TM
Product features may vary from the picture above.
™
™
™
Owner's Manual
with Assembly Instructions
Please read this manual and save it with your original sales receipt.
For Model 74557
Tools needed for assembly: Phillips Screwdriver, Hammer, Pliers, and Safety Scissors.
Use only with Power Wheels
Type H 6 Volt (9.5 Amp/hr.) Batteries, Power Wheels
30 Amp Fuses
®
®
and Power Wheels
®
Type H 12 Volt Charger (all included).
Requires two "AA" alkaline batteries (not included) for sound.
CAUTION
ELECTRIC TOY: Not recommended for children under 3 years of age.
As with all electric products, precautions should be observed during
handling and use to prevent electric shock.
Advertisement
Table of Contents
Related Manuals for Fisher-Price BARBIE SPORT MOBILE 74557
Summary of Contents for Fisher-Price BARBIE SPORT MOBILE 74557
- Page 1 Product features may vary from the picture above. ™ ™ ™ Owner’s Manual with Assembly Instructions Please read this manual and save it with your original sales receipt. For Model 74557 Tools needed for assembly: Phillips Screwdriver, Hammer, Pliers, and Safety Scissors. Use only with Power Wheels Type H 6 Volt (9.5 Amp/hr.) Batteries, Power Wheels 30 Amp Fuses...
-
Page 2: Table Of Contents
Important Information ..............2 Warnings . -
Page 3: Warnings
• Children can be harmed by small parts, sharp edges and sharp points in the vehicle’s unassembled state, or by electrical items. Care should be taken in unpacking and assembly of the vehicle. Children should not handle parts, including the battery, or help in assembly of the vehicle. -
Page 4: Parts
• If you experience a problem with this product, or are missing a part, please call us at 1-800-348-0751, rather than return this product to the store. • Please identify all parts before assembly and save all packaging material until assembly is complete to ensure that no parts are discarded. - Page 5 Parts Left Right Top Half Hand Guard Set Hand Grip - 2 Bottom Half Headlight Housing Cover Plate Windshield Handlebar Brushguard Steering Column Sound Box Headlight Guard and Rim Battery Retainer Handlebar Neck...
- Page 6 Microphone Small Parts Bag Hex Bushing - 4 Wing Nut " Screw – 6 " Screw (silver) - 10 Small Washer *For your convenience, an extra 30 amp fuse and cap nut have been included. Parts Key Assembly Round Bushing - 2 Radio Knobs - 2 Carriage Bolt "...
-
Page 7: Parts Diagram
Vehicle Body Steering Column Front Wheel - 2 Rear Wheel - 2 Hubcap - 4 Right Mudflap Small Shock Half - 2 Large Shock Half - 2 Seat 6 Volt Battery - 2 Battery Retainer 12 Volt Charger Brushguard Rear Axle Cover - Short Half Rear Axle Cover - Long Half Key Assembly Parts Diagram... -
Page 8: Battery Charging
• The batteries must be handled by adults only. The batteries are heavy and contain sulfuric acid (electrolyte). Dropping the batteries could result in serious injury. • Never allow children to charge the batteries. Battery charging must be done by adults only. A child could be injured by the electricity involved in charging the batteries. -
Page 9: Battery Charging
• Your new batteries must be charged for at least 18 hours before you use them in your vehicle for the first time. • We recommend that you start charging your batteries before beginning assembly of your new vehicle. • The batteries must be upright while charging. •... -
Page 10: Assembly
Cover Plate • Fit the cover plate over the opening in the front of the vehicle body. • Insert two " screws (silver) through the cover plate and into the vehicle body. Mudflap Rear of Vehicle Body • Tip up the back end of the vehicle. •... - Page 11 • Slide a hex bushing onto the rear axle. The ring side of the hex bushing should face out. • Press firmly to fit all but the ring on the end of the hex bushing into the rear wheel. • Fit a cap nut on the end of the rear axle. •...
- Page 12 Front Axle • Fit a hubcap on the front axle and slide it into the center of the front wheel. Front Axle • Slide a hex bushing onto the front axle. The ring side of the hex bushing should face out. •...
- Page 13 Upper Steering Linkage Steering Column Lower Steering Bottom View Linkage • Slide the straight end of the steering column through the hole in the lower steering linkage and out through the hole in the vehicle body. • Insert the curved end of the steering column into the hole in the upper steering linkage.
- Page 14 • Replace the battery compartment cover and insert the sound box screw through the hole in the cover. • Tighten the screw with a Phillips screwdriver. Do not over-tighten. Battery Tips: • Do not mix old and new batteries. • Do not mix different types of batteries: alkaline, standard (carbon-zinc) or rechargeable (nickel-cadmium) batteries.
- Page 15 Headlight • Fit the headlight rim against the opening at the front of the handlebar housing, with the headlight guard facing out. • Insert four " screws (black) through the holes in the headlight rim and tighten the screws with a Phillips screwdriver.
- Page 16 Top Tab Sport Bar Brushguard • Wrap the tab at the top of the brushguard around the top of the sport bar. • Insert two " screws through the holes in the front of the brushguard and into the screw pegs on the brushguard tab.
- Page 17 Shock Half - Small Rear Support Rear View • Fit the large half of one shock set against one of the rear supports. Make sure the end of the large shock half fits into the end cap at the bottom of the support. •...
