Lightolier Lytecaster 385X Specification

Page 1 of 2
4 1/2"
Ceiling Cutout:
Complete Fixture consists of Reflector Trim & Frame-In Kit. Select each separately.
Reflector Trim
385BKX Black phenolic step baffle and white flange
385WHX White phenolic step baffle and white flange
Features
1. Housing: 25ga. galvanized steel.
2. Residence Mounting Clip: Factory-installed; zinc plated spring steel ;free-
hand installation.
3. Flange: Die-cast aluminum .060" (1.5mm) thick; white finish.
4. Step Baffle: Molded phenolic. Available in molded black or white.
5. Adjustable Lampholder Support: 27ga. steel ; Rotates 358° horizontally
and 0° to 45° vertically.
6. Mounting Clips (2): 24ga. Spring steel, zinc plated. Provides easy snap-in
/snap-out action.
7. Lamp Guard: 1 3/4" (45mm) dia. borosilicate glass.
Frame-In Kit
Note: For complete Frame-In Kit specifications, see 300 frame
specification sheets
Labels:
CSA , UL (Suitable for damp locations)
Accessories
Square Face Plate
300SQBK Black
300SQWH White
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2011 Philips Group • D0711
Lytecaster
3 3/4" (95mm) Aperture Adjustable Basic Baffle MR16 & ES/ESD16
3/16"
2 7/8"
4 1/2"
Recessed Downlight
®
1" MAX
Frame-In Kit
Remodeler 300MRX/300MRSPX
Remodeler 3401MREX
Remodeler 300ESX
Non-IC 302MRX/302MRSPX
Non-IC 302MREX
Non-IC 302ESX
IC 302MRIC9X/302MRIC9SPX
IC 302ESICX
Air Seal / IC 302MRAICX/302MRAICSPX
Air Seal / IC 302MRAICEX
Air Seal / IC 302ESAICX
Alzak is a registered trademark of ALCOA.
®
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
385X
Lamp
50W MR16
50W MR16
50W ES/ESD16
50W MR16
50W MR16
50W ES/ESD16
50W MR16
50W ES/ESD16
50W MR16
50W MR16
50W ES/ESD16
Type:
