Installation and Operation, cont'd

Front Panel Features

The controls on the SCP 150, SCP 150 AAP, and SCP 150 L
replicate the System 5 IP's volume, input switching, and system
controls. All the button functions for the System 5 IP and the
SCPs are configured via RS-232 or Ethernet control. See the
System 5 IP user's manual for instructions on configuring the
buttons.
6
VOLUME
5
IR
INPUT INPUT
1 2
SCP 150
1
6
VOLUME PROJECTOR
PROJECTOR PROJECTOR
ON OFF
5
LIGHTS LIGHTS
IR
ON OFF
INPUT INPUT INPUT INPUT
1 2 3 4
4
SCP 150 AAP
2-10 SCP 150 • Installation and Operation
1 2
PROJECTOR
PROJECTOR PROJECTOR FUNCTION
ON OFF BUTTON
3
LIGHTS LIGHTS
PC
ON OFF
INPUT INPUT INPUT
3 4 5
SCP 150
4
2 7
FUNCTION
BUTTON
3
PC
INPUT
5
SCP 150 AAP
6
VOLUME
5
IR
INPUT
INPUT
1
2
Extron
SCP 150 L
All the buttons on the SCP can light bright green, red,
or amber when selected in stand-alone mode (not
connected to the System 5 IP). Unselected buttons light
dim amber.
On and Off buttons — Press these buttons to turn the projector
1
on and off. The buttons flash during the projector's warm up
or cool down cycle, and then light steadily.
and Function buttons — These buttons are fully configurable and
2 3
can be used to control the System 5 IP's relays, execute IR or
RS-232 commands, or trigger other buttons. Refer to the
System 5 IP user's manual for information on configuring these
buttons.
The three function buttons in the middle row (
three function buttons on a System 5 IP equipped with front
panel controls. The single function button in the top row (
an additional function button not found on the switcher.
Input selection buttons — These buttons replicate the five input
4
selection buttons on a System 5 IP equipped with front panel
controls. Press one of these buttons to select an input on the
switcher. Refer to the System 5 IP user's manual for more
information on input selection.
IR signal pickup sensor — This sensor allows control of the SCP
5
using an optional Extron IR 402 remote control. Point the
remote directly at the sensor. The remote has a range of
SCP 150 • Installation and Operation
1 2
PROJECTOR
PROJECTOR PROJECTOR FUNCTION
ON OFF BUTTON
3
LIGHTS LIGHTS
PC
ON OFF
INPUT INPUT
INPUT
3 4 5
4
) replicate the
3
) is
2
2-11
