INSTALLATION INSTRUCTIONS FOR LYTECEL (Both LI and LC)
ACCESS PLATE
1
Remove Access Plate by sliding Access Plate
in the direction of Arrow 1. To remove, lift up
and slide in the direction of Arrow 2. Bend
Fixture Tab up out of body and make ground
and ballast connections. Bend Fixture Tab
back to original position. Replace Access
Plate by reversing removal instructions.
INSTALL FIXTURES onto T-bars as shown.
2
CONTINUOUS ROW COUPLER (LC UNITS
3
ONLY) Remove screw as shown. Rotate
Continuous Row Coupler (both sides of
Continuous
Row Coupler
Screw
Hold-
down Clip
T-bar
HOLD-DOWN CLIPS (LI UNITS ONLY)
4
Install Hold-down Clips at beginning and end
of rows.
Hold-
down Clip
© Lightolier 2003
Lightolier
45 INDUSTRIAL WAY, WILMINGTON, MA 01887
Access
Plate
Opening
Fixtures
Fixtures
Screw
59-31123-000
Access
1.
Plate
2.
Access
Tab
Plate
Opening
T-bar
Fixtures) and secure Fixtures together with
Screw. Tighten all Screws to secure Fixtures
to T-bar with Hold-down Clips.
Hold-
down Clip
Screw
T-bar
To open Louver,
5
press Spring Latch
Fixtures
in direction of
Arrow. To close,
insert louver into
Fixture until
Spring Latches
automatically
engage.
Ground
Screw
Access
Plate
Fixture
Opening
Tab
Fixture
Fixtures
Continuous
Row Coupler
Spring
Latch
Printed in U.S.A.
