Page 146
Digital Interface (IEC 61162-1 Edition 2) Input sentences GGA, GLL, RMA, ZDA, RMC Schematic diagram 05P0356 CIF / NMEA RD-A RD-B Load requirements as listner Isolation Optocoupler Input impedance 480 ohms Max. Voltage Threshold 4 mA 1000p 1000p AP3-1 05P0355 PC317A 1SS133...
Page 147
GGA - Global positioning system (GPS) fix data AP3-2...
Page 148
GLL - Geographic position - latitude and longitude AP3-3...
Page 149
RMA - Recommended minimum navigation information - Loran C data AP3-4...
Page 150
RMC - Recommended minimum specific GPS/TRANSIT data ZDA - Data and time AP3-5...
