  • Page 1 V.92 PCI Pro Modem User’s Manual...

  • Page 2: Table Of Contents

    Table of Contents Page Introduction II. Contacting Actiontec Technical Support III. Before You Begin Product Features Package Contents IV. Installing the Modem V. Installing the Modem Drivers Configuring Windows 98, Windows 2000, Windows ME Configuring Windows NT 4.0 Configuring Windows XP VI.

  • Page 3: Introduction

    New drivers and firmware are released as need arises to insure maximum compatibility and operation of your new Actiontec V.92 PCI Pro Modem. To find out more about this Modem on Hold and other Actiontec products, and to sign up for a free e-mail newsletter, visit the Actiontec web site at: http://www.actiontec.com.

  • Page 4: Before You Begin

    Actiontec V.92 PCI Pro Modem Product Features User’s Manual This V.92* PCI Pro Modem allows your computer to connect to an ISP supporting Data/Fax Data Communications Software V.92, V.90, or 56K Flex™ protocols. This manual describes the hardware and software installation procedures for your new Actiontec V.92 PCI Pro Modem as well as trou-...

  • Page 5: Installing The Modem

    Then press on the top edge of the card, straight down until the card’s connectors seat firmly in the PCI slot. Secure it with the screw removed in Step 5, as shown Follow this procedure to install the V.92 PCI Pro Modem into an open PCI slot inside below.

  • Page 6: Installing The Modem Drivers

    Configuring Windows NT Installing the Modem Drivers 1) After installing the modem hardware as shown in Section 4, insert the CD-ROM provided with the modem. The driver installation dialog box will appear. Click Configuring Windows 98, Windows 2000, and Windows ME Install to begin the driver installation.

  • Page 7: Configuring Windows Xp

    Configuring Windows XP 3) Click Continue Anyway in the Hardware Installation dialog box. 1) After installing the modem hardware as shown in Section 4, insert the CD-ROM provided with the modem. The driver installation dialog box will appear. Click Install to begin the driver installation. 3) Click EXIT to complete the installation and close the application.

  • Page 8: Installing Communications Software

    3) The “Source Directory” should be pointing to teh BitWare folder on your CD- Installing Communications Software ROM drive. Input the “Destination Directory” where you would like the com- munications software installed.. Click OK. Installing on Windows NT, 98, 2000, and ME 1) Insert the CD-ROM if you have not done so already and the BitWare Communications Software will begin the installation process.
  • Page 9 7) If you would like the installer to create independent Programs Icons click OK. Otherwise click Cancel to skip this step. 8) The installer will detect the Actiontec V.92 PCI Pro Modem. 10) Click OK to restart Windows and begin using the software.

  • Page 10: Installing On Windows Xp

    3) The “Source Directory” should be pointing to teh BitWare folder on your CD- Installing on Windows XP ROM drive. Input the “Destination Directory” where you would like the com- 1) Insert the CD-ROM if you have not done so already and the BitWare munications software installed..
  • Page 11 10) The software will install the BitWare fax/print driver onto your system. 8) The installer will detect the Actiontec V.92 PCI Pro Modem. 11) If the system will be used by a single user, select the first option. If multiple users need to have mailboxes select the second option.

  • Page 12: The Modem On Hold Feature

    10) Click OK to restart Windows and begin using the software. The Modem On Hold Feature The Actiontec V.92 PCI Pro Modem includes the Modem On Hold feature which will notify you of an incoming call while you are surfing the Web. The Caller ID info box will appear on your screen.
  • Page 13 2) Click Next to continue the installation. 4) Select a Program Folder and click Next. 3) The window will display the destination folder. If you would like to change the 5) The installer will begin the installation process and copy the files to your hard drive. destination folder click Browse and select the folder you wish to install the soft- ware.

  • Page 14: Using The Modem On Hold Feature

    6) Click Finish to complete the installation. If you clicked “Ignore” or when you are finished on the voice call, the software will re- establish the data connection to your ISP. If you clicked “Answer” the software will put your data connection on hold and allow you to accept the voice call.

  • Page 15: At Commands

    AT Command Sets Troubleshooting There may be times when you need to access the modem manually with AT commands. Commands may be sent to your modem from a PC running communications software. When I Restart My Computer (using a Windows operating system) the Modem is not Detected.
  • Page 16 Off or low speaker volume S37 = 15 24000 bits/s Low volume S37 = 16 26400 bits/s Medium volume (default) S37 = 17 28800 bits/s High volume S37 = 18 31200 bits/s S37 = 19 33600 bits/s AT Commands Affecting ITU-T V.90 Operation 56K Dial Line Rate (default 1) There are 3 S-registers which support K56flex, V.90, and V.34 connections.

  • Page 17: Notices

    S109 K56flex and V.90 Selection (default 1) Notices Use this register to disable 56K connections or to choose between K56flex and V.90 pro- tocols. The default setting (S109=1) will attempt K56flex and then V.34 depending Declaration of Conformity upon the central site modem being called and your phone line conditions. This equipment has been tested and found to comply with the limits for a Class B dig- S109 = 0 Disable all 56K connections...
  • Page 18 The REN is used to determine the maximum number of devices connected to your connected together. This precaution may be particularly important in rural areas. telephone line that will ring in response to an incoming call. In most, but not all, areas, Caution: Users should not attempt to make such connections themselves, the total REN of devices connected to a line should not exceed five (5.0).

  • Page 19: Safety Information

    HARDWARE: Actiontec Electronics Inc. warrants to the end user (“Customer”) that this hard- CAUTION: ware product will be free from defects in workmanship and materials, under normal use and serv- ice, for twelve (12) months from the date of purchase from Actiontec Electronics or its authorized To avoid shock hazard: reseller.

  • Page 20: Warranty

    The repaired or replaced OUT OF OR IN CONNECTION WITH THE SALE, INSTALLATION, MAINTE- item will be shipped to Customer, at Actiontec Electronics’ expense, not later than thirty (30) days NANCE, USE, PERFORMANCE, FAILURE, OR INTERRUPTION OF ITS PRODUCT, after Actiontec Electronics receives the defective product.
  • Page 21 Notes Notes...
