Specifications

Specifications, Accessories, Part Numbers, cont'd
Control/remote — control pads
IR controller module ................... IR 701 (optional)
General
Power ............................................. 12VDC, at 60 mA, from the System 7SC or
System 5cr Plus switcher
Temperature/humidity .............. Storage -40° to +158°F (-40° to +70°C) /
10% to 90%, non-condensing
Operating +32° to +122°F (0° to +50°C) /
10% to 90%, non-condensing
Rack mount ................................... No, but furniture/wall mountable with
included faceplates and electrical boxes or
optional mounting bracket kits or AAP
wall plates.
Enclosure type .............................. Metal
Enclosure dimensions
SCP/AAP A
Plate ........................... 2.1" H x 3.5" W x 0.1" D
(three space high AAP plate)
5.3 cm H x 8.9 cm W x 0.3" D
Boards ........................ 2.0" H x 2.5" W x 1.6" D
5.1 cm H x 6.4 cm W x 2.6 cm D
(Allow at least 2.1" (5.3 cm) depth in the
wall or furniture. Depth excludes
connectors and knobs.)
SCP 200
Plate ........................... 4.5" H x 4.6" W x 0.1" D (2 gang)
11.4 cm H x 11.7 cm W x 0.3 cm D
Box ............................. 3.75" H x 3.6" W x 3.5" D
9.5 cm H x 9.2 cm W x 8.9 cm D
Boards ........................ 2.7" H x 3.5" W x 0.9 D
6.9 cm H x 8.9 cm W x 2.3 cm D
(Allow at least 1.5" (3.8 cm) depth in the
wall or furniture. Depth excludes
connectors and knobs.)
SCP 250
Plate ........................... 4.5" H x 6.4" W x 0.1" D (3 gang)
11.4 cm H x 16.3 cm W x 0.3 cm D
Box ............................. 3.75" H x 5.4" W x 3.5" D
9.5 cm H x 13.8 cm W x 8.9 cm D
Boards ........................ 2.7" H x 5.3" W x 0.9 D
6.9 cm H x 13.5 cm W x 2.3 cm D
(Allow at least 1.5" (3.8 cm) depth in the
wall or furniture. Depth excludes
connectors and knobs.)
A-2 SCP/AAP A, SCP 200, SCP 250 • Specifications, Part Numbers
Product weight
SCP/AAP A ...................... 0.2 lbs (0.1 kg)
SCP 200 .............................. 0.3 lbs (0.1 kg)
SCP 250 .............................. 0.5 lbs (0.2 kg)
Shipping weight
SCP/AAP A ...................... 1 lbs (0.5 kg)
SCP 200, SCP 250 ............. 3 lbs (1.4 kg)
Vibration ....................................... ISTA/NSTA 1A in carton
(International Safe Transit Association)
Listings .......................................... UL, CUL
Compliances ................................. CE, FCC Class A
as components of the System 7SC
MTBF ............................................. 30,000 hours
Warranty ....................................... 3 years parts and labor
Specifications are subject to change without notice.
SCP/AAP A, SCP 200, SCP 250 • Specifications, Part Numbers A-3
