The Actiontec Wireless Access Point can be installed in 2 different ways:
On a desktop.
Determine a clear area on your desktop where the Actiontec Wireless Access
Point can be placed in an upright position clear of obstructions.
lV
Mounted on a wall.
Prior to drilling holes into a wall, make sure the wall area of interest is clear of
electrical wiring or water pipes.
Determine the position of the screws and mark with a pencil.
Drill holes in the wall at the location of the marks.
Insert plastic lugs into the holes
Fasten the screws into the plastic lugs, making sure to leave a 3mm distance
as clearance between the wall and screw heads.
Mount the Actiontec Wireless Access Point onto the screws.
8
Installing the Actiontec Wireless Access Point
Figure 5: Actiontec Wireless Access Point on a desktop
Figure 6: Actiontec Wireless Access Point on a wall
.
