: To Dehumidify The Duplexing Document Feeder ("Dehumidify" Function)
You can still copy if there during dehumidifying. (however, dehumidifying will be interrupted.) To specify a time to perform the dehumidifying operation, refer to page 7-28. Press the [Utility] key. Touch [User Management], and then touch [Dehumidify]. The dehumidifying operation begins. Di2510/Di3010/Di3510 7-39...
Page 156: To Replenish The Toner ("Toner Replenisher" Function)
If this occurs, toner can be replenished. Press the [Utility] key. Touch [User Management], and then touch [Toner Replenisher]. The toner is replenished. 7-40 Di2510/Di3010/Di3510...
Page 157: Administrator Management Operations
“The Admin. Code is now disable due to unauthorized access cannot Admin. Mode.” appears, access to Administrator mode is denied, and the password will not be accepted. To allow access to Administrator mode, turn the machine off, then on again. Di2510/Di3010/Di3510...
Page 158 When specifying [1000 Accounts] or [OFF] in the account management mode, neither the [Account Reg] nor Administrator Management 2 the [Account Counter] keys will be displayed. Refer to “To set the Account Management Mode” on page 8-11 for details. Di2510/Di3010/Di3510...
Page 159: Initial Settings
Use the 10-Key Pad to type in the current date and time, and then touch [Enter]. To re-enter the entered value, press the [C] key. Touch the button for the year, month, day, hour or minutes, and then use the 10-Key Pad to enter the value. Di2510/Di3010/Di3510...
Page 160 Administrator Management Operations Enter four digits for the year. Enter the time in the 24-hour format. Continue touching [Enter] to return to the Utility screen, and then touch [Exit] to return to the Basics screen. Di2510/Di3010/Di3510...
Page 161: Specify The Time Zone
Touch the arrow keys to adjust the setting, and then touch [Enter]. The time difference can be adjusted in 30-minute intervals. Continue touching [Enter] to return to the Utility screen, and then touch [Exit] to return to the Basics screen. Di2510/Di3010/Di3510...
Page 162: Administrator Settings
When the “Get Penalty” function is set to “ON”, incorrectly typing the administrator code is counted as an incorrect attempt to access the machine. After three incorrect attempts, the Utility screen is displayed, access to Administrator mode is denied, and the administrator code (administrator password) will not be accepted. Di2510/Di3010/Di3510...
Page 163 To return to the previous screen, touch [Cancel]. Note If the entered administrator code does not have 8 digits, the message “Incorrect code and new administrator. Input administrator code.” appears. Type in an 8-digit administrator code. Touch [Enter]. Di2510/Di3010/Di3510...
Page 164: Copy Number Limits
Use the 10-Key Pad to specify the maximum number of copies, and then touch [Enter]. Numbers between 1 and 99 can be specified. Continue touching [Enter] to return to the Utility screen, and then touch [Exit] to return to the Basics screen. Di2510/Di3010/Di3510...
Page 165: Disable Sleep Mode
“Sleep Mode Setting” function, which is available from the User’s Choice screen. On the User’s Choice [3/6] sleep mode setting screen, select [No]. Continue touching [Enter] to return to the Utility screen, and then touch [Exit] to return to the Basics screen. Di2510/Di3010/Di3510...
Page 166: Account Management Settings
Total counter: displays the total counter value for each account. Additionally, clears the counter value [1000 Accounts] Enter the account number to make copies. Additionally, the following can be configured per account. Total counter: displays the total counter value for each account. Additionally, clears the counter value 8-10 Di2510/Di3010/Di3510...
Page 167: To Set The Account Management Mode
This will set the default account information. Select [Yes], and touch [Enter]. Note When programming or changing account information data, please set the default account information data. However, depending on the currently specified account information method, the default screen may not be displayed. Di2510/Di3010/Di3510 8-11...
Page 168 Continue touching [Enter] to return to the Utility screen, and then touch [Exit] to return to the Basics screen. Note Only when setting [100 Accounts 1] or [100 Accounts 2], will the [Account Reg] or the [Account Counter] be displayed on the Admin.1 screen. 8-12 Di2510/Di3010/Di3510...
Page 169: Account Information Data
Set A4 L paper in the 1st paper drawer, then press the [Start] key. Account management data is printed. Continue touching [Enter] to return to the Utility screen, and then touch [Exit] to return to the Basics screen. Di2510/Di3010/Di3510 8-13...
Page 170: Clear All Counters
[Interrupt] key. If you wish to clear the total counter of other accounts, repeat steps 4 and 5. Continue touching [Enter] to return to the Utility screen, and then touch [Exit] to return to the Basics screen. 8-14 Di2510/Di3010/Di3510...
Page 171: Changing Account Information
[C] key. Use the 10-Key Pad to type in the value you wish to change. Continue touching [Enter] to return to the Utility screen, and then touch [Exit] to return to the Basics screen. Di2510/Di3010/Di3510 8-15...
Page 172: Setting Account Registration
Follow the procedure described in “To display the Administrator Management screens” on page 8-1 to display the Administrator Management screen. Touch [Admin. 1], and touch [Account Reg]. Select the account key to program or change. Touch [Account Name]. 8-16 Di2510/Di3010/Di3510...
Page 173 Touch [Enter]. Touch [Access Number], and enter the access code for the account. Touch [Enter]. Touch [Account Number], and enter the account number using the 10-Key Pad. Touch [Enter]. Di2510/Di3010/Di3510 8-17...
Page 174 Where you wish to change the programmed details, repeat from step 3, entering the correct details. To delete programmed details, at step 4, press the [Delete] key. Continue touching [Enter] to return to the Utility screen, and then touch [Exit] to return to the Basics screen. 8-18 Di2510/Di3010/Di3510...
Page 175: Account Counter
