System board

Description
System board for use with HP Compaq 6715b computer models with WWAN capability (includes
WWAN module slot)
System board for use with HP Compaq 6715b computer models without WWAN capability (does not
include WWAN module slot)
System board for use with HP Compaq 6715s computer models
System board for use with HP Compaq 6710b computer models with WWAN capability (includes
WWAN module slot)
System board for use with HP Compaq 6710b computer models without WWAN capability (does not
include WWAN module slot)
System board for use with HP Compaq 6710s computer models
Before removing the system board, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the battery (see
5. Remove the following components:
a. Hard drive (see
b. Memory/WLAN module compartment cover (see
c. Optical drive (see
d. Keyboard (see
e. Switch cover (see
f. Fan (see
g. Heat sink (see
h. Display assembly (see
i. Top cover (see
88 Chapter 4 Removal and replacement procedures
Battery on page
Hard drive on page
Optical drive on page
Keyboard on page
Switch cover on page
Fan on page 71)
Heat sink on page
Display assembly on page
Top cover on page
48).
52)
Expansion memory module on page
62)
64)
70)
72)
76)
81)
Spare part number
443896-001
443898-001
443897-001
446905-001
446904-001
446906-001
56)
