RETAIN THESE INSTRUCTIONS
FOR FUTURE REFERENCE
This appliance may be installed in an aftermar-
ket permanently located, manufactured home
(USA only) or mobile home, where not prohib-
ited by local codes. This appliance is only for
use with the type of gas indicated on the rating
plate. This appliance is not convertible for use
with other gases, unless a certified kit is used.
WARNING: IF THE INFORMATION IN THIS MANUAL
IS NOT FOLLOWED EXACTLY, A FIRE OR EXPLO-
SION MAY RESULT CAUSING PROPERTY DAM-
AGE, PERSONAL INJURY OR LOSS OF LIFE.
FOR YOUR SAFETY: Do not store or use gasoline
or other flammable vapors or liquids in the vicin-
ity of this or any other appliance.
FOR YOUR SAFETY: What to do if you smell gas:
• DO NOT light any appliance.
• DO NOT touch any electrical switches.
• DO NOT use any phone in your building.
• Immediately call your gas supplier from a
neighbor's phone.
Follow your gas suppliers instructions.
• If your gas supplier cannot be reached, call the
fire department.
Installation and service must be performed by a
qualified installer, service agency or the gas
supplier.
For GHC/GRD-5500
WH Report No. J20046562
For GHC/GRD-6500
WH Report No. J20046564
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
INSTALLATION
INSTRUCTIONS
B-VENT
GHC-5500/6500 AND
GRD-5500/6500 SERIES
B-VENTED GAS FIREPLACES
P/N 700,027M REV. E 07/2004
MODELS
M
l i
v i l
t l o
M
o
e d
s l
G
H
- C
5 5
0 0
N
G
H
- C
5 5
0 0
G
R
- D
5 5
0 0
G
R
- D
5 5
0 0
G
H
- C
5 6
0 0
N
G
H
- C
5 6
0 0
G
R
- D
5 6
0 0
G
R
- D
5 6
0 0
AVERTISSEMENT: ASSUREZ-VOUS DE BIEN SUIVRE
LES INSTRUCTIONS DONNÉ DANS CETTE NOTICE POUR
RÉDUIRE AU MINIMUM LE RISQUE D'INCENDIE OU
POUR ÉVITER TOUT DOMMAGE MATÉRIEL, TOUTE
BLESSURE OU LA MORT.
POUR VOTRE SÉCURITÉ: Ne pas entreposer ni utiliser
d'essence ni d'autre vaperurs ou liquides inflammables
dans le voisinage de cet appareil ou de tout autre
appareil.
POUR VOTRE SÉCURITÉ: Que faire si vous sentez une
odeur de gaz:
• Ne pas tenter d'allumer d'appareil.
• Ne touchez à aucun interrupteur. Ne pas vous servir
des téléphones se trouvant dans le batiment où
vous vous trouvez.
• Evacuez la piéce, le bâtiment ou la zone.
• Appeflez immédiatement votre fournisseur de gaz
depuis un voisin. Suivez les instructions du
fournisseur.
• Si vous ne pouvez rejoindre le fournisseur de gaz,
appelez le service dos incendies.
L'installation et service doit être exécuté par un qualifié
installer, agence de service ou le fournisseur de gaz.
E
e l
r t c
n o
c i
M
o
e d
s l
G
H
- C
5 5
0 0
N
E
2 -
P
G
H
- C
5 5
0 0
P
E
2 -
N
G
R
- D
5 5
0 0
N
E
2 -
P
G
R
- D
5 5
0 0
P
E
2 -
G
H
C
6 -
0 5
E 0
N
P
G
H
C
6 -
0 5
E 0
P
N
G
R
D
6 -
0 5
E 0
N
P
G
R
D
6 -
0 5
E 0
P
1
Advertisement
Table of Contents
Related Manuals for Superior GHC-5500 SERIES
Summary of Contents for Superior GHC-5500 SERIES
- Page 1 INSTALLATION INSTRUCTIONS B-VENT RETAIN THESE INSTRUCTIONS GHC-5500/6500 AND FOR FUTURE REFERENCE GRD-5500/6500 SERIES This appliance may be installed in an aftermar- ket permanently located, manufactured home B-VENTED GAS FIREPLACES P/N 700,027M REV. E 07/2004 (USA only) or mobile home, where not prohib- ited by local codes.
-
Page 2: Table Of Contents
TABLE OF CONTENTS The GHC-5500NE-2, PE-2 and GHC-6500EN, Provide adequate clearances around air open- ings and adequate accessibility clearance for EP models are circulating system appliances; service and proper operation. Never obstruct Packaging ........page 2 the GRD-5500NE-2, PE-2 and GRD-6500EN, the front openings of the appliance. -
Page 3: Location
Do not use these appliances if any part has been These appliances must not be connected to a AVERTISSEMENT: SURVEILLER LES under water. Immediately call a qualified, pro- chimney or flue serving a separate solid fuel ENFANTS. GARDER LES VÊTEMENTS, fessional service technician to inspect the ap- burning appliance. -
Page 4: Appliance Specifications - 5500
APPLIANCE SPECIFICATIONS GHC/GRD-5500 GHC-5500 GRD-5500 " " (108 mm) (108 mm) " (165 mm) 21" (533 mm) " (845 mm) " " (876 mm) (876 mm) 21" (533 mm) " (845 mm) " (38 mm) 7 " (178 mm) " (911 mm) "... -
Page 5: Appliance Specifications - 6500
APPLIANCE SPECIFICATIONS GHC/GRD-6500 GHC-6500 GRD-6500 " " (108 mm) (108 mm) " " (162 mm) (165 mm) " 21" (546 mm) (533 mm) 32" (813 mm) " " " 21" (921 mm) (921 mm) (413 mm) (533 mm) " (959 mm) 32"... -
Page 6: Venting
APPLIANCE CLEARANCES Venting Gas Vent Rule – Gas vent caps are not permitted within 8 feet (2.4 mm) of a vertical wall or similar obstruction. Gas vent caps that are located 8' or more from a portion of a building which extends . -
Page 7: Typical Installation Sequence
TYPICAL INSTALLATION SEQUENCE FRAMING SPECIFICATIONS CONTINUED The typical sequence of installation follows, however, each installation is unique resulting Note: If the Outside Combustion Air Kit is to be installed, it must in variations to those described. be installed before the appliance is framed and enclosed in the finishing walls. - Page 8 2. Measure the square footage of the floor IMPORTANT: HOLD GAS VALVE SECURELY See Figure 11 for 5500 series units and space to be occupied by the system, surrounds TO PREVENT MOVEMENT WHEN CONNECT- Figure 12 for 6500 series. Then install the and hearth extensions.
-
Page 9: Field Wiring
Control Compartment Access - GRD Units 3 - Install the provided “J” box plate on the “J” box 5500 Series units within the control compartment using the screw The lower control compartment access panel and washer provided with the plate. has been designed to cover the control com- 4 - Refer to Figure 17 and 18 and the installa- partment from view. - Page 10 B. Electronic Wiring Electronic Wiring (With Forced Air Kit Usage) – GHC/GRD-5500/6500 Note: These appliances may be equipped with Robertshaw Ignition Control Equipped GHC-5500 series models may use the optional either of two ignition control modules: 1. If any of the original wire as supplied must be replaced, FAB-1500 or FAB-1600 Forced Air Kit;...
-
Page 11: Connecting Gas Line
Step 7. Install Optional Outside Gas Flex Line Connector GHC/GRD-5500/6500 Combustion Air Kit (Honeywell Ignition Module Equipped) " NPT x " " Flare x " NPT Valve Flare Fitting Shut-Off Valve 1. If any of the original wire as supplied must be replaced, it must be replaced with Type AWM 105 C –... -
Page 12: Log And Rockwool Installation
Step 9. Optional Glass Doors/Enclosure Panel Note: Lighting instructions are also found on Actuator Availablity, Precautions and Instructions – the pull-out label attached near the gas valve in Lever the control compartment. Phillips Pan See the Homeowner's Care and Operating In- Head Screw #6-32 x "... -
Page 13: Electronic Appliance Checkout
2. Adjust the pilot screw to provide properly sized pilot flame (Figure 30 ) . Turn counter Manual Reset Limit Switch clockwise to enlarge pilot flame and clockwise to reduce the pilot flame. DO NOT attempt to adjust pilot flame more than one half turn. 3. -
Page 14: Adjustments
Step 12. Adjustments – The following para- FINISHING REQUIREMENTS WARNING: AIR SHUTTER ADJUSTMENT graphs address adjustment concerns and pro- Wall Details SHOULD ONLY BE PERFORMED BY A cedures. QUALIFIED PROFESSIONAL SERVICE Appliance Facing Flush with Finished Wall - TECHNICIAN. Flame Appearance and Sooting Complete finished interior wall. - Page 15 Mantels Combustible Combustible Framing Finished Wall Finished Wall Framing See Figure 34 for combustible mantel shelf Combustible Combustible Mantel projections from the wall and for the mantel's Mantel Spacer Spacer minimum vertical distance from the top of the firebox opening. Top of Noncombustible Noncombustible...
-
Page 16: Cold Climate Insulation
COLD CLIMATE INSULATION GAS CONVERSION KITS If you live in a cold climate, seal all cracks WARNING: THIS CONVERSION KIT SHALL BE INSTALLED around your appliance with noncombustible BY A QUALIFIED SERVICE AGENCY IN ACCORDANCE WITH material and wherever cold air could enter the THE MANUFACTURER'S INSTRUCTIONS AND ALL APPLI- room. - Page 17 Pilot Assembly (Millivolt Shown) v i l t l o v i l t l o Pilot Orifice c i l s t i Figure 41 Step 9. Attach conversion kit label to the v i l t l o rating plate on the appliance as shown in the Figure 42 .
- Page 18 NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
- Page 19 NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
- Page 20 The manufacturer reserves the right to make changes at any time, without notice, in design, materials, specifications, prices and also to discontinue colors, styles and products. Consult your local distributor for fireplace code information. Printed in U.S.A. © 2001 by Lennox Hearth Products P/N 700,027M REV.
