Installation
Instructions
If you have questions, call 800.GE.CARES or visit our website at: www.monogram.com
Sabbath Mode Product Kit
ZSAB1
For Use With Monogram
Built-In Refrigerators:
36" , 42" & 48"
Side-by-Side "R" Models
Manufactured On or After
February 2004
36" Bottom-Freezer "R" Models
Manufactured On or After
April 2004
NOTE: Kit is not designed for
Single-Door ZIF or ZIR models.
K
www.star-k.org

Advertisement

Table of Contents
loading

Related Manuals for Monogram ZSAB1

Summary of Contents for Monogram ZSAB1

  • Page 1 Installation Instructions If you have questions, call 800.GE.CARES or visit our website at: www.monogram.com Sabbath Mode Product Kit ZSAB1 For Use With Monogram Built-In Refrigerators: 36” , 42” & 48” Side-by-Side “R” Models Manufactured On or After February 2004 36” Bottom-Freezer “R” Models...

  • Page 2: Table Of Contents

    Skill Level – The Sabbath Mode Product Kit must • only be installed by a qualified GE Factory Service Technician or GE Customer Care Appliance Service Technician. Product failure due to installation by anyone else is not covered under the GE Appliance Warranty.

  • Page 3: About The Sabbath Mode

    Introduction ABOUT THE SABBATH MODE This feature was designed for use on the Jewish Sabbath and Holidays. The Sabbath Mode feature makes it possible for observant Jews to refrigerate and freeze food during the duration of the holiday. When set, the Sabbath Mode feature will override typical reactions to actions in your refrigerator.

  • Page 4: Using The Sabbath Switch

    Introduction USING THE SABBATH SWITCH • To activate the Sabbath Mode feature, raise the top grille panel and set the Sabbath Mode switch to the On/Off LED ON position. • When the refrigerator is in Sabbath mode, a green LED light will be visible.

  • Page 5: Installation Instructions

    Installation Instructions INSTALLING SABBATH MODE SWITCHBOX Side-by-Side Refrigerators MOUNT SWITCHBOX • FOR PERSONAL SAFETY: Unplug the refrigerator, remove house fuse or open circuit breaker before beginning installation. • Open the grille panel. Sabbath Switchbox • Place a sheet or towel over the top of the fresh food Mounting and freezer doors to prevent accidentally scratching Location...

  • Page 6: Making Electrical Connections

    Installation Instructions INSTALLING SABBATH MODE SWITCHBOX Side-by-Side Refrigerators (cont.) MAKING ELECTRICAL CONNECTIONS • Locate the Refrigerator’s AC Input and Output Refrigerator Connectors to the upper right of the evaporator AC Connectors housing. • Disconnect the refrigerator’s AC Input and Output connectors from each other.

  • Page 7: Operation Checklist

    Installation Instructions MAKING ELECTRICAL CONNECTIONS Refrigerator DC Connectors • Connect the switchbox DC Input Connector to the refrigerator’s DC Input connector. • Connect the switchbox DC Output Connector to the refrigerator’s DC Output connector. Kit DC Input Connector (2 holes) Kit DC Kit DC Output Connectors...

  • Page 8: Mount Switchbox

    Installation Instructions INSTALLING SABBATH MODE SWITCHBOX Bottom-Freezer Refrigerators MOUNT SWITCHBOX • FOR PERSONAL SAFETY: Unplug the refrigerator, remove house fuse or open circuit breaker before beginning installation. • Open the grille panel. • Place a sheet or towel over the top of the fresh food door to prevent accidentally scratching the door panel.
  • Page 9 Installation Instructions MAKING ELECTRICAL CONNECTIONS (cont.) • Connect the switchbox AC Input Connector to the Kit AC Connectors refrigerator’s AC Input connector. • Connect the switchbox AC Output Connector to the refrigerator’s AC Output connector. Kit AC Output Connector (3 prongs) Kit AC Input Refrigerator AC Connector...

  • Page 10: Operation Checklist

    Installation Instructions INSTALLING SABBATH MODE SWITCHBOX Bottom-Freezer Refrigerators (cont.) MAKING ELECTRICAL CONNECTIONS (cont.) • Route the wires for the AC Connectors over the water filter. Route the wires for the DC Connectors under the door trim. If necessary, use the wire ties included with Water filter the kit to dress the wires.

  • Page 11: Consumer Information

    Consumer Information FREQUENTLY ASKED QUESTIONS • How long can I run my refrigerator in Sabbath Mode? We recommend against running the refrigerator for longer than 4 days at a time in Sabbath mode, as the overall cooling capability of the refrigerator may be affected. •...

  • Page 12: Warranty

    Consumer Information WARRANTY Staple sales slip or canceled check here. Proof of original purchase date is needed to obtain service under warranty. WHAT IS COVERED From the Date of the Original Purchase • FULL TWO-YEAR WARRANTY For two years from date of original purchase, we will provide, free of charge, parts and service labor in your home to repair or replace any part of the Sabbath Mode Product Kit that fails because of a manufacturing defect.
