26. Moveable upper cutter
27. Stitch nger lever
28. Stationary lower cutter
29. Chainstitch/Coverstitch looper
30. Lower looper
31. Upper looper
32. 2-thread converter
33. Upper looper clutch
33. Chain/coverstitch thread guide
Accessories
Accessories are contained in the accessory box.
1. Accessory box
2. Screwdriver
3. Knife blade (for the movable upper cutter)
4. Thread unreeling discs (5)
5. Thread spool nets (5)
6. Oiler
7. Allen key
8. Tweezers (placed on the inside of the front cover)
9. Coverstitch table B (for Cover/chainstitch)
10. Cone holders (5)
11. Lint brush
12. Dust cover
13. Waste tray
14. Stylus (placed on the inside of the front cover)
15. Needle threader
16. Extension table including four legs and push pin (not
pictured).
Assemble the extension table and legs according to the
illustrations provided with the table. The push pin is
used in the small holes in the table to hold your fabric
in place when sewing circles (see page 36).
17. Needle pack (not pictured) system ELx705 including
three needles, size #14/90 and two needles, size
#12/80. Two needles, size #14/90, are in the machine
on delivery.
29
31
27
28
30
26
1
2
3
4
10
9
13
32
34
33
5
6
7
8
12
11
14
15
Introduction
5
