- Page 1 INSTALLATION MANUAL DF-601 Reverse Automatic Document Feeder Applied Machine: C450 for Product Code 4037 NOTE • Before installing, be sure to unplug the power cord of the machine. • Keep all packing materials out of the reach of children. 4582-7731-03...
- Page 2 DF-601 I Unpacking the Reverse Automatic Document Feeder Check that the following accessories are available in the box. 3. Place the Document Feeder in position. 1 Shoulder screw ..................2 NOTE 2 Mounting screw ..................2 When installing the Document Feeder, hold onto the upper and lower ends of the 3 Chart ......................1...
- Page 3 DF-601 I Adjusting the Document Feeding Tray Width 7. Narrow the width across the edge guides by 1. Plug the power cord into the power outlet sliding them to their minimum width. and turn on the machine. 2. Widen the width across the edge guides by sliding them to their maximum width.
- Page 4 DF-601 I Checking and Adjusting Document Skew I Checking and Adjusting the Document Feeding Tray Reference Posi- tion 1. Place the chart furnished with the Document Feeder in the document feeding tray (with 1. Place the chart furnished with the Document the side having an arrow facing up).
- Page 5 DF-601 I Adjusting the Document Stop Position 7. Make sure that “Adjustment Result” is “OK.” 1. Display the Service Mode screen. Then, touch “SET.” (For details of how to display the Service Mode screen, see the Service Manual.) 2. Touch “ADF.”...
- Page 6 DF-601 18. Turn OFF and ON the Main Power Switch. NOTE When displayed the Service Mode screen, be sure to turn off the main power after exiting the Service Mode screen and wait for 10 seconds or more before turning on.
