The status of the RXST625 receiver is indicated by the use of two bi-
colour Light Emitting Diodes (LEDs). The status indicators are:
USER CONTROL FUNCTION SUMMARY
Key/Operation
Auto
Manual
On
Cycle
Off
SYNC Button
Reset Button
RECEIVER MODES
The RF receiver can operate in three different modes – AUTO or
MANUAL, and also has a FAILSAFE mode of operation. These modes are
selected by using the slide switches on the front of the receiver:
AUTO MODE
Moving the slide switch to the 'AUTO' position selects the Automatic
operation mode of the RF receiver In this mode, the receiver will
automatically receive an RF signal from the thermostat and control the
output relay. When in auto mode, if RF communication between the
receiver and thermostat is lost for less than one hour, the receiver
remains in the same operating state it was in when the signal was lost.
If the RF signal is lost for more than one hour, the receiver will enter
Failsafe mode, and control of the receiver output will be based on the
setting of the Failsafe mode switch. Please be aware that if the
thermostat is operating in Service mode when changing the receiver
switch position, the relay output may be affected.
RXST625 INSTRUCTION MANUAL
Functions
Sets receiver to Automatic mode (default setting)
Sets receiver to Manual mode
Turns relay output ON (default setting)
Switches receiver output on and off in a 15 minute cycle
(4 minutes on, 11 minutes off)
Turns relay output OFF
Enables RF signal synchronisation with RXST625 thermostat
Resets the receiver to default (original factory) settings
11
