TM
Product features may vary from the picture above.
Kawasaki
Ninja
®
®
Owner's Manual
with Assembly Instructions
Please read this manual and save it with your original sales receipt.
For Model 74750
Tools needed for assembly: Phillips Screwdriver, Hammer, Pliers, and Safety Scissors.
Use only with Power Wheels
Type H 6 Volt (9.5 Amp/hr.) Batteries, Power Wheels
30 Amp Fuses
®
®
and Power Wheels
®
Type H 12 Volt Charger (all included).
CAUTION
ELECTRIC TOY: Not recommended for children under 3 years of age.
As with all electric products, precautions should be observed during
handling and use to prevent electric shock.
Advertisement
Table of Contents
Related Manuals for Fisher-Price KAWASAKI NINJA POWER WHEELS 74750
Summary of Contents for Fisher-Price KAWASAKI NINJA POWER WHEELS 74750
- Page 1 Product features may vary from the picture above. Kawasaki Ninja ® ® Owner’s Manual with Assembly Instructions Please read this manual and save it with your original sales receipt. For Model 74750 Tools needed for assembly: Phillips Screwdriver, Hammer, Pliers, and Safety Scissors. Use only with Power Wheels Type H 6 Volt (9.5 Amp/hr.) Batteries, Power Wheels 30 Amp Fuses...
-
Page 2: Table Of Contents
Important Information ..............2 Warnings . -
Page 3: Warnings
• Children can be harmed by small parts, sharp edges and sharp points in the vehicle’s unassembled state, or by electrical items. Care should be taken in unpacking and assembly of the vehicle. Children should not handle parts, including the battery, or help in assembly of the vehicle. -
Page 4: Parts
• If you experience a problem with this product, or are missing a part, please call us at 1-800-348-0751, rather than return this product to the store. • Please identify all parts before assembly and save all packaging material until assembly is complete to ensure that no parts are discarded. - Page 5 Parts Cover Plate Right Hand Grip Left Hand Grip Handlebar Housing - Top Half Handlebar Housing - Front Fairing Bottom Half Handlebar Brushguard Steering Column Sound Box Battery Retainer Handlebar Neck...
- Page 6 Small Parts Bag Hex Bushing - 4 Wing Nut Not Shown: Label Sheet, Literature Bag #8 x " Screw (black) – 15 #8 x " Screw (blunt silver) - 10 #10 x " Screw (pointed silver) - 2 #10 (small) Washer *For your convenience, an extra 30 amp fuse and four extra cap nuts have been included.
-
Page 7: Parts Diagram
Vehicle Body Steering Column Driver - 2 Wheel - 4 Hubcap - 4 Right Mudflap Small Shock Half - 2 Large Shock Half - 2 Seat 6 Volt Battery - 2 Battery Retainer 12 Volt Charger Brushguard Rear Axle Cover - Short Half Rear Axle Cover - Long Half Key Assembly Parts Diagram... -
Page 8: Battery Charging
We recommend that you start charging your batteries before beginning assembly of your vehicle. Your new batteries must be charged for at least 18 hours before you use your vehicle for the first time. • The batteries must be handled by adults only. The batteries are heavy and contain sulfuric acid (electrolyte). -
Page 9: Battery Charging
• Your new batteries must be charged for at least 18 hours before you use them in your vehicle for the first time. • We recommend that you start charging your batteries before beginning assembly of your new vehicle. • The batteries must be upright while charging. •... -
Page 10: Assembly
Do not omit any steps. Please set aside at least Cover Plate • Fit the cover plate over the opening in the front of the vehicle body. • Insert two #8 x " screws (blunt silver) through the cover plate and into the vehicle body. Mudflap Rear of Vehicle... - Page 11 • Fit a hubcap on the rear axle and slide it into the center of the rear wheel. • Slide a hex bushing onto the rear axle. The ring side of the hex bushing should face out. • Press firmly to fit all but the ring on the end of the hex bushing into the rear wheel.
- Page 12 • Slide a wheel, small round hole first, onto the front axle. Front Axle • Fit a hubcap on the front axle and slide it into the center of the front wheel. Assembly Front Wheel Small Round Hole Front Axle Round Bushing "...
- Page 13 Hole Lock Nut Neck • Position the handlebar so that the side with the three holes and circular indentation faces up. • Fit the neck against the bottom of the handlebar, with the holes in the handlebar and neck aligned. •...
- Page 14 Handlebar Groove Steering Column Helpful Hint: You may want the help of another adult to support the steering column near the steering linkage while assembling the handlebar to the vehicle body. • Slide the bottom half of the handlebar housing onto the end of the steering column.
- Page 15 Knobs • Bend the plastic tip at the end of the microphone cord so that it forms a "T". • Insert the plastic tip through the hole in the handlebar housing. • Pull lightly on the microphone cord to make sure it is secure in the dash.
- Page 16 Shock Half - Small Rear Support Rear View • Fit the large half of one shock set against one of the rear supports. Make sure the end of the large shock half fits into the end cap at the bottom of the support. •...
-
Page 17: Label Decoration
Proper label application will help to keep the labels looking their best! When applying labels, keep the following guidelines in mind: • Wash your hands before applying the labels. • Before applying the labels, wipe the surface of the vehicle with a clean, dry cloth to remove any dust or oils. •... - Page 18 One time assembly is now complete. Four extra cap nuts are included with your vehicle. If you have any extra large washers, hex bushings or round bushings, you have probably incorrectly assembled one or more of the wheels. Please review assembly steps 4 - 12. If you have incorrectly assembled a wheel, squeeze the cap nut at the end of the axle firm- ly with pliers to remove the cap nut.
