M
Figure 54
NOTE: Front location holes are shown. Corresponding rear holes will also
need to be marked.
4. Drill all the new holes with a #30 drill bit.
5. Remount the slide.
RE-INSTALLATION OF DRAWER
CAUTION
Use care when handling the drawer. Drawer edges, drawer
rail and the unit's slide may be sharp.
1. Set the drawer's rails onto the slides.
2. Re-install the rails' mounting screws (Figure 55).
Figure 55
3. Plug in the drawer's connection wiring (top drawer only).
a k r a d n D l l i r N e w
M u o i t n g n H l o s e
P u h s i l S e d
U p w a d r r o
D o w n w a d r
ULIN_0325_A
M u o i t n g n
c S e r w
ULIN_0313_A
Section 3 - Service and Repair
3-53
