Page 1 of 1
3.25"
(82.5mm)
Outside Diameter
2.00"
(51mm)
Mounting Centers
4
Ordering Information
Catalog No.
Finish
83MPTWH
Matte White
83MPTBK
Matte Black
Features
1. Body: Die-formed steel.
2. Mounting Holes: Countersunk mounting holes to match centerline of stan-
dard unistrut holes.
3. Perimeter Slots: Allows use of a wide variety of mounting hardware.
4. Luminaire Mounting Slot: Integral slot accepts PowerArc
naires.
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2010 Philips Group • D0410
Lytespan
2
3.00"
(76mm)
Mounting Centers
3
Mounting
Mounts to any flat surface or
unistrut.
Modular lumi-
™
Track Lighting System
®
PowerArc
0.22"
(5.6mm)
1
Compatibility
PowerArc
™
Modular Track Luminaires:
8313WH, BK, AL
8314WH, BK, AL
8316WH, BK, AL
83W4WH, BK, AL
83W6WH, BK, AL
83W7WH, BK, AL
Finish
All painted finishes are baked enamel.
Labels
UL, cUL
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
83MPT
Modular Mounting Bracket
™
Type:
