- Page 2 3 - 4 5 - 9...
- Page 4 Class D Topology IR2110S S/N 87dB at 15kW @ 1 ohm All "N" Channel MOSFET TO218 Transistors Unregulated Power Supply 140 Volt Rails +/- for INSANE Amounts of Power Capacitance Voltage 160V Monster Solid Copper Buss Bars to Pass >1000 Amps of Current Idle Current Draw 8 amps Maximum Current Draw >1400 amps Dual Monoblock Internally Bridged...
-
Page 5: Specifications
1 ohm B ridged 14.4 kW 16.4 kW 19 kW The XXX-15000D performs best with a 16 volt power source. Soundstream recommends using a minimum 14.4 power source. P ower at 14.4 V olts L oad T HD 1% T HD 5%... - Page 6 BRIDGED INPUT REMOTE BASS GAIN SUBSONIC BOOST BASS EQ POWER [GREEN] SPEAKER OUTPUT PROTECT SPEAKER OUTPUT [RED] MIN MAX 10Hz 50Hz 0dB 18dB 40Hz 120Hz 35Hz 250Hz +12V +12V +12V +12V POWER INPUT...
- Page 7 1.Input RCA jacks INPUT These inputs are for signal cables from the source. Always use high quality RCA cables. 2.Gain GAIN This control allows you to vary the amplifiers input sensitivity between 0.2[200millivolts]and 7.6volts. Clockwise rotation raises the threshold and lowers the sensitivity, requiring higher input signal voltage from the source.
- Page 8 4.Bass Boost & EQ Control 40Hz 120Hz The Bass EQ control is used to select the boost frequency. Any frequency from 40 to 120 Hz can be selected. The Bass Boost control will increase the frequency selected from the Bass EQ up to 18dB. 5.LPF Control 35Hz 250Hz This control is used to set desired low pass frequency[35 ~ 250Hz]...
- Page 9 7. LED indicatior POWER [ GREEN ] PROTECT [ RED ] POWER : This GREEN LED will illuminate when the amplifier is turned“ON”. If it fails to illuminate check the power connections to the amplifier and fuses. PROTECT : The amplifier protection circuitry will disable the amplifier if input overload, short circuit or extremely high temperature conditions are detected.
- Page 10 9.Power[Battery positive] +12V +12V Due to the power requirements of the amplifier this connection should be made directly to the positive [+] terminal of battery. For safety measure install an in-line fuse Holder [not included] as close to the battery positive [+] terminal as possible with an ampere rating not to exceed the maximum current specified on page 3 To remote wire from source unit.
- Page 11 BRIDGED INPUT REMOTE BASS GAIN SUBSONIC BOOST BASS EQ POWER [GREEN] PROTECT SPEAKER OUTPUT SPEAKER OUTPUT [RED] MIN MAX 10Hz 50Hz 0dB 18dB 40Hz 120Hz 35Hz 250Hz...
-
Page 12: Turning On The Amplifier
Turning on the Amplifier The amplifier automatically turns on within a few seconds after remote voltage is applied. If your system is set-up so that the source unit provides the remote voltage . Then it would turn on when your stereo is turn on.
