- Page 1 GAS RANGE Use & Care Guide For questions about features, operation/performance, parts, accessories or service, call: 1-800-843-0304 or visit our website at... www.amana.com Table of Contents ..........2 W10531343B...
-
Page 2: Table Of Contents
TABLE OF CONTENTS RANGE SAFETY ................3 Positioning Racks and Bakeware ..........9 The Anti-Tip Bracket ..............4 Bakeware..................10 Oven Vent ...................10 BATTERY USE ................5 Baking and Roasting ..............10 Installing/Replacing the Battery ...........5 Broiling..................10 Battery Status Indicator ...............6 RANGE CARE ................11 COOKTOP USE ................7 Cooktop/Oven Temperature Controls .........7 Removing the Oven Bottom............11 Surface Burners ................8... -
Page 3: Range Safety
RANGE SAFETY Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the safety alert symbol. This symbol alerts you to potential hazards that can kill or hurt you and others. All safety messages will follow the safety alert symbol and either the word “DANGER”... -
Page 4: The Anti-Tip Bracket
The Anti-Tip Bracket The range will not tip during normal use. However, the range can tip if you apply too much force or weight to the open door without the anti-tip bracket fastened down properly. WARNING Tip Over Hazard A child or adult can tip the range and be killed. Verify the anti-tip bracket has been properly installed and engaged per installation instructions. -
Page 5: Battery Use
BATTERY USE Installing/Replacing the Battery 3. Using a Phillips screwdriver, remove the metal battery top from the bottom of the range and open the plastic battery box. A. Battery holder location 4. Remove the battery holder and insert a new 9V DC alkaline battery into it. -
Page 6: Battery Status Indicator
5. Replace the battery holder in the plastic battery box with the battery facing the bottom and the blue wires facing up, and Battery Status Indicator close the plastic battery box. The battery status indicator on the control panel will show the recommended time to replace the battery. -
Page 7: Cooktop Use
COOKTOP USE This manual covers several different models. The range you have purchased may have some or all of the items listed. The locations and appearances of the features shown here may not match those of your model. BATTERY STATUS BROIL PUSH TO TURN PUSH TO TURN... -
Page 8: Surface Burners
3. Clean the gas tube opening with a damp cloth. Surface Burners 4. Clean clogged burner ports with a straight pin as shown. Do not enlarge or distort the port. Do not use a wooden toothpick. If the burner needs to be adjusted, contact a trained repair specialist. -
Page 9: Oven Use
Use the following chart as a guide for cookware material COOKWARE CHARACTERISTICS characteristics. Copper Heats very quickly and evenly. COOKWARE CHARACTERISTICS Earthenware Follow manufacturer’s instructions. Aluminum Heats quickly and evenly. Use on low heat settings. Suitable for all types of cooking. Porcelain See stainless steel or cast iron. -
Page 10: Bakeware
Bakeware Baking and Roasting The bakeware material affects cooking results. Follow IMPORTANT: To avoid damage to the interior finish, do not place manufacturer’s recommendations and use the bakeware size food or cookware directly on the oven door or the oven bottom. recommended in the recipe. -
Page 11: Range Care
BROILING CHART COOK TIME For best results, place food 3" (7.0 cm) or more from the broil (in minutes) element. Times are guidelines only and may need to be adjusted FOOD SIDE 1 SIDE 2 for individual foods and tastes. Ham slice, precooked COOK TIME "... - Page 12 CONTROL PANEL OVEN DOOR EXTERIOR To avoid damage to the control panel, do not use abrasive Cleaning Method: cleaners, steel-wool pads, gritty washcloths or abrasive paper Glass cleaner and a soft cloth or sponge: towels. Apply glass cleaner to soft cloth or sponge, not directly on Cleaning Method: panel.
-
Page 13: Oven Door
Oven Door For normal range use, it is not suggested to remove the oven To Replace: door. However, if removal is necessary, make sure the oven is off 1. Grasp the door on the sides with your fingers on the front of and cool. -
Page 14: Troubleshooting
TROUBLESHOOTING Try the solutions suggested here first in order to avoid the cost of an unnecessary service call. Nothing will operate Cookware not level on cooktop Is the main gas shutoff valve in the off position? Is the range level? See the Installation Instructions. -
Page 15: Assistance Or Service
® replacement parts will fit right and work right because they are Appliances with any questions or concerns at: ® made with the same precision used to build every new Amana Amana Customer Service appliance. 553 Benson Road To locate factory specified replacement parts in your area, call us Benton Harbor, MI 49022-2692 or your nearest designated service center. -
Page 16: Warranty
If you need service, first see the “Troubleshooting” section of the Use & Care Guide. After checking “Troubleshooting,” you may find additional help by checking the “Assistance or Service” section or by calling Amana. In the U.S.A., call 1-800-843-0304. In Canada, call 1-800-807-6777.
