- Page 1 Installation Guide ® 2115WC Wine Captain ® and 2115WCOL2 Wine Captain with Overlay www.U-LineService.com Phone (414) 354-0300 • FAX (414) 354-7905 Service & Parts Tech Lines Phone (800) 779-2547 • FAX (414) 354-5696 OnlineService@U-Line.com ©2008 U-Line Corporation 03/2008...
-
Page 2: Table Of Contents
2115WC/2115WCOL2 Wine Captain ® Contents 1 Follow Safety Precautions 1-Follow Safety Precautions ..... 2 2-Inspect and Plan ......3 IMPORTANT Exterior Cleaning . -
Page 3: 2-Inspect And Plan
2115WC/2115WCOL2 Wine Captain ® General Precautions 2 Inspect and Plan Use this appliance for its intended purpose only and follow these general precautions along with those listed You have received a carton containing your 2115WC or throughout this guide: ® 2115WCOL2 Wine Captain with a package inside containing a Use and Care Guide, a Product Registration... -
Page 4: Exterior Cleaning
Stainless Steel Polish and Cleaner or comparable product or a mild detergent and warm water solution and soft Your U-Line product has been designed for either free- cloth. Do NOT use abrasive cleaning agents. standing or built-in installation. When built-in, your unit does not require additional air space for top, sides or rear. -
Page 5: Product Dimensions
Figure 2 Environmental Requirements Please note that the unit has adjustable feet that can add Many U-Line models are designed to operate in harsh one additional inch to height during leveling or to match outdoor/marine environments. Special considerations adjacent cabinets (see Figure 26 on Page 13). -
Page 6: Side-By-Side Installation Instructions
For a complete refreshment center, install your 2115WC or trimmed wine racks that are coated at the factory with a 2115WCOL2 unit beside a U-Line Refrigerator, Ice Maker clear vinyl sealer, which will adequately protect the wood or Combo Model (see Figure 4 for typical cut-out). Note in normal usage. -
Page 7: Wood Trim Finishing
4. Allow stain to dry for a minimum of three hours before applying the final finish. Interior components of your U-Line unit are equipped 5. If desired, sand the wood with very fine sandpaper to with a natural wood trim for appearance and durability. -
Page 8: Reversing The Door
2115WC/2115WCOL2 Wine Captain ® Reversing the Door (Black Units Only) All U-Line units (except Stainless Steel models) may be Door Closer left- or right-hand Inserts opening. The door opening is easily reversed by moving the hinge hardware ULIN_0003_A to the opposite side. -
Page 9: Overlay Frame
2115WC/2115WCOL2 Wine Captain ® Overlay Frame 1. Use the following instructions to create or have a wood overlay panel created for your Échelon Wine FRAME PREPARATION Captain or Beverage Center model as shown in Figure IMPORTANT 2. Drill holes for pivot pins, upper door hinge and lower The thickness of the wood overlay panel must be door hinge as shown. -
Page 10: Prepare The New Overlay Panel
2115WC/2115WCOL2 Wine Captain ® PREPARE THE NEW OVERLAY PANEL IMPORTANT The overlay door panel must not weigh more than 20 lbs. The thickness of the door panel must be 3/4". 1. Place a towel, or other similar, soft, non-marking material out on a flat clean surface. Be sure the material is large enough to have the wood panel not touch the hard, marking surface. -
Page 11: Assembling Door To Cabinet
2115WC/2115WCOL2 Wine Captain ® 15. Check the closure assembly on the bottom hinge to be sure it is seated correctly in the bosses in the hinge. DOOR FRAME 16. Position door over closer. Be sure the door hinge plate holes align with the bosses on the closer (Figure 19). TAPE Failure to do so will result in the door not sitting in the proper position and door will not align correctly. -
Page 12: Checking Door Alignment
2115WC/2115WCOL2 Wine Captain ® 5 Adjust Door Checking Door Alignment Slotted Mounting The unit’s door is aligned at the factory before shipment. Holes However, its alignment could have been disturbed during Angled Edge Towards Center shipment or during overlay frame installation. of Door IMPORTANT Properly aligned, the door should be 1/8"... -
Page 13: 6-Prepare Power Supply
2115WC/2115WCOL2 Wine Captain ® 6 Prepare Power Supply 7 Level the Unit Electrical Specifications Leveling Information Note: It is recommended that the unit is level. CAUTION 1. Use a level to check the Electrical installation must observe all state and local levelness of the codes. -
Page 14: 8-Install The Unit
2115WC/2115WCOL2 Wine Captain ® 8 Install the Unit Anti-Tip Bracket Installation 1. Locate two Anti-Tip Brackets included inside the unit. 2. Place the unit into the area where it will be installed. Check the door, sides and top for a proper fit. Also test to make sure the door opens and closes freely. -
Page 15: Single Unit Installation
2115WC/2115WCOL2 Wine Captain ® Single Unit Installation surface should be approximately 1/8" below the countertop. 1. Remove the two screws from the opposite side of the Installation Troubleshooting hinge assembly using a Phillips screwdriver (Figure 30). Problem Right–handed units shown, Left–handed units are mirrored The door remains open unless it is pushed closed. -
Page 16: Who To Call
