U35 Gas Insert
MODELS: U35-NG Natural Gas
Owners & Installation Manual
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
U35-LP Propane
FOR YOUR SAFETY
What to do if you smell gas:
Do not try to light any appliance
Do not touch any electrical switch:
do not use any phone in your build-
ing.
Immediately call your gas supplier
from a neighbour's phone. Follow
the gas supplier's instructions.
If you cannot reach your gas sup-
plier, call the fire department.
05/04/05
Advertisement
Table of Contents
Related Manuals for FPI U35-NG
Summary of Contents for FPI U35-NG
- Page 1 Tested by: Installer: Please complete the details on the back cover and leave this manual with the homeowner. Homeowner: Please keep these instructions for future reference. 908-172d FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4 05/04/05...
-
Page 2: Unit Dimensions
FPI GAS FIREPLACE INSERT TO THE NEW OWNER Congratulations! You are the owner of a state-of-the-art Gas Insert by FPI. The U35 Gas Insert has been designed to provide you with all the warmth and charm of a fireplace, at the flick of a switch. -
Page 3: Table Of Contents
Bay Louvers ............... 12 Double Screen Door ............12 Kensington Front ..............13 Full Screen Front ..............15 Wiring Diagram ..............17 Optional Remote Control ............ 17 Optional Wall Thermostat ........... 17 Final Check ............... 18 U35 FPI Direct Vent Gas Insert... -
Page 4: Safety Label
NOTE: FPI units are constantly being im- proved. Check the label on the unit and if there is a difference, the label on the unit is the correct one. -
Page 5: Installation Requirements
It is imperative that control compartments, The FPI Gas Fireplace must be installed in ac- burners and circulating air passage- cordance with these instructions. Carefully read INSTALLATION INTO A ways of the appliance be kept clean. -
Page 6: Installation Checklist
Do not cut the ground terminal off under any circum- The FPI Gas Insert is installed as listed below. stances. When connected with 120 volts, the appliance must be electrically grounded in 1) Check all clearances to combustibles, see accordance with local codes, current version page 7. -
Page 7: Clearances To Combustibles
Mantel can be installed anywhere in shaded area or higher using the above scale. Note: Ensure the paint that is used on the mantel and the facing is "heat resistant" or the paint may discolour. U35 FPI Direct Vent Gas Insert... -
Page 8: Gas Connection
Mill-pac may be used instead of High Wind Cap high temperature silicone and screws 923GK 3" Co-linear Adaptor with flashing may be used instead of gear clamps at connections of liner to inlet and vent collars. U35 FPI Direct Vent Gas Insert... -
Page 9: Gas Pressure Test
Note: Aeration Adjustment should only pressures equal to or less than 1/2 psig. 8) Main Gas Outlet be performed by an authorized FPI (3.45 kPa). Disconnect piping from valve at 9) Alternative TC Connection Point Installer at the time of installation pressures over 1/2 psig. -
Page 10: Log Installation
4) Place the trim on the assembled faceplate 8) The power cord should be run behind the panels, aligning the wire connections from faceplate panel. the switches with the notch on the left side panel. U35 FPI Direct Vent Gas Insert... -
Page 11: Standard Flush Door
Bottom Louver and secure using 3 screws. Diagram 5 Hinge Location 11) Push the FPI logo plate into the two holes in the bottom left corner of the faceplate. Bottom Louver U35 FPI Direct Vent Gas Insert... -
Page 12: Optional Bay Door
Secure with 1 screw into each Bottom Louver Mounting Bracket as per diagram below. Use the bottom hole in the bracket. Clip installed on right side. U35 FPI Direct Vent Gas Insert... -
Page 13: Kensington Front
The power cord should be run behind the faceplate panel. Screws Left Side Shown 3) Slide the Tabs on the Blanking Plate into the slots located on Front and secure using 2 screws. Blanking Plate Tabs Kensington Front Blanking Plate Screw Screw U35 FPI Direct Vent Gas Insert... -
Page 14: The Kensington Front
Note: If you find that the Left or Right Side Screen Door is lower then the other, use the spacer provided to help align the Doors. The spacer is to be placed over the bottom pin before installing the Screen Door. U35 FPI Direct Vent Gas Insert... -
Page 15: Full Screen Front
It is held in place by magnets. 2) Lift the unit up slightly and push down on the corners of the Bottom Trim Bracket and slide under unit. Screw Top Frame Push in Corners Bottom Trim Bracket U35 FPI Direct Vent Gas Insert... - Page 16 Hold the door at a 45 degree angle to avoid scratching the faceplate. Hinge 6) Place Bottom Frame near hinge. Flip hinge over Bottom Frame and secure with 3 screws each. Screen Door Hinge Location Bottom Frame 8) Close screen doors. U35 FPI Direct Vent Gas Insert...