Touch the button for the account whose counter you wish to view, and then touch [Enter]. After checking the counter, then touch [Enter]. Continue touching [Enter] to return to the Utility screen, and then touch [Exit] to return to the Basics screen. Di2510/Di3010/Di3510 8-19...
Page 176: Setting Machine Access
[ON]. To stop using the “Get Penalty” function, touch [OFF]. Touch [Enter]. To return to the previous screen, touch [Cancel]. Continue touching [Enter] to return to the Utility screen, and then touch [Exit] to return to the Basics screen. 8-20 Di2510/Di3010/Di3510...
Page 177: Configuring Functions (Soft Switches)
HEX specification (hexadecimal) 0000 0000 0000 0001 0000 0010 0000 0011 0000 0100 0000 0101 0000 0110 0000 0111 0000 1000 0000 1001 0000 1010 0000 1011 0000 1100 0000 1101 0000 1110 0000 1111 0001 0000 1111 1111 Di2510/Di3010/Di3510 8-21...
Page 178: Specifying Settings For Resetting Copy Mode With The Duplexing Document Feeder Installed (Mode 429)
* Do not change these bits. Specifies whether or not Do not clear Copy mode is reset after Clear a copy job scanned using the duplexing document feeder is finished 4, 3, 2, 1, 0 00000 * Do not change these bits. 8-22 Di2510/Di3010/Di3510...
Page 179: Removing Penalties
For more details, refer to the User Manual for the printer controller. In addition, to allow access after incorrect attempts to access Administrator mode, turn the machine off, then on again. Di2510/Di3010/Di3510 8-23...
Page 180 Administrator Management Operations 8-24 Di2510/Di3010/Di3510...
Page 181: Copy Paper
3rd paper drawer (LCC*) — — — — 3rd paper drawer — — — — 4th paper drawer — — — — Double-sided copies — — — — * LCC: Large capacity cabinet 2: Available—: Not available Paper Sizes Non-standard-sized paper Di2510/Di3010/Di3510...
Page 182 B6 L Paper Source, Etc. Multiple bypass tray 1st paper drawer — 2nd paper drawer — 3rd paper drawer (LCC*) — 3rd paper drawer — 4th paper drawer — Double-sided copies * LCC: Large capacity cabinet 2: Available—: Not available Di2510/Di3010/Di3510...
Page 183: Paper Capacity
If the optional finisher is used to sort/group, punch holes and staple, only plain paper can be used. The paper size setting for the 3rd paper drawer (large capacity cabinet) can be changed in order to load Letter-size paper. Contact your service representative to change the paper size setting. Di2510/Di3010/Di3510...
Page 184: Unsuitable Paper
Paper of a non-standard shape (not rectangular) Paper that is bound with glue, staples or paper clips Paper with labels attached Paper with ribbons, hooks, buttons, etc. attached Curled or wrinkled paper Art paper, coated paper or inkjet printer paper Di2510/Di3010/Di3510...
Page 185: Print Area
Not exposed to direct sunlight Not exposed to a flame Not exposed to high humidity Not extremely dusty Unwrapped paper should be placed in a plastic bag and stored in a cool, dark location. Keep paper out of the reach of children. Di2510/Di3010/Di3510...
Page 186: Automatically Selecting The Paper Source
We recommend that you make selections for special media in the User’s Choice Special Settings. For details, refer to User’s Choice Settings in the Advanced Operations volume of the User Manual. Di2510/Di3010/Di3510...
Page 187: Loading Paper
We recommend replenishing the paper only after all of the paper in the drawer has been used. Di2510/Di3010/Di3510...
Page 188: Loading Paper Into The 1St/2Nd/3Rd/4Th Paper Drawer
(the side facing up when the package was unwrapped) faces up. Note Be careful not to touch the mylar. Mylar Re-adjust the paper guides to fit the size of the paper. Close the paper drawer. Di2510/Di3010/Di3510...
Page 189: Loading Paper Into The Large Capacity Cabinet
Note Be careful not to touch the mylar. Load the paper into the left side of the drawer so that the front side of the paper (the side facing up when the package was unwrapped) faces Di2510/Di3010/Di3510...
Page 190: Loading Paper Into The Multiple Bypass Tray
Note Do not load so much paper that the top of the stack is higher Paper guides than the Ä mark. Make sure that the paper guides are pushed up against the edges of the paper. 9-10 Di2510/Di3010/Di3510...
Page 191: To Load Postcards
Note Do not load more than 50 postcards. Do not load postcards crosswise. After you have loaded the paper, set the paper type for the Multiple Bypass Tray in the touch panel. Di2510/Di3010/Di3510 9-11...
Page 192: To Load Envelopes
Do not load more than 10 envelopes. After you have loaded the paper, set the paper type for the Multiple Bypass Tray in the touch panel. Note Do not load envelopes crosswise. Do not place the flap of envelopes facing down. 9-12 Di2510/Di3010/Di3510...
Page 193: To Load Overhead Projector Transparencies
Place documents with the side to be printed facing down. Note Do not load more than 50 label sheets. After you have loaded the paper, set the paper type for the Multiple Bypass Tray in the touch panel. Di2510/Di3010/Di3510 9-13...
Page 194: To Set A Non-Standard (Custom) Paper Size
Touch the button for the multiple bypass tray, and then touch [Mode Change]. Touch [Custom Size]. The Custom Size screen appears. Touch [X] and press the [C] key. Then, using the 10-Key Pad, type in the length of side X for the document. 9-14 Di2510/Di3010/Di3510...
Page 195 Copy Paper Touch [Y] and press the [C] key. Then, using the 10-Key Pad, type in the length of side Y for the document. Touch [Enter]. Di2510/Di3010/Di3510 9-15...
Page 196: To Store A Non-Standard (Custom) Paper Size
Touch the button for the multiple bypass tray, and then touch [Mode Change]. Touch [Custom Size]. The Custom Size screen appears. Touch [Memorize Paper Size]. 9-16 Di2510/Di3010/Di3510...
Page 197 To store another custom paper size, repeat steps 4,5 and 6. Touch [Enter]. This completes the storing of custom paper sizes. Di2510/Di3010/Di3510 9-17...
Page 198: To Select A Stored Non-Standard (Custom) Paper Size
Touch the button for the multiple bypass tray, and then touch [Mode Change]. Touch [Custom Size]. Touch either [1] or [2] to select the stored custom paper size, and then touch [Enter]. Press the [Start] key. The copies are printed. 9-18 Di2510/Di3010/Di3510...
Page 199: Selecting The Paper Setting
Touch the button for the multiple bypass tray, and then touch [Mode Change]. Touch the button for the type of paper loaded into the multiple bypass tray, and then touch [Enter]. Press the [Start] key. The copies are printed. Di2510/Di3010/Di3510 9-19...
Page 200 Copy Paper 9-20 Di2510/Di3010/Di3510...
Page 201: Original Documents
A3 L, B4 L, A4 L/C, B5 L/C, A5 L/C, B6 L Documents of Mixed Original Detection mode Single-Sided Documents Double-Sided Documents Paper Type Plain Paper (50 to 128 g/m Document Size Refer to "Mixed Width Document Sizes". Di2510/Di3010/Di3510 10-1...
Page 202: Mixed Width Document Sizes
— 182 mm B5 L — — — — 148 mm A5 L — — — — — — — 123 mm B6 L — — — — — — — 2: Copying possible —: Copying not possible 10-2 Di2510/Di3010/Di3510...
Page 203: Precautions Concerning The Documents
Documents on paper that cannot be fed Curled documents Wrinkled or torn documents Overhead transparencies If non-standard-sized paper is determined to be close to a standard size, copying with the “Auto Paper” or “Auto Size” settings is possible. Di2510/Di3010/Di3510 10-3...
Page 204: Feeding The Document Through The Duplexing Document Feeder
Adjust the document guides to the size of the document. Note Be sure to load the document correctly, otherwise the pages may not be fed in straight. 10-4 Di2510/Di3010/Di3510...
Page 205 Original Direction setting, certain copy operations, such as 2in1 or 4in1 copying, will not be printed correctly. Press the [Start] key. The pages of the document are fed in, starting with the topmost page. Di2510/Di3010/Di3510 10-5...
Page 206: To Load A Document Of Mixed Sizes ("Mixed Orig Detection" Function)
Be sure to load the document correctly, otherwise the pages may not be fed in straight. Note Certain document size combinations are not possible with the “Mixed Orig Detection” function. For details, refer to page 10-2. 10-6 Di2510/Di3010/Di3510...
Page 207 Original Documents In the Basics screen, touch [Mixed Orig Detection]. Select the desired copy settings, and then press the [Start] key. Di2510/Di3010/Di3510 10-7...
Page 208: Positioning Documents On The Original Glass
“Feeding the Document Through the Duplexing Document Feeder” (page 10-4). When placing the document directly on the original glass, position it after lifting the original cover or the duplexing document feeder 15° or more, as shown below. When loaded horizontally When loaded vertically 10-8 Di2510/Di3010/Di3510...
Page 209: To Position Sheet Documents
Position the document so that it aligns with the arrow in the upper- left corner of the document scales. Carefully close the original cover, or the duplexing document feeder if it is installed. Di2510/Di3010/Di3510 10-9...
Page 210: To Position Transparent Or Translucent Documents
Place a blank sheet of paper of the same size over the document. Carefully close the original cover, or the duplexing document feeder if it is installed. 10-10 Di2510/Di3010/Di3510...
Page 211: To Position Books Or Magazines
Do not place objects exceeding 3 kg on the original glass. If a book is placed on the original glass, do not press it down with extreme force, otherwise the original glass may be damaged. For details, refer to “Copying a Book” on page 11-25. Di2510/Di3010/Di3510 10-11...
Page 212: Loading Documents For Specific Applications
7. Shows the selected File Margin setting from the Auxiliary screen if a binding margin is specified for the copy. (Advanced Operations volume) 8. Shows the stapling or hole-punching position that must be selected. (page 11-6 and page 11-8) 10-12 Di2510/Di3010/Di3510...
Page 213: Single-Sided Documents
Sided Punch 2-Point Staple Document: Vertical Paper Single- Corner — — — Sided Staple Single- Corner — — — Sided Staple Single- Hole — — Sided Punch 2-Point Staple Single- Hole — — — Sided Punch 2-Point Staple Di2510/Di3010/Di3510 10-13...
Page 214 2in1 Punch 2-Point Staple Document: Vertical Paper Single- Corner — — — 2in1 Staple Single- Corner — — — 2in1 Staple Single- Hole — — — 2in1 Punch 2-Point Staple Single- Hole — — 2in1 Punch 2-Point Staple 10-14 Di2510/Di3010/Di3510...
Page 215 4in1 Punch 2-Point Staple Document: Vertical Paper Single- Corner — — — 4in1 Staple Single- Corner — — — 4in1 Staple Single- Hole — — 4in1 Punch 2-Point Staple Single- Hole — — — 4in1 Punch 2-Point Staple Di2510/Di3010/Di3510 10-15...
Page 216 — Sided Punch 2-Point Staple Document: Vertical Paper Double- Corner — — Sided Staple Double- Corner — — — Sided Staple Double- Hole — — Sided Punch 2-Point Staple Double- Hole — — — Sided Punch 2-Point Staple 10-16 Di2510/Di3010/Di3510...
Page 217 — 2in1 Punch 2-Point Staple Document: Vertical Paper Double- Corner — — — 2in1 Staple Double- Corner — — 2in1 Staple Double- Hole — — — 2in1 Punch 2-Point Staple Double- Hole — — 2in1 Punch 2-Point Staple Di2510/Di3010/Di3510 10-17...
Page 218 4in1 Staple 9 10 11 12 Double- Corner — — — 4in1 Staple 9 10 11 12 Double- Hole — — 4in1 Punch 9 10 2-Point 11 12 Staple Double- Hole — — — 4in1 Punch 2-Point Staple 10-18 Di2510/Di3010/Di3510...
Page 219: Left-Bound Double-Sided Documents
Single- Hole — — Sided Punch 2-Point Staple Document: Vertical Paper Single- Corner — — Sided Staple Single- Corner — — Sided Staple Single- Hole — — Sided Punch 2-Point Staple Single- Hole — Sided Punch 2-Point Staple Di2510/Di3010/Di3510 10-19...
Page 220 Hole — — — 2in1 Punch 2-Point Staple Document: Vertical Paper Single- Corner — — 2in1 Staple Single- Corner — — 2in1 Staple Single- Hole — — 2in1 Punch 2-Point Staple Single- Hole — 2in1 Punch 2-Point Staple 10-20 Di2510/Di3010/Di3510...
Page 221 Single- Hole — — 4in1 Punch 2-Point Staple Document: Vertical Paper Single- Corner — — 4in1 Staple Single- Corner — — 4in1 Staple Single- Hole — — 4in1 Punch 2-Point Staple Single- Hole — 4in1 Punch 2-Point Staple Di2510/Di3010/Di3510 10-21...
Page 222 Staple Double- Hole — — Sided Punch 2-Point Staple Document: Vertical Paper Double- Corner — — Sided Staple Double- Corner — Sided Staple Double- Hole — Sided Punch 2-Point Staple Double- Hole — — Sided Punch 2-Point Staple 10-22 Di2510/Di3010/Di3510...
Page 223 Double- Hole — — — 2in1 Punch 2-Point Staple Document: Vertical Paper Double- Corner — — 2in1 Staple Double- Corner — 2in1 Staple Double- Hole — — 2in1 Punch 2-Point Staple Double- Hole — 2in1 Punch 2-Point Staple Di2510/Di3010/Di3510 10-23...
Page 224 Double- Corner — — 4in1 Staple 9 10 11 12 Double- Corner — 4in1 Staple 9 10 11 12 Double- Hole — 4in1 Punch 9 10 2-Point 11 12 Staple Double- Hole — — 4in1 Punch 2-Point Staple 10-24 Di2510/Di3010/Di3510...
Page 225: Top-Bound Double-Sided Documents
Sided Punch 2-Point Staple Document: Vertical Paper Single- Corner — — — Sided Staple Single- Corner — — — Sided Staple Single- Hole — — Sided Punch 2-Point Staple Single- Hole — — — Sided Punch 2-Point Staple Di2510/Di3010/Di3510 10-25...
Page 226 — 2in1 Punch 2-Point Staple Document: Vertical Paper Single- Corner — — — 2in1 Staple Single- Corner — — 2in1 Staple Single- Hole — — — 2in1 Punch 2-Point Staple Single- Hole — — 2in1 Punch 2-Point Staple 10-26 Di2510/Di3010/Di3510...
Page 227 4in1 Punch 2-Point Staple Document: Vertical Paper Single- Corner — — — 4in1 Staple Single- Corner — — — 4in1 Staple Single- Hole — — 4in1 Punch 2-Point Staple Single- Hole — — — 4in1 Punch 2-Point Staple Di2510/Di3010/Di3510 10-27...
Page 228 — Sided Punch 2-Point Staple Document: Vertical Paper Double- Corner — — Sided Staple Double- Corner — — — Sided Staple Double- Hole — — Sided Punch 2-Point Staple Double- Hole — — — Sided Punch 2-Point Staple 10-28 Di2510/Di3010/Di3510...
Page 229 — 2in1 Punch 2-Point Staple Document: Vertical Paper Double- Corner — — — 2in1 Staple Double- Corner — — 2in1 Staple Double- Hole — — — 2in1 Punch 2-Point Staple Double- Hole — — 2in1 Punch 2-Point Staple Di2510/Di3010/Di3510 10-29...
Page 230 4in1 Staple 9 10 11 12 Double- Corner — — — 4in1 Staple 9 10 11 12 Double- Hole — — 4in1 Punch 9 10 2-Point 11 12 Staple Double- Hole — — — 4in1 Punch 2-Point Staple 10-30 Di2510/Di3010/Di3510...
Page 231: Large Documents
Original Direction setting from the Orig. Ö Copy screen. A page 11-21 When making A3 L or B4 L copies, the “2-Point Staple” and “Hole Punch” settings are not available with the following positions. Di2510/Di3010/Di3510 10-31...
Page 232 Original Documents 10-32 Di2510/Di3010/Di3510...
Page 233: Specifying Copy Settings
Non-Sort The copies are fed out and stacked on top of each other as they are printed. Sort The copies are automatically divided into the specified number of sets with each set containing a copy of each page. Di2510/Di3010/Di3510 11-1...
Page 234 Only when the finisher is installed 2-Point Staple Copies printed with the “Sort” or “Group” setting are automatically stapled together at two points on the left edge. Note Thick paper, envelopes and overhead projector transparencies cannot be stapled. 11-2 Di2510/Di3010/Di3510...
Page 235 The default setting is “Non-Sort”. The default setting can be changed using a function on the User’s Choice screen. For details, refer to “Changing Default Settings” on page 7-6. Di2510/Di3010/Di3510 11-3...
Page 236: Notes On Using The "Sort" And "Group" Settings
A4 or B5 sized paper is set horizontally or vertically. If a finisher is installed, crisscross sorting can not be carried out. Shift Sorting Each copy set is fed out shifted to alternating sides. Crisscross Sorting Each copy set is fed out in an alternating crisscross pattern. 11-4 Di2510/Di3010/Di3510...
Page 237: Shift Grouping
Specifying Copy Settings Shift Grouping Each page set is fed out shifted to alternating sides. Crisscross Grouping Each page set is fed out in an alternating crisscross pattern. Di2510/Di3010/Di3510 11-5...
Page 238: To Make Copies Using A Stapling Setting
The copies are printed. Note A stapling setting cannot be selected if another job has been interrupted. When making copies while using a staple setting, be careful of the selected stapling position. For details, refer to page 11-10. 11-6 Di2510/Di3010/Di3510...
Page 239 For details, refer to “Auxiliary Functions” on page 6-1. When copying while using a stapling setting, be sure that the maximum number of pages that can be stapled together is not exceeded. Where you do not set the position, the stapling position is automatically specified. Di2510/Di3010/Di3510 11-7...
Page 240: To Make Copies Using The "Hole Punch" Setting
If copying is started without the hole punch position specified or if "OFF" was selected, the hole punch position is automatically specified according to the document orientation, as shown below. To adjust the position of the punched holes, contact your service representative. 11-8 Di2510/Di3010/Di3510...
Page 241: Creasing And Folding
The copies are printed. Note Creased and 2-point staple can be applied to A3, B4, A4, and B5 sized paper. 2 to 15 sheets of paper can be stabled. Only plain and recycled paper can be creased or 2-Point Stapled. Di2510/Di3010/Di3510 11-9...
Page 242: Notes On The Staple Position
Document size: A4 L Paper size: A4 C Document size: A4 L Document size: A4 L Paper size: A4 L Document size: A3 L, B4 L Document size: A3 L, B4 L Paper size: A3 L, B4 L 11-10 Di2510/Di3010/Di3510...
Page 243 Document size: A4 L Paper size: A4 C Document size: A4 L Document size: A4 L Paper size: A4 L Document size: A3 L, B4 L Document size: A3 L, B4 L Paper size: A3 L, B4 L Di2510/Di3010/Di3510 11-11...
Page 244: Notes On The Number Of Possible Stapled Sets
When copying with the "Hole Punch" setting selected, be careful of the orientation of the document. When the finisher (FN-117) and saddle kit are installed Screen Icon Document Orientation Feeding From the Duplexing Scanning From the Original Glass Document Feeder 11-12 Di2510/Di3010/Di3510...
Page 245: Specifying A Zoom Setting
The zoom ratio of the “Minimal” setting can be changed to any ratio between × 0.900 and × 0.999. Zooming Any zoom ratio (between × 0.250 and × 4.000) can be specified. Di2510/Di3010/Di3510 11-13...
Page 246: To Select A Zoom Setting
The copy size can be changed by specifying different scaling proportions (between × 0.250 and × 4.000) for the vertical and the horizontal dimensions. To select a Zoom setting Touch [Zoom]. A screen appears, showing the available Zoom settings. Select the desired Zoom setting. 11-14 Di2510/Di3010/Di3510...
