Summary of Contents for Soundstream Tarantula Amplifier Series
- Page 3 Model TX4.440 TX4.560 TX2.350 TX2.500 TX2.1500 TX1.1300D TX1.2000D TX1.2600D RMS power at 14.4V 0.5Ohm Load 2600W x 1 1Ohm Load 1300W x 1 2000W x 1 2000W x 1 2Ohm Load 110W x 4 140W x 4 175W x 2 250W x 2 750W x 2 900W x 1...
- Page 4 Symptom Possible Remedy Amplifier Check to make sure you have a good ground connection. will not Check that there is battery power on the (+)terminal . power up Check all fuses, replace if necessary . Make sure that the Protection LED is not illuminated. Protection Check for short circuits on speaker leads.
- Page 5 Fig 13. TX2.350/TX2.500/TX2.1500 wiring Fig 14. TX2.350/TX2.500/TX2.1500 wiring...
- Page 9 Fig 3. TX2. 350/TX2.500/TX2.1500 panel layout MODEL TX1.1300D TX1.2000D TX1.2600D TX2.350 TX2.500 TX2.1500 TX4.440 TX4.560 CABLE 2-4# 0-2# 4-6# 0-2# 4-6# FUSE 120A 200A 250A 150A...