-
Page 19: Battery Installation
Important Note: Use only Power Wheels ies with Power Wheels ® 30 amp fuses installed. Use of any other batteries or fuses will damage your vehicle. Make sure that you charge the batteries for at least 18 hours using the enclosed Power Wheels ®... -
Page 20: Battery Care And Disposal
Care If a battery leak develops, avoid contact with the leaking acid and place the damaged battery in a plastic bag. See information below for proper disposal. If acid comes in contact with skin or eyes, flush with cool water for at least 15 minutes and call a physician. If acid is internally ingested, give water, milk of magne- sia or egg whites immediately. -
Page 21: Rules For Safe Driving
WARNING • Adult supervision is required. Children do not have the judgement necessary to avoid many accidents. Be sure that children operating this vehicle can do so safely and that they are supervised at all times. • Never use near steps, driveways, steep inclines, roadways, alleys, swimming pool areas or other bodies of water. -
Page 22: How To Operate Your Vehicle
How to Operate Your Vehicle Beginner Use - Low Speed Drive LOW/HIGH Switch As assembled, your vehicle is ready to roll in low speed mph, maximum). • Push the bottom button on the LOW/HIGH switch to set the vehicle to drive in low speed. •... -
Page 23: Caring For Your Vehicle
How to Operate Your Vehicle Advanced Use - High Speed Drive Connecting the High Speed Hook-Up High Speed Connectors Before you connect the high speed hook-up, make sure your child knows how to start and stop the vehicle and knows the rules for safe driving. When the high speed hook-up is connected, the vehicle can be driven forward in low speed (2 mph, maximum) or high speed (5 mph,... -
Page 24: Problems And Solutions Guide
Problems and Solutions Guide IMPORTANT! If you experience a problem with your vehicle, first check the Problems and Solutions Guide below. If you still experience a problem, please contact Power Wheels toll-free at 1-800-348-0751 between 8 AM and 6 PM (EST) Monday through Friday. Or, contact your local Power Wheels the Authorized Service Center list beginning on page 28. -
Page 25: Problems And Solutions Guide
Problems and Solutions Guide Problem Vehicle was running but Loose wire or loose connectors suddenly stopped Wrong type or improperly installed fuse Blown fuses Vehicle is overloaded Driving conditions are too stressful Short run time (Less than Undercharged batteries 1 - 3 hours per charge) Overcharged batteries Batteries are old and will not accept full charge... - Page 26 Problems and Solutions Guide Problem Vehicle runs sluggishly Undercharged batteries Batteries need charging Wrong type or improperly installed fuses Batteries are old and will not accept full charge Vehicle is overloaded Driving conditions are too stressful Sometimes the vehicle doesn’t Loose wire or connector run, but other times it does Motor or electrical switch damage...
- Page 27 Problems and Solutions Guide Problem Vehicle constantly blows fuses Wrong type of fuse used Child is switching between FORWARD and REVERSE or LOW and HIGH without stopping. Loud clacking or grinding Broken gears noise from a motor-gearbox Charger gets warm during use It is normal for some chargers to get warm during use and is not reason for concern.
-
Page 28: Statement Of Limited Warranty
Statement of Limited Warranty 90-day limited warranty for the Power Wheels ® Ride-On Toy Vehicle A 6-month battery warranty applying only to those 6 volt batteries which were included ® by Power Wheels , with the Power Wheels vehicle when originally purchased. This limited warranty covers the Power Wheels ride-on vehicle and the 6 volt batteries, purchased from Power Wheels... - Page 29 YUCAIPA - Aire-Rite Heating & A/C, 34724 Yucaipa Blvd., 92399, (909) 797-2788 COLORADO COLORADO SPRINGS - Nelson Appliance Repair, Inc., 1220 E. Fillmore, 80907, (719) 635-1928, (800) 291-8010 DENVER - Appliance Service, 4262 Lowell Blvd., 80211, (303) 458-1109, (800) 631-0941 (CO, WY only) DENVER (ENGLEWOOD) - Appliance Service, 3932 S.
- Page 30 MASSACHUSETTS BOSTON (MEDFIELD) - Wills Hardware, 5 Janes Avenue, 02052, (508) 359-4381 BOSTON (WALTHAM) - Suburban Appliance Service Center, Inc., 271 Moody Street, 02154, (617) 893-6694 LOWELL - Lowell Appliance Service Center, Inc., 564 Dutton Street, 01854, (508) 454-8731 MAYNARD - Gramp’s Garage, 16 Main Street, 01754, (508) 461-0463 QUINCY - Appliance Service and Parts, Inc., 582 Wash- ington Street, Route 3A, 02169, (617) 773-6656...
- Page 31 OREGON PORTLAND - Appliance Repair Central, 3203 N. E. Sandy Blvd., 97232, (503) 234-7339, (800) 588-7339 PENNSYLVANIA ALTOONA - Frye’s Sweeper & Sewing Center, Inc., 1400 Valley View Boulevard, 16602, (814) 943-5001, (800) 640-1308 HARRISBURG - C.A. Juillard, Inc., 2301 North Seventh Street, 17110, (717) 233-3488, (800) 633-3488 JOHNSTOWN - Cambria True Value Hardware,West Hills Square, Goucher Street, 15905, (814) 255-4752...
- Page 32 Kawasaki, Ninja and associated trademarks are owned by and used under license from Kawasaki Motors Corp., U.S.A. ©1998 Kawasaki Motors Corp., U.S.A. All Rights Reserved. ©1997 Fisher-Price, Inc., a subsidiary of Mattel, Inc., East Aurora, New York 14052 - All Rights Reserved Printed in the U.S.A.
