  • Page 1 O w n e r ’ s M a n u a l...

  • Page 2: Important Safety Instructions

    This household sewing machine is designed to comply with IEC/EN 60335-2-28 and UL1594. IMPORTANT SAFETY INSTRUCTIONS When using an electrical appliance, basic safety precautions should always be followed, including the following: Read all instructions before using this household sewing machine. Keep the instructions at a suit- able place close to the machine.
  • Page 3 For Europe only: This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.

  • Page 5: Table Of Contents

    Table of contents Introduction Stitches & Sewing techniques Parts of the machine ............4 Stitch overview ..............22 Accessories ................5 Start sewing ..............28 Pin placement ..................28 Optional accessories from INSPIRA™ ......6 Chain off .....................28 Preparations Rolled edge sewing ............29 Connecting the foot control Coverstitch sewing ............

  • Page 6: Introduction

    Parts of the machine 3 4 5 6 7 12 13 1. Telescopic thread stand 2. Handle 9. Flat bed extension 10. Cutter cover A 11. Front cover 12. Power & light switch 20. Presser foot pressure adjusting dial 13. Foot control/electric power cord socket 21.

  • Page 7: Accessories

    28. Moveable upper cutter 31. Chainstitch/Coverstitch looper 32. Lower looper 33. Upper looper 34. 2-thread converter 35. Upper looper clutch 36. Chain/coverstitch thread guide Accessories Accessories are contained in the accessory box. 1. Accessory box 6. Oiler 7. Allen key 8.

  • Page 8: Optional Accessories From Inspira

    Optional accessories from INSPIRA™ Optional presser feet specially prepared for this machine are available at your PFAFF® dealer. The snap-on type presser foot used on this machine allows easy removal and replacement. Elastic Foot 620 08 65-96 Blindhem & Lace Foot 620 08 69-96 The Blindhem Foot is perfect for sewing invisible hems and for applying lace.

  • Page 9: Preparations

    Connecting the foot control and the power supply Foot control to use with this machine: Before plugging your machine in, make sure the voltage is the same as indicated on the plate under the machine. • Connect the foot control/electric power cord to the socket on the machine.

  • Page 10: Front Cover

    Front cover Open First push the cover to the right as far as it will go and then pull it downward toward you. Close First pull the cover upward and then slide it to the left until it locks. Note: The front cover has a safety switch and the machine will Attaching the waste tray Position the machine so the front is nearly aligned with the edge of the table.

  • Page 11: Needle Information

    Needle information A. Overlock left needle eliminates the possibility of inserting the needle backwards. B. Overlock right needle Do not attempt to use a standard household sewing machine C. Coverstitch left needle needle of any size or type in this overlock. D.

  • Page 12: 2-Thread Overlock Converter

    2-thread overlock converter Engaging 2-thread overlock stitches are sewn using one needle thread and the lower looper thread. Before sewing, the 2-thread converter must be attached to the upper looper. The 3-thread stretch overlock stitch is also sewn with the 2-thread overlock converter engaged.

  • Page 13: Threading

    overlock sewing. To sew rolled edge you need to retract lever as far as it will go in each direction. General threading information upper looper, followed by the lower looper and then the needles from right to left. Re-threading if a thread breaks If the two loopers are not threaded in the correct order they will not create a stitch.

  • Page 14: Threading The Upper Looper (Red)

    Threading the upper looper (red) • Raise the presser foot to release tension discs. • Pass the thread from back to front through the thread • Thread the top cover thread guide by pulling the thread towards the right until it slips under the guide. Then pull the thread along the right side of the button •...

  • Page 15: Threading The Lower Looper (Yellow)

    Threading the lower looper (yellow) • Raise the presser foot to release tension discs. • Pass the thread from back to front through the thread • Thread the top cover thread guide by pulling the thread towards the right until it slips under the guide. Then pull the thread along the right side of the button •...

