Page 1 of 1
4
2
6
4 5/8"
(117mm)
8
Ordering Information
Catalog No. Finishes
8314WH
Matte White
8314BK
Matte Black
8314AL
Metallic Aluminum
Features
1. Housing: Die cast aluminum body.
2. Vertical Pivot: 0-90° vertical adjustment.
3. Horizontal Pivot: Die cast track adapter with infinite rotation.
4. Track Attachment Fitting: Molded polycarbonate, rotates into track.
5. Power Connector: 5kv rated with insulated pins. Connects to ballast
module. Keyed for polarity.
6. Safety Lens: Tempered 1/8" glass. Meets or exceeds U.L. safety
requirement for metal halide lamps.
7. Reflector: (not shown) Interchangeable reflectors available to allow for
desired precise beam spread without the need of additional lenses.
8. Shade: Die cast aluminum. Accepts Accessory Holder.
Reflectors sold separately. See MHT4R S/NF/F specification sheets.
Accessories
83T4AH
Accessory Holder. Accepts 2 Accessories Max.
83T4S
Snoot Accessory Holder. Accepts 2 Accessories Max.
ADF3 (3 3/4" dia.)
Color Filters
AF3 (3 3/4" dia.)
Diffusion Filters
AL3HC
Hex Cell Louver (For use with 39W Max.)
83EW18WH, BK, AL 18" Extension Wand
83EW48WH, BK, AL 48" Extension Wand
83EC72WH, BK
6' Extension Cord
83PCWH, BK
Pipe Clamp
83MPTWH, BK
Mounting Bracket
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2010 Philips Group • E0210
Lytespan
PowerArc
™
3
2 5/8"
(67mm)
2 1/4"
(57mm)
1
4 5/8"
(117.5mm)
Track Mountings
All Lytespan
Track systems and
®
Multipoint. All PowerArc
Modular
™
canopies, extension wands, mount-
ing brackets or pipe clamps. Not
compatible with ProSpec
®
or ATOM
®
.
See ballast for details.
}
Compatible with
83B39LE, 83B70E
Track Lighting System
®
Modular Metal Halide 20W, 39W, 70W T4 Enclosed Spot
1 13/16"
(46mm)
Ballast Module
Lamp
Use one of:
T4 or T4.5 Single-Ended,
83B20E
G8.5 Base, Clear Ceramic
83B39E
Metal Halide 70W Max.
83B70SE
83CY39E 83CY70E
83B39LE 83B70E
Finish
All painted finishes are baked enamel.
Electrical
See ballast module spec sheet.
Labels
UL, cUL
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
8314
5
4 7/16"
(113mm)
ø 1 1/2"
(38mm)
Reflectors
MHT4RS
MHT4RNF
MHT4RF
Type:
