Lightolier ProSpec 37254 Specification

Page 1 of 2
1
5
4 13/16 in
[123 mm]
3 25/32 in
[96 mm]
Catalog No. Finish
37254WH
Matte White
37254BK Matte Black
Features
1. Ballast & Reflector Housing: Aluminum with die-cast endcaps.
2. Ballast: 54w electronic.
3. Flood Reflector: Aluminum, with highly reflective and semispecular finish
for a smooth wash of light.
4. Louver: Aluminum, for glare control, with captive locking springs for easy
installation and removal.
5. Vertical Pivot: Die cast rotation housing with positive rotation stop
provides 0° (NADIR) –130° vertical rotation in both directions.
6. Sockets: 600v rated mini bi-pin sockets with 90° rotor lock to engage
contacts and retain with a positive detent.
7. Socket Bracket: Adjustable steel, mounting bracket slides out for easy
lamping.
8. Attachment Fitting: Molded polycarbonate; pin rotates fitting into track
to engage luminaire
9. Track Adapter Arm: Die-cast aluminum with integral polarity keyguard.
Electrical
Class P T5HO Universal Voltage Electronic Ballast
Input Voltage: 120V/277V
Power Factor: >97%
Input Power: 121W/118W
Max Input Current: 1.0A @ 120V/0.43A @ 277V
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2009 Philips Group • B0709
ProSpec
PowerWash
9
Mounting
ProSpec 120V/277V track systems only.
®
Not compatible with MonoPoint.
Sound Rated: A
Minimum Start Temp: 0°F
Do Not Use On Dimming Circuit
120V/277V Track Lighting
®
T5 4 Foot Track Mounted 54 Watt High Output Fluorescent
™
49 9/16 in
[1259 mm]
47 7/16 in
[1205 mm]
Lamp
2x 54W T5 High Output (Fluorescent)
Finish
All painted finishes are baked enamel.
Labels
UL, c.U.L.
Advent is a registered trademark of Lightolier.
®
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
37254
3
2
4
Type:
8
3 9/32 in
[83 mm]
6
7
