Intelligent Assembly Solutions
Dual Servo Spin Welder
User's Manual
DUKANE Part No. 403–570-01
Dukane Intelligent Assembly Solutions • 2900 Dukane Drive • St. Charles, Illinois 60174 USA • TEL (630) 797-4900 • FAX (630) 797–4949
ISO 9001:2000
www.dukane.com/us
Dukane products are manufactured
in ISO registered facilities