Page 247: Specifying A "Custom Zoom" Setting
A screen appears, showing the available Zoom settings. Touch [CustomZoom]. Use the 10-Key Pad to type in the desired zoom ratio (between × 0.250 and × 4.000). Touch [Enter]. The entered zoom ratio is displayed and is specified as the custom Zoom setting. Di2510/Di3010/Di3510 11-15...
Page 248: To Store Custom Zoom And Minimal Zoom Ratios
The entered zoom ratio is stored. To recall a stored custom zoom ratio Touch [Zoom]. A screen appears, showing the available Zoom settings. Touch [CustomZoom]. Touch [1], [2] or [Minimal]. Touch [Enter]. The entered zoom ratio is recalled. 11-16 Di2510/Di3010/Di3510...
Page 249: To Specify Different Vertical And Horizontal Scaling Proportions ("X/Y Zoom" Setting)
X (between × 0.250 and × 4.000). Use the 10-Key Pad to type in the desired length of side Y (between × 0.250 and × 4.000). Touch [Enter]. The entered zoom ratio is applied. Di2510/Di3010/Di3510 11-17...
Page 250: Selecting The Orig. > Copy Settings
Double-Sided Ö Single-Sided Only if the duplexing document feeder is installed: Two single-sided copies are produced from a double-sided document. Double-Sided Ö Double-Sided Only if the duplexing document feeder is installed: A double-sided copy is produced from a double-sided document. 11-18 Di2510/Di3010/Di3510...
Page 251 A double-sided copy is produced from eight single-sided documents. Single-Sided Ö Booklet Creation A double-sided copy is produced from four single-sided documents. Double-Sided Ö Single-4in1 Only if the duplexing document feeder is installed: A single-sided copy is produced from two double-sided documents. Di2510/Di3010/Di3510 11-19...
Page 252 Book (Spreadsheet) Ö Single-Sided A single-sided copy is produced from a bound document. Book (Separation) Ö Double-Sided A double-sided copy is produced from a bound document. Book (Spreadsheet) Ö Double- Sided A double-sided copy is produced from a bound document. 11-20 Di2510/Di3010/Di3510...
Page 253: To Specify Orig. > Copy Settings
Touch [Orig. > Copy]. Select the setting for the type of document to be copied. (For the example at the right, touch [Single-Sided].) Select the setting for the desired type of copy. (For the example at the right, touch [Double-Sided].) Di2510/Di3010/Di3510 11-21...
Page 254 [Enter]. Touch [Original Direction]. Select an Original Direction setting if the document is loaded in an orientation other than the standard. Select the appropriate document orientation setting. Touch [Enter]. Press the [Start] key. The copies are printed. 11-22 Di2510/Di3010/Di3510...
Page 255: Copying A Bound Document
For details, refer to “10 Original Documents”. Touch [Orig. > Copy]. Touch [Margin]. Select the appropriate binding margin position. Left binding position There are two locations for the binding position, as shown in the illustrations at the right. Top binding position Di2510/Di3010/Di3510 11-23...
Page 256 Original Document Copy To adjust the width of the area erased from the bottom of the back side of the page, contact your service representative. 11-24 Di2510/Di3010/Di3510...
Page 257: Copying A Book
(“Standard Book” or “RightBound”). Select whether to copy both pages of the book onto one sheet (“Spreadsheet”) or onto two separate sheets (“Separation”). To erase around the text or along the binding, touch [Book Erase]. Di2510/Di3010/Di3510 11-25...
Page 258 The erased area can be set between 5 mm and 20 mm, in 1 mm increments. As a default, the width of the area erased along the binding is 12 mm. To change this default setting, consult your service representative. 11-26 Di2510/Di3010/Di3510...
Page 259 Specifying Copy Settings Touch [Enter]. Select the desired copy settings. Note If you touch [Book], you can not select [Single-2in1] or [4in1 / Booklet]. Press the [Start] key. The copies are printed. Di2510/Di3010/Di3510 11-27...
Page 260: Copying Book Pages Onto Separate Double-Sided Pages
Select the appropriate setting for the binding position of the book (“Standard Book” or “RightBound”). Touch [Separation], and then touch [Enter]. Touch [Double-Sided]. Touch [Page Order]. Select the setting for the desired page order, and then touch [Enter]. 11-28 Di2510/Di3010/Di3510...
Page 261 Specifying Copy Settings Book page order Both the left and the right sides are double-sided. Press the [Start] key. The copies are printed. Di2510/Di3010/Di3510 11-29...
Page 262: Quickly Selecting Default Settings
“Single-Sided > Double-Sided” or “Double-Sided > Double-Sided”. The default settings can be changed using the various functions on the User’s Choice screen. For details, refer to “Changing Default Settings” on page 7-6. 11-30 Di2510/Di3010/Di3510...
Page 263: Specifying A Copy Density
“Auto” Density: The density is automatically adjusted for the document. Position the document(s) to be copied. For details, refer to “10 Original Documents”. Touch [Density]. Touch [Text]. Touch [Auto], or touch [Lighter] and [Darker] to select the desired Density setting. Di2510/Di3010/Di3510 11-31...
Page 264: Selecting The "Photo" Setting
For details, refer to “10 Original Documents”. Touch [Density]. Touch [Photo]. Touch [Lighter] and [Darker] to select the desired Density setting. Note The “Auto” Density setting cannot be selected if the “Photo” setting is selected. Selecting the “Auto” setting automatically selects the “Text” setting. 11-32 Di2510/Di3010/Di3510...
Page 265: Selecting The "Text/Photo" Setting
If the “Auto” Density setting is selected, the density of the copy is adjusted as necessary. However, the density can be made lighter or darker using a function on the User’s Choice screen. For details, refer to “Changing Default Settings” on page 7-6. Di2510/Di3010/Di3510 11-33...
Page 266 Specifying Copy Settings 11-34 Di2510/Di3010/Di3510...
Page 267: Touch Panel Messages
When the toner is nearly empty, the “Please add toner” message is displayed. After it is displayed, you can still print approximately 1000 pages, however please replace the bottle as soon as possible. For details, refer to “To replace the toner bottle” on page 12-2. Di2510/Di3010/Di3510 12-1...