  • Page 16: Threading Chainstitch Looper (Purple)

    Threading chainstitch looper (purple) • Raise the presser foot to release tension discs. • Pass the thread from back to front through the thread • Thread the top cover thread guide by pulling the thread towards the right until it slips under the guide. Then pull the thread along the right side of the button •...

  • Page 17: Threading The Right Needle

    Threading the right needle (green, B on needle clamp) • Raise the presser foot to release tension discs. • Pass the thread from back to front through the thread • Thread the top cover thread guide by pulling the thread towards the right until it slips under the guide. Then pull the thread along the right side of the button •...

  • Page 18: Threading The Left Needle

    Threading the left needle (blue, A on needle clamp) • Raise the presser foot to release tension discs. • Pass the thread from back to front through the thread • Thread the top cover thread guide by pulling the thread towards the right until it slips under the guide. Then pull the thread along the right side of the button •...

  • Page 19: Threading The Chainstitch Needle

    Threading the chainstitch needle (blue, D on needle clamp) • Raise the presser foot to release tension discs. • Pass the thread from back to front through the thread • Thread the top cover thread guide by pulling the thread towards the right until it slips under the guide. Then pull the thread along the right side of the button •...

  • Page 20: Threading The Coverstitch Needles

    Threading the coverstitch needles Threading the right coverstitch needle (red, E on the needle clamp) • Raise the presser foot to release tension discs. • Pass the thread from back to front through the thread • Thread the top cover thread guide by pulling the thread towards the right until it slips under the guide.
  • Page 21 Threading the middle coverstitch/chainstitch needle (green, D on the needle clamp) • Raise the presser foot to release tension discs. • Pass the thread from back to front through the thread • Thread the top cover thread guide by pulling the thread towards the right until it slips under the guide.
  • Page 22 Threading the coverstitch left needle (blue, C on the needle clamp) • Raise the presser foot to release tension discs. • Pass the thread from back to front through the thread • Thread the top cover thread guide by pulling the thread towards the right until it slips under the guide.

  • Page 23: Needle Threader

    The following is an easy way to change threads: • Cut the thread in use near the spool, behind the guides PFAFF coverlock 3.0 on the telescopic thread stand. • Remove the thread spool and place the new thread on german design the spool pin.

  • Page 24: Stitches & Sewing Techniques

    Stitch overview The settings shown in this table are our recommendations based on normal conditions. The correct tension is set the stitch, type of fabric and thread you are using. For best results make tension adjustments in small steps of no greater than half a number at a time.
  • Page 25 Threading path Stitch A and • • • • 4-thread safety stitch, wide B and • • • • 4-thread safety stitch, narrow • • • 3-thread overlock, wide For sewing two layers of stretchy fabric or overcasting a single layer of light to medium fabric. Use heavier •...
  • Page 26 Threading path Stitch • • • 3-thread narrow edge* upper looper with a decorative thread, such as 40 weight rayon for a beautiful satin edge. Read more on page • • • side. Create varying effects by threading the upper looper with decorative thread. Read more on page 30. •...
  • Page 27 Threading path Stitch • • • 3-thread rolled edge* rolled edge, thread the upper looper with decorative thread and the needle and lower looper with lightweight regular thread. Read more on page 29. • • 2-thread overlock, wide • • 2-thread overlock, narrow •...
  • Page 28 Threading path Stitch • • more on page 30. • • 2-thread wrapped overlock, wide • • 2-thread wrapped overlock, narrow • • 2-thread rolled edge* Read more on page 29. * Not recommended for heavyweight woven fabrics or medium to heavyweight stretch fabrics. Stitches &...
  • Page 29 Threading path Stitch C, D • • • • and E Coverstitch, triple For hems on stretch fabrics and for decorative effects on all kind of fabrics. Use decorative thread in looper for embellishment. Read more on page 29. C and •...

  • Page 30: Start Sewing

    Start sewing Pin placement When securing the fabric pieces using pins, insert straight pins to the left of the presser foot. The pins will be easy to remove and are away from the cutters. cutting edge of the cutters. • When the machine is completely threaded, close the front cover and bring all of the threads over the stitch plate and slightly to the left under the presser foot.

