CDA-7965
CDA-7864
CDA-7863
CDA-7862
FM/AM Compact Disc Player
FM/AM Compact Disc Receiver
• OWNER'S MANUAL
Please read before using this equipment.
• MODE D'EMPLOI
Veuillez lire avant d'utiliser cet appareil.
• MANUAL DE OPERACIÓN
Léalo antes de utilizar este equipo.
ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD.
6-8 Fiveways Boulevarde Keysborough,
Victoria 3173, Australia
Tel.: (03) 9769-0000
ALPINE ELECTRONICS GmbH
Kreuzerkamp 7-11 40878 Ratingen, Germany
Tel.: 02102-45 50
ALPINE ITALIA S.p.A.
Via C. Colombo 8, 20090 Trezzano Sul Naviglio
MI, Italy
Tel.: 02-48 47 81
R
(CDA-7965)
ALPINE ELECTRONICS FRANCE S.A.R.L.
(RCS PONTOISE B 338 101 280)
98, Rue De La Belle Etoile, Z.I. Paris Nord Il
B.P. 50016 F-95945, Roissy, Charles De Gaulle
Cedex, France
Tel.: 01-48 63 89 89
ALPINE ELECTRONICS OF U.K., LTD.
13 Tanners Drive, Blakelands, Milton Keynes
MK14 5BU, U.K.
Tel.: 01908-61 15 56
ALPINE ELECTRONICS DE ESPAÑA, S.A.
Portal De Gamarra 36, Pabellón 32
01013 Vitoria (Alava)-Apdo. 133, Spain
Tel.: 34-45-283588
Designed by ALPINE Japan
EN
FR
ES
ES
IT
SE
Printed in China (Y)
68P01149K88-O

Advertisement

Table of Contents
loading

Related Manuals for Alpine CDA-7965

Summary of Contents for Alpine CDA-7965

  • Page 1 Veuillez lire avant d'utiliser cet appareil. • MANUAL DE OPERACIÓN Léalo antes de utilizar este equipo. (CDA-7965) ALPINE ELECTRONICS, INC. ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD. ALPINE ELECTRONICS FRANCE S.A.R.L. Tokyo office: 1-1-8 Nishi Gotanda, 6-8 Fiveways Boulevarde Keysborough, (RCS PONTOISE B 338 101 280)
  • Page 2 More musical selections, more versatility, more convenience. An Alpine CD Changer adds more musical choices to your sound system. All models can be controlled from Alpine head units and deliver excellent sound quality. The CHA-S624 is a high-performance 6-disc changer with a new M DAC, Ai-NET compatibility, Optical Digital Output, 150 Disc Title Memory and CD TEXT.

  • Page 3: Table Of Contents

    Selecting BBE Mode ........5 Remote Control Operation Displaying Time ..........6 Controls on Remote Control Setting Time ............6 (CDA-7965/CDA-7864/CDA-7863 only) ... 18 Dimmer Control ..........6 Battery Replacement ........19 Subwoofer On and Off ........7 Information Sound (Beep) Guide Function ......7 In Case of Difficulty ........

  • Page 4: Warning

    HALT USE IMMEDIATELY IF A PROBLEM APPEARS. YOUR ATTENTION AWAY FROM SAFELY DRIVING Failure to do so may cause personal injury or damage to the product. Return it to your authorized Alpine dealer or YOUR VEHICLE. the nearest Alpine Service Center for repairing.
  • Page 5 Using such accessories can cause the mechanism. disc to be out of standard specifications and may create operational problems. We recommend not using these accessories on discs played in Alpine CD players. Transparent Sheet Disc Stabilizer...

  • Page 6: Basic Operation

    MUTE Detaching the Front Panel Remote Controllable (CDA-7862 only) This unit can be controlled with an optional Alpine Press the PWR (Power) button for more than 3 remote control. For details, consult your Alpine seconds to turn off the power.

  • Page 7: Display Angle Adjustment

    Display Angle Adjustment Turning Loudness On/Off Movable display Loudness introduces a special low- and high- frequency emphasis at low listening levels. This compensates for the ear's decreased sensitivity to bass and treble sound. Press and hold the MODE (Audio Control) knob The movable display may be adjusted to 3 for at least 2 seconds to activate or deactivate different angles depending upon user preference.

  • Page 8: Displaying Time

    Basic Operation MODE INTLZ TUNE DN g f UP Displaying Time Dimmer Control Press the CLK (clock) button repeatedly until the Set the DIMMER control to AUTO to decrease the illumination brightness of the unit with the head time is displayed. lights of the vehicle ON.

  • Page 9: Subwoofer On And Off

    Subwoofer On and Off Turning Mute Mode On/Off Press and hold the INTLZ button for more than 2 If a device having the interrupt feature is seconds. connected, audio will be automatically muted whenever the interrupt signal is received from the Press the f UP button repeatedly to select device.

  • Page 10: Setting The Aux Mode

    Basic Operation MODE INTLZ/DISP SOURCE A.PROC BLACK OUT TUNE DN g f UP Setting the AUX Mode Demonstration You can input TV/video sound by connecting an This unit has the Demonstration feature which optional Ai-NET/RCA Interface cable (KCA-121B) simulates the display functions on the display panel. to this component.

  • Page 11: Blackout Mode On And Off (Cda-7965 Only)

    2. BW (Setting the Bass Band Width): Blackout Mode On and Off (Q-Factor) → WIDE1 → WIDE2 → WIDE3 → WIDE4 (CDA-7965 only) (Narrow) ← ......... → (Wide) When the Blackout mode is turned on, the CFL Changes the displayed frequency’s band width display will turn off to reduce power consumption.

