- Page 1 Exhaust Type Tumble Dryer GDZ3.5-61 GDZ5.0-61 Please read this manual carefully before using. Retain it for future reference. User's Manual...
-
Page 2: Important Safety Instructions
Important Safety Instructions Warning-To reduce the risk of fire ,electric shock, or injury to persons when using your appliance, follow basic precautions, including the following: 1.Read all instructions before using the appliance. 2.The tumble dryer is not to be used if chemicals have been used for cleaning. 3.The tumble dryer is intended only for drying textile material washed in water. - Page 3 Important Safety Instructions 13.Do not allow children to play on, climb on or in the appliance. Close supervision of children is necessary when the appliance is used near children. 14.Before the appliance is removed from service or discarded, remove the door to the drying compartment.
- Page 4 Important Safety Instructions 24.When normally using, the power cord of dryer shall be easily plugged or unplugged by hand. It must be unplugged during power blackout, moving, not in use or cleaning. Do not plug or unplug the power cord with wet hands. 25.Always disconnect dryer from electrical supply before attempting any service.
-
Page 5: Names Of The Parts
Names Of The Parts Drum Exhaust Shroud Door Window Timer Selector Knob Air Intake Shroud Heat Selector Knob Door Gasket Power Cord Exhaust Vent Casing Back Cover Please check if the power receptacle has good earthing Condition before using to guarantee your safety. The manufacturer will not take responsibility for those Risks occurred from not obeying this manual. -
Page 6: Operation Cautions
Operation Cautions Clothes with ribbon or lace should be dried in a nylon net Put chemical fiber and/or clothes with ribbon or lace into a nylon net before drying. Clothes with zipper Dry this kind of clothes with zipper zipped or fastener buckled and inside out (to reduce the impact noise between... -
Page 7: Installation Instructions
Installation Instructions For your safety and correct using your dryer, please observe all the instructions in this manual toinstall and adjust your dryer. Location of your dryer Dryer should be located in a dry and well-vented place, not filled with moisture and vapors and where rain cannot reach (like bathroom,open balcony and water faucet). -
Page 10: Using Method
Using Method 1. Plug the power cord The appliance shall be supplied with220- 240V,50Hz, connected to a special receptacle more than 10A (reliably grounded). 2. Place the dehydrated clothes in your dryer Check the following items before putting clothes in. They shall be loaded in such a way that 2-3 pieces each time and not in a group to avoid tangling, which is not easy to turn it over resulting in uneven drying... - Page 11 Using Method 3. Control panel and its functions Heat Selector Knob Select drying level according to the material, quantity and drying requirements of the clothes to be dried as shown in the figure Select strong Dry for clothes particularly thick and in large quantities or in lower room temperature.
- Page 12 Using Method 4. Set heat selector knob to select Strong dry or Soft dry level. Strong dry level for large quantity and low room temperature. Soft dry for non heat-resistant clothes. 5. Dry time settings Select dry program according to clothes materials and quantity, turn the timer knob to relative position.
-
Page 13: Dry Capacity Dry Time Reference Table
Approx.200min Dry time Suggest use ' strong ' Suggest use ' strong ' Approx.90min Approx.150min Soft GDZ3.5-61 GDZ5.0-61 GDZ5.0-61 Model Dry time affected by many factors, such as material, weight, thickness and the hydrated ratio of clothes , the above listed dry time is only for reference. -
Page 14: Care And Cleaning
Care And Cleaning Clean the buildup such as lints on filters in time after each use, otherwise it will affect the performance of your dryer. Please unplug the power cord first when cleaning it. Cleaning of filters The lint filter must be used for drying. It must be cleaned in time befor and after each use. -
Page 15: Troubleshooting
Trouble Shooting Trouble Shooting (If your dryer exhibits problems, please unplug the power cord before checking) The following maybe unrelated to a malfunction of the dryer itself, please reconfirm before calling a serviceman. If it does relate to a malfunction, please contact our service agent or after-sales service and do not repair it by yourself. -
Page 16: Specification
Rated Input Power Rated Fuse Current Rated Max. Capacity Overall Dimension Net Weight 220-240V 50Hz Extra 1020W Light Extra 1070W Light 3.5kg 5.0kg 630mm 425mm 685mm 630mm 515mm 685mm 23kg 26.5kg Model 670W GDZ3.5-61 700W GDZ5.0-61 GDZ3.5-61 GDZ5.0-61 GDZ3.5-61 GDZ5.0-61 GDZ3.5-61 GDZ5.0-61...
