Supported Antennas

The following table lists the available antennas for the ProCurve Wireless
Access Point 530:
J8441A
J8444A
J8448B*
J8997A
J8999A
J8998A
J9000A
* A point-to-point antenna, accompanied with a pigtail cable, a 10 ft extension cable (model
LMR-400), and a lightning arrester, which should be connected.
C A U T I O N
■
■
■
C-16
HP Product Number Frequency Range (GHz)
2.4-2.5
2.4-2.5
2.4-2.5
2.4-2.5
4.9-5.99
2.4-2.5
4.9-5.99
5.15-5.875
5.15-5.875
When using antennas outdoors, a lightning arrestor is required for light-
ning protection. Consider placing the lightning arrestor immediately
before the antenna cable enters the building. ProCurve Networking offers
a lightning arrestor as an accessory; it is orderable under HP product
number J8996A.
All ProCurve Networking devices are designed to be compliant with the
rules and regulations in locations they are sold and will be labeled as
required. Any changes or modifications to ProCurve Networking equip-
ment, not expressly approved by HP, could void the user's authority to
operate this device. Use only antennas approved for use with this device.
Unauthorized antennas, modifications, or attachments could cause
damage and may violate local radio regulations in your region.
When using external antennas, users must ensure that the combined
transmit power and antenna gain does not exceed the maximum Equiva-
lent Isotropic Radiated Power (EIRP) for your region. For maximum RF
power settings by country/region, see the documentation for your access
point at www.procurve.com/manuals.
Antenna Type Actual Gain (dBi)
Omni 4.4
Omni 7.4
Yagi 13.8
Omni 3/4
Directional 6.9/7.7
Omni 6.3
Directional 13.3