  • Page 12: Displaying The Title/Text

    Basic Operation TITLE T.S.M. MODE DN g - / J f UP Displaying the Title/Text CD/Changer mode: ↓ ELAPSED TIME DISPLAY It is possible to display the CD/Station title if the ↓ title has been previously inputted. For details, see CLOCK DISPLAY ↓...

  • Page 13: Titling Discs/Stations

    Titling Discs/Stations Searching for Titled Discs/Stations It is possible to title your favorite CD's or radio If a CD/Station is titled, you can do a search for it. stations. (To title CDs or Stations, refer to "Titling Discs/ Stations" on page 11.) Press the TITLE button and select the title display mode.

  • Page 14: Radio Operation

    Radio Operation Preset buttons (1 through 6) BAND SOURCE TUNE/A.ME D.A.P. DN g f UP Manual Tuning Automatic Seek Tuning Press the SOURCE button until a radio Press the SOURCE button until a radio frequency appears in the display. frequency appears in the display. Press the BAND button repeatedly until the Press the BAND button repeatedly until the desired radio band is displayed.

  • Page 15: Manual Storing Of Station Presets

    Manual Storing of Station Presets Storing into Direct Access Preset (D.A.P.) Band Select the radio band and tune in a desired radio station you wish to store in the preset memory. A combination of radio stations in any band (up to Press and hold any one of the Preset buttons (1 6 stations) can be manually preset into the D.A.P.

  • Page 16: Mono/Stereo Switching

    Radio Operation MONO Mono/Stereo Switching Press the "F" button to illuminate the FUNC (Function) indicator. "ST" indicator appears when a stereo FM station is tuned in. Press the MONO button to switch from stereo to monaural FM reception. This will help in reducing the noise of weak FM Stereo broadcasts.

  • Page 17: Cd Player Operation

    CD Player Operation SOURCE - / J DN g f UP Insert a disc with the label side facing up. Opening and Closing the Movable The disc will be pulled into the unit automatically. display The movable display will close and playback will begin.

  • Page 18: Fast Forward And Backward

    CD Player Operation SOURCE BAND Disc Select buttons (1 through 6) DN g f UP M.I.X. SCAN NOTES Fast Forward and Backward • If a CD Changer equipped with the ALL M.I.X. function is connected, ALL M.I.X. will also be selectable. Press and hold the DN g or f UP button to In this mode, the tracks on all the CDs in the current quickly move backward or forward until you...

  • Page 19: Controlling Cd Changer (Optional)

    Controlling CD Changer (Optional) Multi-Changer Selection An optional 6-disc or 12-disc CD Changer may be Alpine's Ai-NET system will support up to 6 CD connected to the CDA-7965/CDA-7864/ Changers. When operating two or more changers, CDA-7863/CDA-7862 if it is Ai-NET compatible.

  • Page 20: Remote Control Operation

    PROG RUE-4185 REMOTE CONTROL UNIT " Controls on Remote Control (CDA-7965/CDA-7864/CDA-7863 only) 8 g Button 1 Mute Button Radio mode: SEEK (DN) Button Press the button to lower the volume by 20 dB CD mode: Press the button to go back to the instantly.

  • Page 21: Battery Replacement

    Battery Replacement Applicable battery: Use two "AAA" sized dry batteries or equivalent. Opening the battery cover Slide out the battery cover while firmly pressing outward. Replacing the battery Put the batteries in the case observing the polarities as illustrated. Closing the cover Push the cover as illustrated until a click is heard.

  • Page 22: Information

    Otherwise, cool. make sure the rest of your system is properly CD playback sound is wavering. connected or consult your authorized Alpine dealer. • Moisture condensation in the CD Module. - Allow enough time for the condensation to evaporate Basic (about 1 hour).

  • Page 23: Specifications

    ERROR - 01 Capture Ratio 2.0 dB AM TUNER SECTION • Malfunction in the CD Changer. - Consult your Alpine dealer. Press the magazine eject Tuning Range 530 – 1,710 kHz button and pull out the magazine. Sensitivity (IEC Standard) 22.5 µV/27 dB...

  • Page 24: Installation And Connections

    DO NOT USE BOLTS OR NUTS IN THE BRAKE OR CDA-7863/CDA-7862 to the fuse box, make sure the fuse STEERING SYSTEMS TO MAKE GROUND for the intended circuit of the CDA-7965/CDA-7864/CDA- CONNECTIONS. 7863/CDA-7862 has the appropriate amperage. Failure to do so may result in damage to the unit and/or the vehicle.

  • Page 25: Installation

    Installation Connect each input lead coming from an amplifier or equalizer to the corresponding output lead coming from the left rear of the CDA-7965/CDA-7864/CDA- Metal plate 7863/CDA-7862. Connect all other leads of the CDA- 7965/CDA-7864/CDA-7863/CDA-7862 according to details described in the CONNECTlONS section.

  • Page 26: Connections

    Amplifier Front Right < Rear Left Amplifier Rear Right < Subwoofers Amplifier (CDA-7965 only) < Rear or Amplifier ∗ Subwoofers (CDA-7864/CDA-7863/CDA-7862 only) ∗ When Subwoofer is set to OFF: Output is from Rear speakers. When Subwoofer is set to ON: Output is from Subwoofer.
  • Page 27 • Connect the ground lead securely to a bare metal spot (remove the coating if necessary) of the car chassis. • If you add an optional noise suppressor, connect it as far away from the unit as possible. Your Alpine dealer carries various Alpine noise suppressors, contact them for further information.
