INSTALLATION & OPERATION MANUAL
Thank you for purchasing this product from a fine line of heating equipment.
We wish you many years of safe heating pleasure.
Visit our web site at
frequently asked questions, parts & accessory orders and more.
NOTE: IF YOU HAVE A PROBLEM WITH THIS UNIT DO NOT RETURN IT TO
THE DEALER. CONTACT CUSTOMER SERVICE @ 1-800-245-6489.
READ THESE INSTRUCTIONS CAREFULLY BEFORE INSTALLING THIS MODEL.
CAUTION: This stove must be installed in accordance with the Manufactured
Home and Safety Standard (HUD), CFR 3280, Part 24 and must comply
with local building and fire codes. Failure to follow these instructions
could result in property damage, bodily injury or even death. Keep
children, furniture, fixtures and all combustibles away from any
heating appliance.
NOTE: THIS STOVE IS MOBILE HOME AND DOUBLE WIDE APPROVED (WITH
OUTSIDE AIR HOOK-UP). DO NOT INSTALL IN A SLEEPING ROOM. THE
STRUCTURAL INTEGRITY OF THE MOBILE HOME FLOOR, WALL AND
CEILING/ROOF MUST BE MAINTAINED.
England's Stove Works highly recommends the use of smoke detectors and Carbon
Monoxide detectors with any hearth product, including this unit. Follow all
manufacturer's instructions when using smoke or Carbon Monoxide detectors.
This product contains a catalytic combustor, which needs periodic inspection and
replacement for proper operation. It is against the law to operate this wood
heater in a manner inconsistent with the operating instructions in this manual, or
if the catalytic element is deactivated or removed.
Our catalytic stoves are designed to burn seasoned, dry wood.
18-MH, 50-SHW15 & 50-TRW15
TYPE FUEL
EPA CERTIFICATE NO.
EMISSION RATE
OVERALL TEST EFFICIENCY
www.englanderstoves.com
CAUTIONS AND WARNINGS:
COMPLIANCE STATUS
REV. 2/06
for helpful information,
WOOD
335
1.97 GRAMS/HR
80.6%
Advertisement
Table of Contents
Related Manuals for England's Stove Works 18-MH
Summary of Contents for England's Stove Works 18-MH
- Page 1 STRUCTURAL INTEGRITY OF THE MOBILE HOME FLOOR, WALL AND CEILING/ROOF MUST BE MAINTAINED. England’s Stove Works highly recommends the use of smoke detectors and Carbon Monoxide detectors with any hearth product, including this unit. Follow all manufacturer’s instructions when using smoke or Carbon Monoxide detectors.
- Page 2 Thank you for purchasing this fine product from England’s Stove Works! England's Stove Works was started, and is still owned by, a family that believes strongly in a "Do It Yourself" spirit – that’s one reason you found this product at your favorite “Do It Yourself” store.
-
Page 3: Safety Notice
The area of the chimney liner must also be equal to or greater than the area of the flue collar on the stove. If the area of the flue is greater than the area of the collar, it should never be more than three (3) times greater. - Page 4 This involves connecting a metal pipe (usually three inches (3”) in diameter - check your stove - and the pipe can be flex or rigid) from the air inlet pipe located on the bottom rear of the stove through your floor or wall.
- Page 5 *IMPROPER INSTALLATION: The manufacturer will not be held responsible for damage caused by the malfunction of a stove due to improper venting or installation. Call (800-245-6489) and/or consult a professional installer if you have any questions.
- Page 6 (8”) behind the unit, eight inches (8”) on each side of the unit and sixteen inches (16”) in the front of it. This stove requires a minimum 36” x 48” floor protector.
- Page 7 (3”) pipe (flex or rigid) from the air inlet pipe located on the rear of the stove through the floor or wall. The outside end of this pipe should be covered in some manner to keep it clear of foreign matter. If you are installing this stove in a regular dwelling this connection is not necessary, but is recommended in air-tight homes.
-
Page 8: Section Iv: Accessory Items
There are two (2) pieces of J-Channel Trim in this kit that snap onto the edges of the stove. They cover the top front edge, the two vertical front edges and the ash apron front edge. To remove the protective plastic film, start at one end of the piece and peel off the film. -
Page 9: Section V: Operating Instructions
Note: Pulling the slide damper out or towards you increases the amount of combustion air and allows a faster burn. Pushing the rod in or away from you slows down the amount of air and allows the stove to burn slower. - Page 10 This controls the amount of heat your stove produces, as well as the burn time. The more you open the draft by pulling out the handle, the more combustion air enters the firebox; this will cause the stove to burn hotter and faster.
-
Page 11: Section Vi: Care And Maintenance
This type cleaning can be done without removing the combustor from the stove. For 1” thick Clear Skies combustor: Follow the instructions provided by Clear Skies pertaining to the cleaning of their combustor. - Page 12 Your pipe should be cleaned at least once a year and inspected monthly. Most people will clean their pipe and stove at the end of the heating season as this will keep odors from entering the house during the summer months. The flue pipe should be replaced every three to five years, depending on the thickness of the pipe (thicker pipe will last longer).
- Page 13 Any existing air leaks will cause the air to draw at points where the least resistance is offered — such places are pipe joints, flue thimble, flue openings in the chimney, ash clean-out doors and cracks in the chimney.
- Page 14 REPLACEMENT PARTS FOR 18-MH, 50-SHW15 and 50-TRW15 AC-DGKC AC-FCGK AC-SB AC-G9 AC-SH AC-SH4 AC-SHM AC-6C3 AC-MCSP CA-1710 CA-20 IP-18PC NOTE: Accessory items and trim (found in Section IV of this manual) may also be ordered. NOTE: ALL PARTS CAN BE ORDERED FROM YOUR LOCAL DEALER, FROM OUR FACTORY, OR FROM OUR WEB SITE.
- Page 15 Have this information on hand if you phone the factory or your dealer regarding this product. Retain for your files: Model Number __________________________ Date of Purchase ________________________ Date of Manufacture _________________ Serial #_____________________ LIMITED 5 YEAR WARRANTY FROM THE DATE OF PURCHASE TO THE ORIGINAL OWNER The manufacturer extends the following warranties: Five Year Period:...
-
