FireplaceXtrordinair 864TRV Installation Instructions

Arched face
Hide thumbs Also See for 864TRV:
1
2
3
4

Advertisement

Quick Links

Download this manual
Compatibility:
• 864TRV Fireplace
The FPX Face Upgrade Kit (98500686) must be
installed prior to installing the facing material and face.
Hand-Rubbed Patina Finishes
The optional patina finish is hand applied by a skilled artisan to permanently alter the metal colors and texture
of the face. Each face is individually hand-polished and fired in an oven which imparts unique color subtleties
with no two finishes alike. The patina finish on your face is a "living" color and will age and antique over time.
Enjoy the timeless, rich luster of your beautiful new face.
Installation Details
Page 1 of 4
French Country Black: 95800616

Packing List:

• Face
• (2) Face Mounting Brackets (w screws)
• Glass Frame Cover
5"
Radius = 45-3/4"
35-3/4"
NOTE FOR THICK FACING (BRICK, ROCK, ETC.):
The Fireplace Xtrodinair 864 Set-Up Face is recommended for
masonry installation (98500688). The set-up face helps locate
and support the masonry during installation.
17601406 - 9/14/11
864TRV Arched Face
Classic Black: 99300497
41"
NOTE:
This face has an adjustable bracket that allows for
different facing depths to be tucked under the face.
Artisan: 99300498
Artisan Patina Bronze 95800621
• (4) 8-32 Nuts
• (2) 10-24 1-1/2" Screws
SIDE OF FIREPLACE
5/16" TO 1"
© Travis Industries, Inc.
1"

Advertisement

loading

Related Manuals for FireplaceXtrordinair 864TRV

Summary of Contents for FireplaceXtrordinair 864TRV

  • Page 1: Packing List

    Compatibility: • 864TRV Fireplace The FPX Face Upgrade Kit (98500686) must be installed prior to installing the facing material and face. Hand-Rubbed Patina Finishes The optional patina finish is hand applied by a skilled artisan to permanently alter the metal colors and texture of the face.
  • Page 2 Remove the glass frame (see the owner's manual for details). Install the glass frame cover following the directions below. Replace the glass frame. Place the cover over the top of the door frame. Page 2 of 4 864TRV Arched Face Classic Black: 99300497 French Country Black: 95800616 Push these pins inwards to lock the cover in place.
  • Page 3 The facing and hearth (if applicable) must be installed prior to attaching the face. See the installation manual for complete details. Raised Fireplaces Page 3 of 4 864TRV Arched Face Classic Black: 99300497 French Country Black: 95800616 Note how the tile is 1” (maximum) above the base of the fireplace.

  • Page 4: Plated Surfaces

    Plated Surfaces Use denatured alcohol and a soft cloth to clean plated surfaces. Marks left on the surface may damage the face. Page 4 of 4 864TRV Arched Face Classic Black: 99300497 French Country Black: 95800616 17601406 - 9/14/11 Artisan: 99300498...
