GT150 F1 specifications
Product overview
The Gateway GT150 F1 is solid tower or 4U rack mountable dual-socket server featuring powerful
computing and limited expandability. With up to 2 Intel Xeon 5600/5500 series processors, 12 DIMMs of
memory and a choice of 4 3.5" or 8 2.5" HDDs, this server offers everything you need and nothing you
don't.
Internal view
1
1 x 560 W 80 PLUS
2
2 x Intel® Xeon® X5600 series processors
3
12 x DDR3 ECC registered / unbuffered DIMMs
4
N+1 redundant cooling fans (internal), and 1 rear cooling fan (rear)
5
6 x PCIe expansion slots
6
3 x 5.25" media expansion bay
8
8 x 2.5" hot-swappable hard drive bays or
4 x 3.5" hot-swappable hard drive bays
Note: Availability may vary by region
®
gold-level efficient fixed power supplies
1
Advertisement
Related Manuals for Gateway GT150 F1
Summary of Contents for Gateway GT150 F1
- Page 1 GT150 F1 specifications Product overview The Gateway GT150 F1 is solid tower or 4U rack mountable dual-socket server featuring powerful computing and limited expandability. With up to 2 Intel Xeon 5600/5500 series processors, 12 DIMMs of memory and a choice of 4 3.5" or 8 2.5" HDDs, this server offers everything you need and nothing you don't.
- Page 2 GT150 F1 specifications Front View 4U Rackmount View Rear View Front I/O 2 x USB ports ID LED button Network, hard drive and power status indicators Rear I/O PS2 mouse and keyboard ports...
- Page 3 GT150 F1 specifications 4 x USB ports 2 x Gigabit LAN port (RJ-45) Video port Serial port System ID LED Management port (RJ-45) What's New • New Intel® Xeon® 5600 Series processors Intel Xeon X5675, X5672, E5649, E5645, E5607, E5606, E5603 ®...
- Page 4 GT150 F1 specifications Management • Gateway Smart Server Manager • System ID LED buttons, System Health LED • Gateway Smart Console for server management and KVM over IP remote management Deployment/Serviceability • Gateway Smart Setup • BIOS Update Tool • IPMI Firmware Update Tool Operating Systems ®...
- Page 5 GT150 F1 specifications Safety • UL/cUL • CB Nemko/GS Environmental Specifications Dimensions 434 (H) x 648 (D) x 178 (W) mm (17.2 x 25.5 x 7 inches) Weight Maximum 39 kg (88.1 lbs) Minimum (includes a single HDD, CPU and 28.5 kg (62.8 lbs)
- Page 6 GT150 F1 specifications Technical specifications ® PCIe specifications The primary I/O bus for the main board is PCIe Gen2. The following table lists the characteristics of the PCI-E bus segments. Details about each bus segment follow the table. NOTE: The signaling bit rate of PCI Express is 2.5Gbit/s one direction per lane for Gen 1 and 5.0Gbit/s one direction per lane for Gen 2.
- Page 7 Registered DDR3 1066 / 1333 MHz • Unbuffered DDR3 1066 / 1333 MHz • NOTE: Gateway does not qualify mixed memory configurations of memory type, capacity or make. Population Gateway’s validated memory populations are listed below. NOTE: Support for 8 / 16 GB DIMMs may vary by regional availability.
- Page 8 GT150 F1 specifications Dual processor configuration guide NOTE: Quad Rank DIMMs and Unbuffered DIMMs can only use a maximum of 6 slots per CPU (12 slots total) DIMM CPU 1 CPU 2 * support depends on 8GB/16GB DIMM available Mirroring mode: For mirroring mode, the memory contains a primary image and a copy of the primary image.
- Page 9 GT150 F1 specifications Sparing mode: In this mode, if system detects degrading memory and system still not crash, the data in failed channel • will be copied to spare channel. Failed channel is then isolated and spare channel becomes active. But if any uncorrectable error happens before the isolation, it will still cause the system stop normal operation.
- Page 10 GT150 F1 specifications Power specifications 560W Power Supply Operational Input 100 to 240 Voltage Range (Vrms) Frequency 60/50 Range (Nominal) (Hz) Nominal Input Voltage (Vrms) Max. Rated Output Wattage (Watts) Nominal Input Current (A rms) Max. Rated Input Wattage Rating (Watts) Max.
- Page 11 DVD or a downloadable file to be put into a USB 2.0 device, and eases the deployment of Gateway servers for any certified OS. Through its unique interface, users may select to have all the correct...
- Page 12 GT150 F1 specifications Available options Processors (up to 2) Intel® Xeon® processor (Six Core) X5675 (12 MB L3 cache, 3.06 GHz, DDR3-1333 MHz, 95W) X5670 (12 MB L3 cache, 2.93 GHz, DDR3-1333 MHz, 95 W) X5660 (12 MB L3 cache, 2.80 GHz, DDR3-1333 MHz, 95 W) X5650 (12 MB L3 cache, 2.66 GHz, DDR3-1333 MHz, 95 W)
- Page 13 GT150 F1 specifications Memory Memory type Registered / Unbuffered DDR3 ECC memory Capacities 1 / 2 / 4 / 8 / 16 GB DIMMs DIMM number Max memory 192 GB (48 GB unbuffered) Hard drives Type Interface, bandwidth Capacities (RPM) Enterprise SATA, 2.5”...
- Page 14 GT150 F1 specifications RAID cards Model Port number RAID support ® MegaRAID SAS 9240-4i 4 internal ports 0, 1, 5, 10 ® MegaRAID SAS 9260-8i* 8 internal ports 0, 1, 5, 6, 10, 50, 60 ® Flex I/O, LSI SAS 2108*...
- Page 15 GT150 F1 specifications Model Tape capacity Form factor LTO Ultrium-3, 3Gb/s SAS 400/800 GB External 1U rack LTO-4, 3Gb/s SAS 400/800 GB External 1U rack LTO Ultrium-3, 3Gb/s SAS 400/800 GB Internal 5.25” half-height LTO-4, 3Gb/s SAS 400/800 GB Internal 5.25” half-height...
- Page 16 GT150 F1 specifications Service and support Gateway Servers offer a comprehensive service suite to take care of daily IT needs. Users can select the 3- year standard warranty or choose extended warranties and services. In a continuing effort to improve the quality of our products, information in this document is subject to change without notice.
