Lightolier Lytecaster 384X Specification

Page 1 of 2
4-1/2"
(114mm)
Complete fixture consists of Reflector Trim & Frame-In Kit. Select each separately
Reflector Trim
384CHX Chrome and White Flange
384BSX Brass and White Flange
Features
1. Housing: 25ga. galvanized steel.
2. Residence Mounting Clip: Factory-installed; zinc plated spring steel ;free-
hand installation.
3. Flange: Die-cast aluminum .060" (1.5mm) thick.
4. Aperture Cone: 18ga. aluminum.
5. Adjustable Lampholder Support: 27ga. steel; Rotates 358° horizontally
and 0° to 45° vertically.
6. Mounting Clips (2): 24ga. Spring steel, zinc plated. Provides easy snap-in
/snap-out action.
7. Lamp Guard: 1 3/4" (45mm) dia. borosilicate glass.
Frame-In Kit
Note: For complete Frame-In Kit specifications,
see 300 frame specification sheets
Accessories
Square Face Plate
300SQBK Black
300SQWH White
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2011 Philips Group • J0711
Lytecaster
3 3/4" (95mm) Aperture Basic Adjustable Cone MR16 & ES/ESD16
3/16"
(4mm)
Frame-In Kit
Remodeler
Remodeler
Remodeler
Non-IC
Non-IC
Non-IC
IC
IC
Air Seal / IC
Air Seal / IC
Air Seal / IC
Recessed Downlight
®
2-7/8"
(73mm)
4-1/2"
(114mm)
300MRX/300MRSPX
3401MREX
300ESX
302MRX/302MRSPX
302MREX
302ESX
302MRIC9X/302MRIC9SPX
302ESICX
302MRAICX/302MRAICSPX
302MRAICEX
302ESAICX
Labels
CSA, UL (Suitable for damp locations.)
Alzak ® is a registered trademark of ALCOA.
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
384X
1" MAX.
(24mm)
Lamp
50W MR16
50W MR16
50W ES/ESD16
50W MR16
50W MR16
50W ES/ESD16
50W MR16
50W ES/ESD16
50W MR16
50W MR16
50W ES/ESD16
Type:
