Page 1 of 1
2 1/16"
(52mm)
Ordering Information
Catalog No.
Finishes
83CY70EWH
Matte White
83CY70EBK
Matte Black
83CY70EAL
Metallic Aluminum
Features
1. Housing: .10" thick extruded aluminum body with die cast end caps.
2. Canopy: 0.06" aluminum canopy.
3. Mounting Arm: 0.07" extruded aluminum housing.
4. Cross Bar: (not shown) .074" galvanized steel with positive rotation stop.
Provides 350° rotation and positive lock every 45°. Mounting to J-Box
provides simple hands-free wiring.
5. On/Off Switch: Rocker switch to disconnect power to the ballast.
6. Power Receptacle: 5kv rated, insulated. Accepts power connector from
fixture.
7. Integral Track Groove: To mount PowerArc™ modular spots and wall wash
fixtures.
Electrical
Magnetic Ballast
Input Voltage:
Power Factor:
Input Power:
Max Input Current:
Total Harmonic Distortion:
ANSI Code:
Do not use on a dimming circuit.
Lightolier is a Philips group brand
ø 4 5/8"
(117mm)
5
3 7/8"
(98mm)
4 7/32"
(107mm)
Track Mountings
Intended for ceiling mounting and-
surface wall mounting 5' or greater
from floor. No remote mounting.
120 to 277V, 60Hz
High
79W
0.67A
<15%
M143 or M98
Lytespan
Accent Lighting System
®
PowerArc
Modular 70W Electronic Metal Halide Canopy Ballast
™
6
3/4"
(19mm)
3 7/8"
(98mm)
1
Luminaires
Use one of:
8313
8317
83W4
8314
8318
83W6
8316
83W7
Finish
All painted finishes baked enamel.
Labels
cUL, UL
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2008 Philips Group • D1108
83CY70E
7
2
3
7 1/8"
(181mm)
Lamp
70W Ceramic Metal Halide
Type:
