Lightolier ProSpec 37100 Specification

Page 1 of 2
1 15/16
[50 mm]"
7 1/2
[190 mm]"
8
3 31/32
[101 mm]"
7
9
Catalog No. Finish
37100WH White
37100BK Black
Features
1. Track Attachment Fitting: Molded polycarbonate, rotates into track.
2. Push Tab: Steel Pin. Locks and detaches unit.
3. Track Adaptor Housing: Die-cast aluminum.
4. Ballast Housing: Extruded aluminum housing with die-cast aluminum
end caps.
5. Ballast: Electronic HID.
6. Tension Pivot Mounts: Allows for 350° horizontal and 180° vertical
rotation with tensioned mounts for controlled aim.
7. Lamp Housing: Die-cast aluminum with cool-grip
temperature silicone rubber which allows aiming adjustments while fixture
is on. Integral color.
8. Lampholder GX10: Twist and lock base. 5kV pulse rated heat resistant
thermo plastic body socket with nickel-plated contacts.
9. Cowl: Painted steel; steel springs hold lamp front and accessories;
secured to housing with springs.
Accessories
Holder: Integral, holds one accessory
Diffusion/Special Filters: AF2 series
Color Filters: ADF2 series
Louver (Hex Cell): AL2HC
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2009 Philips Group • B0709
ProSpec
1
3
7 7/32
[184 mm]"
6
2 3/4
[70 mm]"
Mounting
ProSpec 120V/277V track systems only.
®
insulation band; a high
®
120V/277V Track Lighting
™
Mini HID, Step Spot, 20W MR16 CMH
2
2 13/16
4
[ 72 mm]"
5
7 7/8
[200 mm]"
Lamp
20W MR16 CMH (M156) GX10 base
Not included
Electrical
Electronic Ballast (Thermally Protected)
Input Voltage: 120V/277V
Power Factor: >0.99
Input Power: 24W
Max Input Current: 0.20A@120V/0.09A@277V
Finish
All painted finishes are baked powder or enamel.
Markings
U.L., c.U.L
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
37100
2 1/2
[64 mm]"
1 5/8
[41 mm]"
4 1/2
[114 mm]"
Total Harmonic Distortion: <10%
ANSI Code: M (C) 156
Do not use on dimming circuit
Type:
