WarmHearth Fireplace
Owners &
Installation Manual
Regency WarmHearth High Effi ciency EPA Certifi ed Fireplace
MODEL: Z2510L
Tested by:
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
11/16/07
908-200
