In the Cursor Mode, you are provided with a cursor that can be moved on the
map. At the bottom of the display is the information for the position of the
cursor relative to your present position. Also any points
of interest that the cursor is over will be shown.
To access the Cursor Mode, press any arrow on the
keypad. A crosshair appears that can be moved with the
arrow keys.
To return to the Position Mode, press
will disappear and the present position icon will appear
centered on the map.

Compass Screen.

fingertips while you are navigating. It is totally customizable to
display the information that is useful to you. The lower portion
of the Compass screen not only displays your heading in a
graphical manner, but also displays the relationship of the sun,
moon and your destination (if navigating on a route) to your
heading.

Large Data Screen.

The Large Data screen is similar to the
Compass screen but here the compass has been removed to
allow for large display of the navigation data. Ideal for when
you have your MAP 330 mounted on the dashboard of a boat
using the optional swivel mounting bracket. Even from a
distance the information can be read with ease.

Position Screens.

present position using the coordinate systems that you have
selected in Setup. This screen shows all of the basic position,
time and satellite information. In addition current navigation
information is shown on the bottom half of the screen.
Magellan MAP 330 GPS Receiver
. The cursor
ESC
This is a handy screen to have at your
The Position screens 1 and 2 display your
Basic Operation
Basic Operation
13