-
Page 17: Wiring Diagram
(Millivolt) OPTIONAL REMOTE CONTROL OPTIONAL WALL THERMOSTAT Use the FPI Remote Control Kit approved for this CAUTION unit. Use of other systems may void your Do not connect the millivolt A wall thermostat may be installed if desired, warranty. -
Page 18: Final Check
"PILOT" to "OFF" unless it is densation and fog the glass. This partially depressed. condensation is normal and will disappear in a few minutes as the glass heats up. U35 FPI Direct Vent Gas Insert... -
Page 19: Copy Of Lighting Instruction Plate
Blower: from a neighbours phone. Follow E) This appliance needs fresh air for FPI gas appliances use high tech blowers to the gas supplier’s instructions. safe operation and must be installed push heated air farther into the room. It is not... -
Page 20: Maintenance
(not with wall paint). FPI out the joints, Continuous condensation has been under water. uses StoveBrite Paint - Metallic Black #6309. -
Page 21: Door Glass
5) Remove brick panels, if used. 3) Replace the glass. The glass must have 6) Straighten the adjustment wire under the Your FPI stove is supplied with high tempera- gasketing around it. firebox base. ture, 5 mm Neoceram ceramic glass that will... -
Page 22: Valve Removal
4) Remove the logs and brick panels if in- stalled. Lift Burner/Rear Log Support assembly up 5) Straighten the adjustment wire under the and away from the burner orifice. firebox base. Straighten adjustment wire. U35 FPI Direct Vent Gas Insert... -
Page 23: Valve Installation
18) Close the door and replace the louvers. there is a union by the valve, otherwise removal will be almost impossible. 19) Fire up the unit again and check for proper flame appearance and glow on logs. U35 FPI Direct Vent Gas Insert... -
Page 24: Parts List
47) * Adaptor Holding Brkt - Right 48) 320-518 Flue Adaptor Assembly 50) * Insulation Hold Down Bracket 51) * Louver Hold Down - Top 908-172 Manual * Not available as a replacement part. U35 FPI Direct Vent Gas Insert... - Page 25 82) 320-001 Burner Grate 84) 320-034 Log Tray Rear 600-964 Log Set 86) 902-202 Front Log - Right 87) 902-201 Front Log - Left 88) 902-026 Rear Log * Not available as a replacement part. U35 FPI Direct Vent Gas Insert...
-
Page 26: Flush Door And Bay Front Assembly
Flame Hi/Low 3" Extension Knob 320-936 Optional Bay Door Trim - Gold * Not available as a replacement part. 113) 320-960 Bay Front Screen 320-956 Gold Trim Bay Front 320-958 Steel Trim Bay Front U35 FPI Direct Vent Gas Insert... - Page 27 Screw #8 x 1/2" Black Self-tapping 191) Screw #8 x 1/2" Brass Plated Self-tapping 910-246 Burner ON/OFF Switch 199) 948-216 Regency Logo 910-330 Fan Speed Control 120 V * Not available as a replacement part. Faceplate Filler U35 FPI Direct Vent Gas Insert...
- Page 28 _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ ____________________________________________________________ __________________________________________________________ ____________________________________________________________ _______________________________________________________ _____________________________________________________ __________________________________________________________ _________________________________________________________ _________________________________________________________ ______________________________________________________ ______________________________________________________ _______________________________________________________________ ___________________________________________________________ __________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ _____________________________________________________________ __________________________________________________________ __________________________________________________________ _____________________________________________________ ________________________________________________________ _________________________________________________________ _________________________________________________________ U35 FPI Direct Vent Gas Insert...
- Page 29 _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ ____________________________________________________________ __________________________________________________________ ____________________________________________________________ _______________________________________________________ _____________________________________________________ __________________________________________________________ _________________________________________________________ _________________________________________________________ ______________________________________________________ ______________________________________________________ _______________________________________________________________ ___________________________________________________________ __________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ _____________________________________________________________ __________________________________________________________ __________________________________________________________ _____________________________________________________ ________________________________________________________ _________________________________________________________ _________________________________________________________ U35 FPI Direct Vent Gas Insert...
- Page 30 NOTES _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ ____________________________________________________________ __________________________________________________________ ____________________________________________________________...
-
Page 31: Warranty
This limited Lifetime Warranty does not extend to or include paint, door or glass gasketing or trim. At no time will FPI be liable for any consequential damages which exceed the purchase price of the unit. FPI has no obligation to enhance or modify any unit once manufactured. - Page 32 __________________________________________________________________ Installer: ___________________________________________________________ Phone #: ___________________________________________________________ Date Installed: ______________________________________________________ Serial No.: _________________________________________________________ Regency, Palace Designer Fireplaces and energy are trademarks of FPI Fireplace Products International Ltd. Printed in Canada © Copyright 2005, FPI Fireplace Products International Ltd. All rights reserved.