Page 268: When The Message "Please Add Toner." Appears
Follow the procedure described below to replace the toner bottle. To replace the toner bottle Open the front door. Pull the toner hopper out as far as possible. Flip up the toner bottle holder. 12-2 Di2510/Di3010/Di3510...
Page 269 Since the toner within the bottle may have become compacted, be sure to break it up by performing this step. Shake the new toner bottle up and down about 5 times. With the seal on the toner bottle facing upward, insert the bottle. Di2510/Di3010/Di3510 12-3...
Page 270 While toner is being refilled, do not turn off the copier or open any other doors. If the print is faint immediately after the toner bottle is replaced, replenish the toner. (For more details, refer to “User Management Functions” on page 7-37.) 12-4 Di2510/Di3010/Di3510...
Page 271: When The Message "Stapler Empty." Appears
Be sure to replace the staple cartridge only after the message appears. The machine may be damaged if the staple cartridge is removed before the message appears. To replace the staple cartridge for finisher Open the front door. Di2510/Di3010/Di3510 12-5...
Page 272 Press in the area marked “PUSH” to unlock the staple holder. Remove the empty staple cartridge from the staple cartridge holder. Insert the new staple cartridge into the staple cartridge holder, and then carefully remove the stopper. 12-6 Di2510/Di3010/Di3510...
Page 273 Touch Panel Messages Insert the refilled staple cartridge holder until it locks into place. Close the front door. Di2510/Di3010/Di3510 12-7...
Page 274: To Replace The Staple Cartridge For The Saddle Kit
To replace the staple cartridge for the saddle kit While holding up the paper output tray, remove the staple cartridge. Press in the area marked “PUSH” to unlock the staple holder. Remove the empty staple cartridge from the staple cartridge holder. 12-8 Di2510/Di3010/Di3510...
Page 275 Insert the refilled staple cartridge holder until it locks into place. CAUTION Be careful when installing the staple cartridge holder. § Be sure that the staple cartridge holder is inserted facing the correct direction. Lower the paper output tray. Di2510/Di3010/Di3510 12-9...
Page 276 Touch Panel Messages Open then shut the misfeed- clearing door. 12-10 Di2510/Di3010/Di3510...
Page 277: When A Paper Misfeed Occurs
A paper misfeed in the multiple A paper misfeed in the mail bin bypass tray (page 12-18) kit (page 12-24) A paper misfeed in the 1st or A paper misfeed in the saddle 2nd paper drawer (page 12-19) kit (page 12-26) Di2510/Di3010/Di3510 12-11...
Page 278: To Clear A Paper Misfeed In The Duplexing Document Feeder
Pull up the lever for the misfeed- clearing cover, and then open the cover. Carefully pull out any misfed documents. Swing up the document guide lever. Turn the dial to feed out any misfed documents. 12-12 Di2510/Di3010/Di3510...
Page 279 Touch Panel Messages While supporting the document feed tray with your right hand, carefully pull out any misfed paper. Return the document guide to its original position, and then close the misfeed-clearing cover. Di2510/Di3010/Di3510 12-13...
Page 280: To Clear A Paper Misfeed In The Fusing Section
Touching any part other those indicated may result in burns. If you get burnt, immediately cool the skin under cold water, and then seek professional medical attention. Pull up the right-side door release lever, and then open the right-side door. 12-14 Di2510/Di3010/Di3510...
Page 281 Decreased copy quality may result if the surface of the image transfer roller is touched. § Be careful not to touch the surface of the image transfer roller. Image transfer roller Carefully pull out any misfed paper. Open the fusing unit guide. Di2510/Di3010/Di3510 12-15...
Page 282 If the paper is misfed as described below, contact your service representative: The paper is wrapped around the image transfer roller. The paper is folded or shredded by the image transfer roller. The paper that was removed tore and partly remains in the fusing unit. 12-16 Di2510/Di3010/Di3510...
Page 283 Touch Panel Messages Carefully pull out any misfed paper around the image transfer roller. Carefully pull out any misfed paper. Close the right-side door. Di2510/Di3010/Di3510 12-17...
Page 284: To Clear A Paper Misfeed In The Duplex Unit
Press down on the sliding plate with your left hand and carefully pull out any misfed paper. Return the multiple bypass tray to its original position. 12-18 Di2510/Di3010/Di3510...
Page 285: To Clear A Paper Misfeed In The 1St Or 2Nd Paper Drawer
Pull up the lower-right door release lever to open the lower-right door of the paper feed unit indicated in the touch panel message. Carefully pull out any misfed paper. Close the lower-right door. Close the multiple bypass tray. Di2510/Di3010/Di3510 12-19...
Page 286: To Clear A Paper Misfeed In The 3Rd Or 4Th Paper Drawer
To clear a paper misfeed in the 3rd or 4th paper drawer Pull up the lower-right door release lever to open the lower-right door of the paper feed unit indicated in the touch panel message. Carefully pull out any misfed paper. Close the lower-right door. 12-20 Di2510/Di3010/Di3510...
Page 287: To Clear A Paper Misfeed In The Large Capacity Cabinet
To clear a paper misfeed in the large capacity cabinet Pull up the lower-right door release lever to open the lower-right door of the paper feed unit indicated in the touch panel message. Carefully pull out any misfed paper. Close the lower-right door. Di2510/Di3010/Di3510 12-21...
Page 288: To Clear A Paper Misfeed In The Built In Finisher
Touch Panel Messages To clear a paper misfeed in the built in finisher Open the front door. Lower lever “FN1”, and then pull out any misfed paper. Turn knob “FN2”. 12-22 Di2510/Di3010/Di3510...
Page 289 If the punch kit is installed: Insert the punch box into its original position. Lower lever “FN4”. Turn dial “FN5” or dial “FN6”, and then pull out any misfed paper. Return lever “FN4” to its original position. Close the front door. Di2510/Di3010/Di3510 12-23...
Page 290: To Clear A Paper Misfeed In The Mail Bin Kit
