A level floor with a maximum slope of 1" (25 mm) under
entire washer. Installing the washer on soft floor surfaces,
such as carpets or surfaces with foam backing, is not
recommended.
• A sturdy and solid floor to support the washer with a total
weight (water and load) of 400 Ibs (180 kg).
Do not operate your washer in temperatures below 32°F (0°C).
Some water can remain in the washer and can cause damage
in low temperatures.
Installation clearances
• The location must be large enough to allow the washer door
to be fully opened.
• Additional spacing should be considered for ease of
installation and servicing.
• Additional clearances might be required for wall, door, and
floor moldings.
• Additional spacing of 1" (25 mm) on all sides of the washer
is recommended to reduce noise transfer.
Companion appliance spacing should also be considered.
Washer Dimensions
8i"
(1295ram}
27"
(888 r am}
311/2"
(800rnrn)
Recommended installation spacing for custom
undercounter installation
Recommended installation spacing for recessed or
closet installation, with or without a pedestal
The dimensions shown are for the recommended spacing.
Recessed area or closet installation
34,,_ 48 in.2*:_
(3100 mm2)
(864ram)
24 in. 2 .
(1550rnrn2)
I1"N-311/2"÷1 4 "F_-
(28mm)(800mm)(102mm)
3"
(76ram)
-f
8,,
(70ram)
A B
A. Side view - closet or confined area
B. Closet door with vents
*Min. top and bottom air openings for closet door.
Recessed or closet installation - Washer on pedestal
1"---_--- 27"---_._-= 1"
(25ram) (686ram} (25ram)
A
IE
II" I_
311/2" _ I 4"1
(25mm)(800mm)(102mm)
B
A. Recessed area
B. Side view - closet or confined area
The dimensions shown are for the recommended spacing.
Custom undercounter installation - Washer only
39" rain.
(990 ram)
+
Recommended installation spacing for recessed or
closet installation, with stacked washer and dryer
The dimensions shown are for the recommended spacing.
48 in. 2 *
(3100mm 2)
7c-
3"* (76 mm)
O
24 in? * +
(1550 mm2)
1"* (25mm)
*Required spacing
