Lightolier ProSpec 37224 Specification

Page 1 of 2
15/16 in
[24 mm]
1 7/16 in
[37 mm]
8
5
4 7/8 in
[124 mm]
3 3/4 in
[96 mm]
Ordering Information
Catalog No. Finishes
37224WH Matte White
37224EBK Matte Black
Features
1. Ballast & Reflector Housing: Aluminum with die-cast endcaps.
2. Ballast: Electronic.
3. Flood Reflector: Aluminum, with highly reflective and
semispecular finish for a smooth wash of light.
4. Louver: Aluminum, for glare control, with captive locking springs for easy
installation and removal. White for 37224WH, Silver for 37224EBK
5. Vertical Pivot: Die cast rotation housing with positive rotation stop
provides 0° (NADIR) –130° vertical rotation in both directions.
6. Sockets: 600v rated mini bi pin sockets with 90° rotor lock to engage
contacts and retain with a positive detent.
7. Socket Bracket: Adjustable steel, mounting bracket slides out for easy
lamping.
8. Attachment Fitting: Molded polycarbonate; pin rotates fitting into track to
engage luminaire.
9. Track Adapter Arm: Die-cast aluminum.
Electrical
Class P T5HO Universal Electronic Ballast
Input Voltage: 120V/277V
Power Factor: >97%
Input Power: 55W/54W (2 lamps)
Max Input Current: 0.47A @ 120V/0.20A @ 277V
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2009 Philips Group • B0709
ProSpec
PowerWash
1
3 9/32 in
[83 mm]
9
Track Mountings
ProSpec 120V/277V track systems only.
®
Not compatible with MonoPoint.
Sound Rated: A
Minimum Start Temp: 0°F
Do Not Use on Dimming Circuit
120V/277V Track Lighting
®
T5 2 Foot Track Mounted 24 Watt High Output Fluorescent
™
23 3/4 in
[603 mm]
Lamp
2 x 24W T5 High Output (Fluorescent) - Not Included
Finish
All painted finishes are baked enamel.
Labels
UL, cUL
Advent is a registered trademark of Lightolier.
®
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
37224
1 5/8 in
[41 mm]
2
3
4
6
7
Type:
