Integrated Installation - Full Height Grille
To remove the top grille panel:
1. Open the door(s).
2. Slide your fingers under the bottom of the grille panel until
you can fully grasp the panel, then pull the panel straight out.
Place the grille panel on a soft surface.
To replace the top grille panel:
1. Align the bracket with the mounting posts.
2. Push the grille panel forward until the bracket snaps into
place.
Power On or Off Switch
1. Remove the top grille panel.
2. Press power switch to the On or Off position.
3. Replace the top grille panel.
IMPORTANT: Be sure the power switch is set to the On position
after cleaning refrigerator or changing light bulbs.
A. Power switch

Water Supply Requirements

Read all directions before you begin.
IMPORTANT:
When your refrigerator was installed, the water connection
from the water source should have been connected to your
refrigerator. If your refrigerator is not connected to a water
source, see "Connect to Water Line" in the Installation
Instructions. If you have any questions about your water
connection, see "Troubleshooting" or call a licensed, qualified
plumber.
If you turn the refrigerator on before the water line is
connected, turn the ice maker OFF. See "Ice Maker and
Storage Bin."
All installations must meet local plumbing code requirements.
Water Pressure
A cold water supply with water pressure between 30 and 120 psi
(207 and 827 kPa) is required to operate the water dispenser and
ice maker. If you have questions about your water pressure, see
"Troubleshooting" or call a licensed, qualified plumber.
Reverse Osmosis Water Supply
IMPORTANT: The pressure of the water supply coming out of a
reverse osmosis system going to the water inlet valve of the
refrigerator needs to be between 30 and 120 psi (207 and
827 kPa).
If a reverse osmosis water filtration system is connected to your
cold water supply, the water pressure to the reverse osmosis
system needs to be a minimum of 40 psi (276 kPa).
If the water pressure to the reverse osmosis system is less than
40 psi (276 kPa):
Check to see whether the sediment filter in the reverse
osmosis system is blocked. Replace the filter if necessary.
Allow the storage tank on the reverse osmosis system to refill
after heavy usage.
If your refrigerator has a water filter, it may further reduce the
water pressure when used in conjunction with a reverse
osmosis system. Remove the water filter. See "Water
A
Filtration System."
If you have questions about your water pressure, call a licensed,
qualified plumber.

Water System Preparation

Please read before using the water system.
Immediately after installation, follow the steps below to make
sure that the water system is properly cleaned.
1. Open the freezer door and turn off the ice maker. For Style 1,
lift up the wire shutoff arm as shown. For Style 2, move the
switch to the OFF (right) setting as shown. The On/Off switch
is located on the top right side of the freezer compartment.
Style 1 – Non-Dispenser Models
Style 2 – Dispenser Models
NOTE: If your model has a base grille water filter, make sure the
water filter is properly installed so that the Eject button is out. See
"Water Filtration System."
Do not use with water that is microbiologically unsafe or of
unknown quality without adequate disinfection before or
after the system.
5