Touch Panel Messages To clear a paper misfeed in the mail bin kit Open the front door. Turn dial “FN5” or dial “FN6”, and then pull out any misfed paper. While pressing down lever “FN7”, pull out any misfed paper. 12-24 Di2510/Di3010/Di3510...
Page 291 Touch Panel Messages Pull handle “FN8” to open the misfeed-clearing door. Pull out any misfed paper in the mail bin. Close the misfeed-clearing door. Close the front door. Di2510/Di3010/Di3510 12-25...
Page 292: To Clear A Paper Misfeed In The Saddle Kit
Turn dial “FN5” or dial “FN6”, and then pull out any misfed paper. Remove all paper from the paper output tray. Open the misfeed-clearing door, and then pull out any misfed paper. Close the misfeed-clearing door. Close the front door. 12-26 Di2510/Di3010/Di3510...
Page 293: When The Message "Cannot Staple." Appears
When the message “Cannot Staple.” appears, clear the jammed staples as described below. Not following the following procedure and forcefully pulling out the paper may result in damage to the “Stapler Unit”. Remove all paper from the finisher. Di2510/Di3010/Di3510 12-27...
Page 294 Touch Panel Messages Open the front door. Lower lever “FN1”, and then pull out any misfed paper. Turn dial “FN2”. If the punch kit is installed: Pull out the punch box. 12-28 Di2510/Di3010/Di3510...
Page 295 Insert the punch box into its original position. Lower lever “FN4”. Turn dial “FN5” or dial “FN6”, and then pull out any misfed paper. Return lever “FN4” to its original position. Turn the dial to the left to move the stapler toward the front. Di2510/Di3010/Di3510 12-29...
Page 296 Return the guide to its original position. Insert the staple cartridge holder until it locks into place. Close the front door. Note If stapling still cannot be performed, even after performing the above procedure, contact your service representative. 12-30 Di2510/Di3010/Di3510...
Page 297: When The Message "Hole Punch Collection Box Is Full." Appears
Follow the procedure described below to empty the punch box. To empty the punch box Empty and re-install the punch box as described below. Open the front door. Pull out the punch box. Di2510/Di3010/Di3510 12-31...
Page 298 Touch Panel Messages Empty the punch box. Insert the punch box into its original position. Close the front door. 12-32 Di2510/Di3010/Di3510...
Page 299: Troubleshooting
Make copies using only one selected with XXXXXXXX. used together are selected. of the functions. Pause. When making 2in1 copies, Position the second the second document page document page or press could not be scanned while [Finish]. scanning manually. Di2510/Di3010/Di3510 13-1...
Page 300 The total amount of jobs to Ask the administrator to clear jobs to be printed has been be printed as set by the the number of jobs to be reached. Please contact the administrator has been printed. administrator. reached. 13-2 Di2510/Di3010/Di3510...
Page 301: When Incorrect Copies Are Printed
The printed output is blurry. The paper is damp. Replace the paper. The document was not Position the document so pressed close enough that it is pressed closely against the original glass. against the original glass. Di2510/Di3010/Di3510 13-3...
Page 302 The printed page is curled. The paper that was used (as Remove the paper from the with recycled paper) curls paper drawer, turn it over, easily. and then load it again. Replace the paper with paper that is not damp. 13-4 Di2510/Di3010/Di3510...
Page 303 Otherwise, set Zoom to “Auto Size” to reduce the copy to the selected paper size. * If the problem is not corrected even after the operations described above are performed, contact your service representative. Di2510/Di3010/Di3510 13-5...
Page 304: When The Copier Is Not Operating Correctly
Close the breaker for the electrical circuit has been electrical circuit. tripped. * If the problem is not corrected even after the operations described are performed, turn off the copier,unplug its power supply cord, and the contact your service representative. 13-6 Di2510/Di3010/Di3510...
Page 305: Appendix
Appendix Appendix 14.1 Specifications Copier Di2510/Di3010/Di3510 Specification Type Desktop Platen Fixed platen (mirror scanning) Photo conductor Copying system Digital laser copying Developing system MTHG developing method Fusing system Heat-roller-fixing system Resolution 600 dpi Document Types: Sheets, books Size: Maximum A3 L, Weight: 3 kg Paper types •...
Page 306 Specification Di3510 First copy Less than 4.8 seconds (for A4 C paper loaded into the 1st drawer) Di3010/Di2510 Less than 5.3 seconds (for A4 C paper loaded into the 1st drawer) Di3510 Copy speed For A4 C paper loaded into the 1st drawer: 35 sheets/min.
Page 307: Duplexing Document Feeder Afr-19
— 182 mm B5 L — — — — 148 mm A5 L — — — — — — — 123 mm B6 L — — — — — — — 2: Copying possible —: Copying not possible Di2510/Di3010/Di3510 14-3...
Page 308: Duplex Unit Ad-16
A3 L, B4 L, A4 L/C, B5 L/C Paper capacity 500 sheets (80 g/m Power requirements Supplied by main unit Power consumption Less than 15 W Dimensions 570 mm (width) × 548 mm (depth) × 263 mm (height) Weight About 22 kg 14-4 Di2510/Di3010/Di3510...
Page 309: 2Way Paper Feed Cabinet Pf-210
Paper size A4 C Paper capacity 2,500 sheets (80 g/m Power requirements Supplied by main unit Power consumption Less than 45 W Dimensions 570 mm (width) × 564 mm (depth) × 263 mm (height) Weight About 26 kg Di2510/Di3010/Di3510 14-5...
Page 310: Built In Finisher Fn-117
• Plain paper (56 g/m to 90 g/m ): Maximum 200 sheets • postcards, envelopes, overhead projector transparencies, label sheets: Maximum 20 sheets Dimensions 282 mm (width) × 368 mm (depth) × 57 mm (height) Weight About 0.7 kg 14-6 Di2510/Di3010/Di3510...
Page 311: Mail Bin Kit Mk-1
445 (576) mm (width) × 203 (281) mm (depth) × 478 mm (height) (The values within parentheses are the measurements with a media tray installed.) Weight 9.3 kg Accessories 1 staple cartridge MS-2C (2,000 staples) Power requirements Supplied by finisher Di2510/Di3010/Di3510 14-7...
Page 312: Job Separator Js-203
Paper size A3 L, A4 L/C Paper capacity JS-203 100 sheets (80 g/m Copy output tray 250 sheets (80 g/m Dimensions 450 mm (width) × 443 mm (depth) × 75 mm (height) Weight About 1.7 kg 14-8 Di2510/Di3010/Di3510...
