Sharp AY-XM09BE Operation Manual

Sharp AY-XM09BE Operation Manual

Multi split type room air conditioner
Hide thumbs
Table of Contents

Advertisement

Quick Links

INDOOR UNIT
OUTDOOR UNIT
AY-XM09BE AE-XM18BE
R
MULTI SPLIT TYPE
ROOM AIR CONDITIONER
OPERATION MANUAL
CONTENTS
• PRECAUTIONS ................................................. 2
• TIPS ON SAVING ENERGY .............................. 5
• PART NAMES .................................................... 6
• USING THE REMOTE CONTROL .................... 8
• BASIC OPERATION ........................................ 10
• ONE-HOUR OFF TIMER ................................. 13
• FULL POWER OPERATION ........................... 13
• TIMER OPERATION ........................................ 14
• SAVE OPERATION ......................................... 16
• AUXILIARY MODE .......................................... 16
• MAINTENANCE ............................................... 17
• BEFORE CALLING FOR SERVICE ................ 18
• OPTION KIT .................................................... 19
Thank you for purchasing a SHARP air con-
ditioner. Please read this manual carefully
before operating the product.
AY-XM09BE

Advertisement

Table of Contents
loading

Related Manuals for Sharp AY-XM09BE

Summary of Contents for Sharp AY-XM09BE

  • Page 1: Table Of Contents

    • MAINTENANCE ..........17 • BEFORE CALLING FOR SERVICE ....18 • OPTION KIT ............ 19 INDOOR UNIT OUTDOOR UNIT Thank you for purchasing a SHARP air con- AY-XM09BE AE-XM18BE ditioner. Please read this manual carefully before operating the product.

  • Page 2: Precautions

    PRECAUTIONS WARNINGS FOR USE Do not pull or deform the power supply cable. Pulling and misuse of the power supply cable can result in damage to the unit and cause electrical shock. Be careful not to expose your body directly to the outlet air for a long time. It may affect your physical conditions.
  • Page 3 CAUTIONS FOR USE Open a window or door periodically to ventilate the room, especially when using gas appliances. Insufficient ventilation may cause oxygen shortage. Do not operate the buttons with wet hand. It may cause electric shock. For safety, turn the circuit breaker off when not using the unit for an extended period of time.

  • Page 4: Additional Notes On Operation

    ADDITIONAL NOTES ON OPERATION OPERATING TEMPERATURE RANGE • The built-in protective INDOOR TEMP. OUTDOOR TEMP. device may prevent the 32˚C D.B. 43˚C D.B. unit from operating when upper limit 23˚C W.B. used out of this range. COOLING 21˚C D.B. 21˚C D.B. •...

  • Page 5: Tips On Saving Energy

    TIPS ON SAVING ENERGY Below are some simple ways to save energy when you use your air conditioner. SET THE CORRECT TEMPERATURE • Setting the thermostat 1°C higher than the desired temperature in the COOL mode and 2°C lower in the HEAT mode will save approximately 10 percent in power consumption. •...

  • Page 6: Part Names

    PART NAMES INDOOR UNIT 1 Inlet (Air) 2 Open Panel 3 Operation panel 4 Air Filters 5 Indicator Panel 6 Vertical Adjustment Louvre 7 Horizontal Adjustment Louvres 8 Outlet (Air) 9 Remote Control To open the panel, hold the bot- tom corners of the open panel and gently pull outwards.

  • Page 7: Remote Control

    REMOTE CONTROL 1 TRANSMITTER 2 DISPLAY (Liquid Crystal Display) 3 ON/OFF Button MODE TEMP. 4 THERMO. (Thermostat) Button 5 SAVE Button 6 MODE Button TIMER 7 TIMER ON Button (for setting the timer) TEMP. 8 ONE-HOUR OFF TIMER Button 9 TIMER OFF Button (for setting the timer) 0 FAN Button SAVE MODE q TIMER CANCEL Button...

  • Page 8: Using The Remote Control

    USING THE REMOTE CONTROL INSTALLING BATTERIES Use two size-AAA (R03) batteries. Remove the battery cover at the back of the remote control. Insert batteries in the compart- ment, making sure the ± and — polarities are correctly aligned. • Lines will be indicated on the display when batteries are properly installed.
  • Page 9 CAUTION • Do not allow the signal receiver window to receive strong direct sunlight, since it can adversely affect its operation. If the signal receiver window is exposed to direct sunlight, close a curtain to block the light. • Using a fluorescent lamp with a quick starter in the same room may interfere with transmission of the signal.

  • Page 10: Basic Operation

    BASIC OPERATION Press the MODE button to select the opera- tion mode. AUTO HEAT COOL Press the ON/OFF button to start operation. • The red OPERATION lamp on the unit will light MODE TEMP. Press the THERMO. button to set the de- TIMER sired temperature.
  • Page 11 NOTES This air conditioner is a multi-type, and two indoor units are connected to one outdoor unit. When the setting mode of one indoor unit differs from the other, the indoor unit operated later may not work. • When one indoor unit is operating in HEAT mode, the other unit can not operate in COOL or DRY mode.

  • Page 12: Adjusting The Air Flow Direction

    ADJUSTING THE AIR FLOW DIRECTION VERTICAL AIR FLOW DIRECTION The air flow direction is automatically preset in each mode as follows for optimum comfort: COOL and DRY mode Horizontal air flow HEAT mode Diagonal air flow HOW TO ADJUST THE AIR FLOW DIRECTION Press the SWING button on the Adjustment range remote control once.

  • Page 13: One-Hour Off Timer

    ONE-HOUR OFF TIMER When the ONE-HOUR OFF TIMER is set, the unit will stop operating after one hour. Press the ONE-HOUR OFF TIMER button. • The remote control displays "1 ". • The yellow TIMER lamp on the unit will light up. •...

  • Page 14: Timer Operation

    TIMER OPERATION TIMER OFF The unit will turn off automatically according to your setting. Timer duration can be set from minimum 0.5 hours (30 minutes) to maximum 12 hours. Up to 9.5 hours, you can set by 0.5 hours (30 minutes) increments and from 10 to 12 hours, by 1 hour increment.

  • Page 15: Timer On

    TIMER ON The unit will turn on automatically according to your setting. Timer duration can be set from minimum 0.5 hours (30 minutes) to maximum 12 hours. Up to 9.5 hours, you can set by 0.5 hours (30 minutes) increments and from 10 to 12 hours, by 1 hour increment.

  • Page 16: Save Operation

    SAVE OPERATION With the SAVE operation, the air conditioner will operate with reduced power by adjusting fan speed and/or temperature settings. Excess power consump- tion will be avoided. Press the SAVE button during operation. MODE TEMP. • The remote control displays “SAVE”. TIMER TO CANCEL TEMP.

  • Page 17: Maintenance

    MAINTENANCE Be sure to turn the air conditioner off and turn the circuit breaker CAUTION off before performing any maintenance. CLEANING THE FILTERS The air filters should be cleaned every two weeks. TURN OFF THE UNIT REMOVE THE FILTERS Lift the open panel. Push the air filters up slightly to unlock them.

  • Page 18: Before Calling For Service

    BEFORE CALLING FOR SERVICE The following conditions do not denote equipment malfunctions UNIT DOES NOT OPERATE WATER VAPOUR • The unit will not operate if it is turned on • In the COOL and DRY operation, water va- immediately after it is turned off. The unit pour can sometimes be seen at the air out- will not operate immediately after the let due to the difference between the room...

  • Page 19: Option Kit

    IF THE UNIT FAILS TO COOL OR HEAT THE ROOM EFFECTIVELY Check the filters. If dirty, Check the outdoor unit to Check the thermostat is make sure nothing is blocking proper setting. clean them. the air inlet or outlet. A large number of people in Make sure windows and Check whether any heat- the room can prevent the unit...
  • Page 20 SHARP CORPORATION OSAKA, JAPAN Printed in Thailand TINSEA286JBRZ 1CO 1...
