- Page 1 Parts Manual Dryer Model: GDZ5.0-61WH HA AA Product Code: 61401-A 61401-A...
- Page 2 61401-A...
- Page 3 61401-A - NOVEMBER 2009 REPRINT - APRIL 2013 PRODUCT Brand Haier Voltage 220-240V, 50Hz Model GDZ5.0-61 WH HA AA Product Code 61401-A Fisher & Paykel Appliances Ltd 78 Springs Road, East Tamaki, PO Box 58-732, Botany, Manukau 2163, New Zealand...
- Page 4 61401-A...
- Page 5 61401-A CONTENTS DRYER.............................. 6...
- Page 6 61401-A DRYER...
- Page 7 61401-A DRYER PART DESCRIPTION H0030100496 BACK COVER H0030300285 FRICTIONAL SLICE OF DRYER H0030300300 FELT (FRONT) H0030600085 SINKING TAPPING SCREW H0030100498 BARREL ROLL SUPPORT H0030203613 CONNECTOR H0030600085 TAPPING SCREW H0030100561 SAFEGUARD NETTING H0030203637 PTC RETAINER H0030600174 SCREW H0034000637 TEMPERATURE-CONTROLLED INSTRUMENT H0034000639B PTC HEATER H0030203641 PTC SUPPORT...
- Page 8 61401-A DRYER...
-
Page 9: Tapping Screw
61401-A DRYER PART DESCRIPTION H0030300337 LONG SEAL GASKET H0030203623 FILTER SCREEN HOLDER H00330818001 H0030600168 GASKET H0030203612 FLANGE SUPPORT H00330810009 TAPPING SCREW H0030203867 WHISK LEAF H00330810005 TAPPING SCREW H00330810005 TAPPING SCREW H0030806983A BARREL ROLL COMPONENT H0030300301 WOOL FELT (REAR) H0030203391 GASKET H0030203443 GASKET H0030600151... - Page 10 61401-A DRYER...
- Page 11 61401-A DRYER PART DESCRIPTION H0030600172 SCREW H00330506006 CAPACITOR H0030100541 MULTI-WEDGE BELT WHEEL H00330802005 TAPPING SCREW H00330802500 TAPPING SCREW H0030203344 BELT PULLEY H0030100524 TIGHTEN SPRING H0030600152 GASKET H0030203444 GASKET H0030804218 FASTEN WHEEL PARTS H0030600154 GASKET H0030400272 POWER CORD H00330802005 TAPPING SCREW H00330802005 TAPPING SCREW H00330802005...