Page 313: Care Of The Copier
Note Pressing too hard on the operation panel or the touch panel may damage them. In addition, never use mild household detergent or glass cleaner to clean the operation panel or touch panel. Di2510/Di3010/Di3510 14-9...
Page 314 Appendix Original glass Clean the original glass by wiping it with a soft, dry cloth. 14-10 Di2510/Di3010/Di3510...
Page 315: Function Combination Table
Appendix 14.3 Function Combination Table Di2510/Di3010/Di3510 14-11...
Page 316 Appendix 14-12 Di2510/Di3010/Di3510...
Page 317 Appendix Di2510/Di3010/Di3510 14-13...
Page 318: Function Combination Codes
The function selected first is not performed if documents of mixed sizes are being copied. (*2) The function selected later is not performed if documents of mixed sizes are being copied. (*2) This setting cannot be selected since the “Booklet Creation” setting is selected. 14-14 Di2510/Di3010/Di3510...
Page 319 This setting cannot be selected since the “Book” setting cannot be selected. ■ A warning message should appear. ■ The settings can be selected, but either the function will automatically be cancelled or the function is not performed. Di2510/Di3010/Di3510 14-15...
Page 320: Paper Size And Zoom Ratio Tables
Quarto 8 in. × 10 in. 203 mm × 254 mm Statement Invoice 5-1/2 in. × 8-1/2 in. 140 mm × 216 mm 4 in. × 6 in. 4 in. × 6 in. 102 mm × 152 mm 14-16 Di2510/Di3010/Di3510...
Page 321: Zoom Ratios
257 mm × 364 mm × 0.577 10 in. × 14-1/4 in. × 0.707 × 0.500 × 1.154 × 0.816 182 mm × 257 mm × 0.577 7-1/4 in. × 10 in. × 0.707 × 1.640 × 1.154 × 1.414 Di2510/Di3010/Di3510 14-17...
Page 322 11 in. × 17 in. × 1.294 11 in. × 14 in. × 1.076 Letter Invoice × 0.647 8-1/2 in. × 11 in. 11 in. × 17 in. × 1.294 215.9 mm × 279.4 mm 11 in. × 14 in. × 1.272 14-18 Di2510/Di3010/Di3510...
Page 323 11 in. × 14 in. × 1.647 139.7 mm × 215.9 mm Legal × 1.545 Foolscap × 1.529 Letter × 1.294 Zoom ratio = Paper size/Document size 1 in. (inch) = 25.4 mm 1 mm = 0.0394 in. (inch) Di2510/Di3010/Di3510 14-19...
Page 324: Consumables
Note Only use toner that has been manufactured specifically for this copier. Do not throw away the used toner cartridges. Instead, keep them in their boxes to be collected by your service representative. 14-20 Di2510/Di3010/Di3510...
Page 325: Staple Cartridges
Appendix Staple Cartridges MS-5D for the finisher Staples for staple binding 5,000 staples are provided in the staple cartridge. MS-2C for the saddle kit Staples for staple binding 2,000 staples are provided in the staple cartridge. Di2510/Di3010/Di3510 14-21...
Page 326: Index
Auto size ................... 7-10 Automatically selecting the paper source ........... 9-6 Available functions and settings ............4-19 Basic copy operations ................. 5-1 Black-White reverse ................6-19 Book ..................11-20 11-25 Bound document ................11-23 Built in finisher ................1-8 14-6 14-22 Di2510/Di3010/Di3510...
Page 327 Corner staple ..................11-2 Cover mode ................. 6-1 Crease/Center staple .................7-29 Crisscross grouping ................11-5 Custom paper size ................9-14 Date and time ..................8-3 Default settings ..................4-17 Density ..................7-21 7-23 Distribution # ..................6-14 Document feed tray ................1-14 Document guides ................1-14 Di2510/Di3010/Di3510 14-23...
Page 328 ............10-4 File margin ..................6-8 Finisher ....................1-8 Free penalty ..................8-23 Front door ..................1-11 Function combination table ............. 14-11 Group ....................11-2 Hard disk drive ..................1-9 Hole punch ..................11-3 Hole punch setting ................11-8 14-24 Di2510/Di3010/Di3510...
Page 329 Lower-right door release lever ............1-14 Mail bin ....................1-15 Mail bin kit .................. 1-8 14-7 Making copies using accounts .............5-5 Memory ....................1-9 Memory recall ................4-24 Message display ................4-19 Messages ..................13-1 Meter count ..................7-33 Misfeed-clearing door .............. 1-15 1-16 Di2510/Di3010/Di3510 14-25...
Page 330 Paper guide ..................1-11 Paper misfeed 1st or 2nd paper drawer ............12-19 3rd or 4th paper drawer ............. 12-20 duplex unit ................. 12-18 duplexing document feeder ............12-12 finisher ..................12-22 fusing section ................12-14 large capacity cabinet ..............12-21 14-26 Di2510/Di3010/Di3510...
Page 331 Punch kit ..................1-9 14-7 Replacing the staple cartridge finisher ..................12-5 saddle kit ..................12-8 Replacing the toner bottle ..............12-2 Right-side door ..................1-11 Right-side door release lever .............1-11 Saddle kit ................1-8 1-16 14-7 Scanner dry ..................7-28 Screen tabs ..................4-19 Di2510/Di3010/Di3510 14-27...
Page 332 Toner bottle ..................14-20 Toner replenisher ................7-40 Touch panel ................1-11 4-17 Tray extension .................. 1-11 Turning the copier on and off ............4-12 Useful operations ................3-1 User management ................7-37 Utility mode ..................7-1 Watermark ..................6-16 14-28 Di2510/Di3010/Di3510...
Page 333 Appendix X/Y zoom setting ................11-17 Zoom ratios ..................14-17 Zoom setting ..................11-13 Di2510/Di3010/Di3510 14-29...
Page 334 Appendix 14-30 Di2510/Di3010/Di3510...

This manual is also suitable for:

Di3510 Di3010

Konica Minolta DI2510 Advanced Information

1 Introduction

2 Safety Information

3 Available Features

4 Before Making Copies

5 Basic Copy Operations

6 Auxiliary Functions

7 Utility Mode Operations

8 Administrator Management Operations

9 Copy Paper

10 Original Documents

11 Specifying Copy Settings

12 Touch Panel Messages

Quick Links

Related Manuals for Konica Minolta DI2510

Summary of Contents for Konica Minolta DI2510
