Introducing the ProCurve Wireless Access Point 530
Top of the Access Point

LEDs

Table 1-1.
Access Point State
LEDs
Power On
(green)
Off
LAN Off
(green)
Blinking or
On
Radio 1 (11b/g) Off
Radio 2 (11a/b/g)
(green)
Blinking or
On
1-4
Access Point LEDs
Meaning
The access point is receiving power.
The access point is NOT receiving power.
The RJ-45 port has no network cable connected, or is not receiving a link signal.
The RJ-45 port has a link indication from a 10 Mbps or 100 Mbps device and is
transmitting or receiving traffic. The LED blinking rate is proportional to the traffic
rate. If there is no traffic, the blinking rate will be once every five seconds. As the
traffic rate increases, the blinking rate also increases until the LED is solid on, which
indicates there no available bandwidth on the port.
The wireless interface is disabled, either through the access point console or the
Web browser interface.
The wireless interface is enabled and transmitting or receiving traffic. The LED
blinking rate is proportional to the traffic rate. If there is no traffic, the blinking rate
will be once every five seconds. As the traffic rate increases, the blinking rate also
increases until the LED is solid on, which indicates there no available bandwidth
on the interface.