-
Page 18: Label Decoration
Proper label application will help to keep the labels looking their best! When applying labels, keep the following guide- lines in mind: • Wash your hands before applying the labels. • Before applying the labels, wipe the surface of the vehicle with a clean, dry cloth to remove any dust or oils. -
Page 19: Battery Installation
Important Note: Use only Power Wheels ies with Power Wheels ® 30 amp fuses installed. Use of any other batteries or fuses will damage your vehicle. Make sure that you charge the batteries for at least 18 hours using the enclosed Power Wheels ®... -
Page 20: Battery Care And Disposal
Care If a battery leak develops, avoid contact with the leaking acid and place the damaged battery in a plastic bag. See information below for proper disposal. If acid comes in contact with skin or eyes, flush with cool water for at least 15 minutes and call a physician. If acid is internally ingested, give water, milk of magne- sia or egg whites immediately. -
Page 21: Rules For Safe Driving
WARNING • Adult supervision is required. Children do not have the judgement necessary to avoid many accidents. Be sure that children operating this vehicle can do so safely and that they are supervised at all times. • Never use near steps, driveways, steep inclines, roadways, alleys, swimming pool areas or other bodies of water. -
Page 22: How To Operate Your Vehicle
How to Operate Your Vehicle Beginner Use - Low Speed Drive LOW/HIGH Switch Steering Forward Wheel Button FORWARD/REVERSE Switch As assembled, your vehicle is ready to roll in low speed mph, maximum). • Push the bottom button on the LOW/HIGH switch to set the vehicle to drive in low speed. -
Page 23: Caring For Your Vehicle
How to Operate Your Vehicle Advanced Use - High Speed Drive Connecting the High Speed Hook-Up Before you connect the high speed hook-up, make sure your child knows how to start and stop the vehicle and knows the rules for safe driving. When the high speed hook-up is connected, the vehicle can be driven forward in low speed (2 mph, maximum) or high speed (5 mph,... -
Page 24: Problems And Solutions Guide
Problems and Solutions Guide IMPORTANT! If you experience a problem with your vehicle, first check the Problems and Solutions Guide below. If you still experience a problem, please contact Power Wheels toll-free at 1-800-348-0751 between 8 AM and 6 PM (EST) Monday through Friday. Or, contact your local Power Wheels the Authorized Service Center list beginning on page 28. -
Page 25: Problems And Solutions Guide
Problems and Solutions Guide Problem Vehicle was running but Loose wire or loose connectors suddenly stopped Wrong type or improperly installed fuse Blown fuses Vehicle is overloaded Driving conditions are too stressful Short run time (Less than Undercharged batteries 1 - 3 hours per charge) Overcharged batteries Batteries are old and will not accept full charge... - Page 26 Problems and Solutions Guide Problem Vehicle runs sluggishly Undercharged batteries Batteries need charging Wrong type or improperly installed fuses Batteries are old and will not accept full charge Vehicle is overloaded Driving conditions are too stressful Sometimes the vehicle doesn’t Loose wire or connector run, but other times it does Motor or electrical switch damage...
- Page 27 Problems and Solutions Guide Problem Vehicle constantly blows fuses Wrong type of fuse used Child is switching between FORWARD and REVERSE or LOW and HIGH without stopping. Loud clacking or grinding Broken gears noise from a motor-gearbox Charger gets warm during use It is normal for some chargers to get warm during use and is not reason for concern.
-
Page 28: Statement Of Limited Warranty
Statement of Limited Warranty 90-day limited warranty for the Power Wheels ® Ride-On Toy Vehicle A 6-month battery warranty applying only to those 6 volt batteries which were included by Power Wheels ® , with the Power Wheels vehicle when originally purchased. This limited warranty covers the Power Wheels ride-on vehicle and the 6 volt batteries, purchased from Power Wheels... - Page 29 TEMECULA - California Electric Service Center, 41715 Enterprise Circle North, Suite 101, 92590, (909) 695-5445 VAN NUYS - California Electric Service Center, 14753 Oxnard Blvd., 91411, (818) 997-8855 WEST LOS ANGELES - California Electric Service Center, 2314 S. Westwood Blvd., 90064, (310) 475-2532 YUCAIPA - Aire-Rite Heating &...
- Page 30 8741 Mylander Lane, 21286, (410) 321-9033 BERLIN - Myers Auto-Power Tool Rental Co., Inc.,10714 Ocean Gateway, 21811, (410) 641-3497 GAITHERSBURG - Waters Appliance Service, 216 E. Diamond Avenue, 20877, (301) 258-7500, (800) 225-5009 SALISBURY - Cycle and Sports Outlet, 2505 N. Salisbury Blvd., 21801, (410) 860-0400 TANEYTOWN - MacHenry Services, 68 Frederick Street, 21787, (410) 756-6659, (800) 276-1301 WASHINGTON D.C.
- Page 31 DAYTON (NEW CARLISLE) - Ballweg Do-It Center, 3300 South Dayton, Lakeview Rd., 45344, (937) 849-1306 LIMA - Crouse Lumber Do-It Center, 333 E. Market Street, 45801, (419) 229-9070, (800) 826-9663 NEW BOSTON - True Value Toy Town, Rt. 52 & 139, 45662, (614) 456-5704 STRYKER - Short’s Hardware, 115 N.
- Page 32 Authorized Service Center list in this manual. BARBIE is a trademark owned by and used under license from Mattel, Inc. ©1997 Mattel, Inc. All Rights Reserved. ©1997 Fisher-Price, Inc., East Aurora, New York 14052 - All Rights Reserved Printed in the U.S.A. 74557 1...