  • Page 31: Rolled Edge Sewing

    Rolled edge sewing The rolled edge stitch is appropriate for lightweight fabrics such as lawn, voil, organdy, crepe, etc. The rolled edge is achieved by adjusting the thread tension to make the fabric edge roll under the fabric while overlocking. Adjust the regular thread.

  • Page 32: Flatlock Sewing

    Flatlock sewing look, or with the right sides together, to create a ladder stitch. • Use the left or the right needle. • Engage the 2-thread converter Thread the lower and upper • Place the wrong sides of the two pieces of fabric together to sew a decorative stitch on the right side of the garment.

  • Page 33: Chainstitch Sewing

    Chainstitch sewing The chainstitch is sewn with two threads, one needle and one looper. Normally, the machine trims the fabric edge while the seam is being sewn. However, a chainstitch seam can be placed at a desired distance from edge of fabric by Machine set up the distance, in cm and inches, from coverstitch middle needle.

  • Page 34: Stitch Adjustments

    Stitch width adjustment A) Left needle B) Right needle C) Chainstitch needle The stitch width can be increased or decreased by 6 mm 4 mm 9 mm changing the needle position or with the cutting width dial. Width adjustment by changing needle position used the stitch width is 6 mm.

  • Page 35: Differential Feed Adjustment

    Differential feed adjustment The differential feed system consists of two sets of feed teeth arranged one behind the other. Both feed teeth work independently of each other to give perfect results when sewing on speciality fabrics. When the amount of feed by the front feed teeth is changed in relation to the feed by Use the differential feed to prevent stretching of knit fabrics and puckering of lightweight fabrics.
  • Page 36 • Type and thickness of the fabric • Needle size 2-thread overlock When the lower looper thread lies on the underside of the fabric When the needle thread tension is too loose 2-thread overlock, wrap When the lower looper thread tension is too tight or needle thread tension is too loose When the lower looper thread tension is too loose When the lower looper thread tension is too loose...
  • Page 37 4-thread overlock When the upper looper thread lies on the underside of the fabric higher position. When the lower looper thread appears on the top of the fabric When the left needle thread tension is too loose toward a higher position. When the right needle thread tension is too loose Safety stitch When the lower looper thread tension is too loose...

  • Page 38: Maintenance

    Machine maintenance than a conventional machine mainly for two reasons: • A lot of lint is produced when the cutters are cutting the the fabric. • An overlock runs at a very high speed and needs to be Cleaning • Open the front cover and remove all the lint using the lint brush.

  • Page 39: Changing The Light Bulb

    Changing the light bulb Only use light bulbs of the same type rated 15W. Light bulbs are available at your authorized PFAFF® dealer. • Remove the light cover screw and while pushing the cover lightly to the rear, swing cover to the left and remove from machine as shown in the illustration.

  • Page 40: Trouble Shooting

    Trouble shooting Problem Solution Fabric does not feed well - Lengthen stitch length. - Increase presser foot pressure for heavyweight fabric. - Decrease presser foot pressure for lightweight fabric. - Check the differential feed. Needle breaks - Insert needle correctly. - Do not pull fabric while sewing.
  • Page 41 Sewing speed 1100 stitches/min Stitch length 1.0 - 4.0 mm Differential feed ratio 0.6 - 2.0 Overlock stitch width Left needle: 5 - 7 mm Right needle: 3 - 5 mm Coverstitch: 3 - 6 mm Presser foot rise 4.5 mm Needles INSPIRA™...

  • Page 43: Intellectual Property

    and the assortment of accessories without prior notice, or user and the product. Intellectual Property Please note that on disposal, this product must be safely recycled in accordance with relevant National legislation relating to electrical/electronic products. Do not dispose of electrical appliances as unsorted muncipal waste, use separate collection facilities.
  • Page 44 www.pfaff.com...
