TABLE OF CONTENTS DANGER For Your Safety ........2-3 If you smell gas: Use and Care .
Page 3
WARNING CAUTION CALIFORNIA PROPOSITION 65 Using pots larger than 6 quarts in capacity could exceed weight limit of the 1. Combustion by-products produced when using this product contain chemicals known to the State of side burner shelf California to cause cancer, birth defects, and other or side shelf, reproductive harm.
LP Cylinder USE AND CARE •The LP cylinder used with your grill must meet the following requirements: DANGER •Use LP cylinders only with these required measurements: 12" (30.5cm) (diameter) x 18" (45.7 cm) (tall) with 20 lb. (9 kg.) capacity maximum. •...
LP Cylinder Exchange Connecting Regulator to the LP Cylinder •Many retailers that sell grills offer you the option of replacing 1.LP cylinder must be properly secured onto grill. (Refer to your empty LP cylinder through an exchange service. Use only assembly section.) those reputable exchange companies that inspect, precision fill, 2.Turn all control knobs to the OFF position.
Page 6
Leak Testing Valves, Hose and Regulator 1.Turn all grill control knobs to OFF. 2.Be sure regulator is tightly connected to LP cylinder. 3.Completely open LP cylinder valve by turning hand wheel counterclockwise. If you hear a rushing sound, turn gas off immediately.
Page 7
Safety Tips WARNING Before opening LP cylinder valve, check the coupling nut for tightness. When grill is not in use, turn off all control knobs and LP cylinder valve. For Safe Use of Your Grill and to Avoid Serious Never move grill while in operation or still hot. Injury: Use long-handled barbecue utensils and oven mitts to avoid •...
Page 8
Burner Flame Check Ignitor Lighting (continued) • Remove cooking grates and flame tamers. Light burners, rotate 8. For grills equipped with ELECTRONIC IGNITION at each burner: knobs from HI to LOW. You should see a smaller flame in Repeat steps 4 through 6 to light each burner. LOW position than seen on HI.
3. Remove carryover tubes and burners. CAUTION Detach electrode from burner. NOTE: Removal/Detachment method will depend on the SPIDER ALERT! burner configuration. See different configurations in illustrations below. 5. Carefully lift each burner up and away from valve openings. We suggest three ways to clean the burner tubes. Use the one SPIDER AND WEBS easiest for you.
LIMITED WARRANTY This warranty only applies to units purchased from an authorized retailer. Manufacturer warrants to the original consumer-purchaser only that this product shall be free from defects in workmanship and materials after correct assembly and under normal and reasonable home use for the periods indicated below beginning on the date of purchase*.
PARTS LIST Key Qty Description Key Qty Description BOTTOM SHELF LOGO PLATE CASTER, LOCKING HARDWARE F/ TOP LID CASTER, FIXED DOOR LEFT, NO HANDLES CART LEFT SIDE PANEL HANDLE F/ DOOR, SB LID GROMMET DOOR RIGHT, NO HANDLES CART RIGHT SIDE PANEL GRATE, F/ SB LOWER BACK PANEL GRIDDLE, F/ SB...
ASSEMBLY Place bottom shelf upside down. Insert Bent U Pin into the caster mounting plate to lock it in place, shown A. Spin the caster clockwise into the threads on the bottom shelf until secure. Remove the Bent U Pin and repeat for remaining casters.
Page 14
Place lower back panel between side panels at rear of bottom shelf. Make sure the slots are positioned as shown A. Secure lower back panel to side panels using two 1/4-20x1/2” screws, 7mm lock washers, and 7mm flat washers on each side. 1/4-20x1/2”...
Page 15
On back of grill, place upper back panel between side panels and above lower back panel. Secure upper back panel, in lower holes, using one 1/4-20x1½” screw, 7mm lock washer, and 7mm flat washer on each side. Do not fully tighten screws until side shelf installation is complete in later steps. Upper back panel 7mm flat 1/4-20x1½”...
Page 16
Insert tabs on left sideburner shelf assembly into rectangular slots in side of firebox, shown A. Attach rear of shelf using one 1/4-20x3/4” screw, 7mm flat washer,7mm lock washer and 1/4”nut in upper hole; and using 1/4-20x1½” screw, 7mm lock washer, 7mm flat washer in lower hole, shown B/C. Attach front of shelf and fascia using two 1/4-20x3/4”...
Page 17
Insert front brace under control panel and between cart side panels. Make sure door hinge pins are on the top side and facing the front. Secure using two 1/4-20x1½” screws, 7mm lock washers, and 7mm flat washers on each side. NOTE: MAKE SURE THAT THE FRONT BRACE IS MOUNTED IN THE MOST DOWNWARD POSITION WHEN ASSEMBLED TO CART.
Page 18
Insert sideburner burner into left shelf. The stud on bottom of burner fits into rear small hole in sideburner drip pan on shelf, shown A. Secure burner to sideburner drip pan with one Wing nut, shown B. Under sideburner shelf, attach Make sure burner tube engages sideburner valve, shown C.
Page 19
Place sideburner grate onto sidebruner shelf. Then place sideburner griddle onto sidebruner shelf, aligning griddle legs with holes in shelf. Sideburner griddle Sideburner grate Inside of cart, insert rear heat shield tabs(without holes) into three slots between upper and lower back panels, shown A. Attach shield tabs under front brace with three #8x3/8”...
Page 20
Inside of cart, insert end of tank wire (without hole) into back of lower back panel. Attach other end to bottom of front brace with a #8x3/8” self-tapping screw. Front brace #8x3/8” self-tapping screw Tank wire end of tank wire Inside of cart, insert tank exclusion wire ends into lower back panel.
Page 21
Release the cap and nut from electronic ignition module. Attach electronic ignition module to the cart right side panel with the nut, shown A. – ) end first. Then put on the cap, shown B. Insert AA battery into ignition module, negative ( Connect each of the wires from the main burner electrodes, and sideburner electrode into the back of the electronic ignition module.
Page 22
Install flame tamers by sliding one end of each flame tamer into slots at front of firebox and resting opposite end on pins in back of firebox. Flame tamer Slide into slots Place cooking grates onto the firebox as shown. Insert the three wire ends at rear of warming rack into holes in back of firebox.
Page 23
On back of grill, slide grease tray into opening in upper back panel. CAUTION Failure to install grease tray will cause hot grease to drip from bottom of grill with risk of fire or property damage. Grease tray LP CYLINDER IS SOLD SEPARATELY. Fill and leak check the cylinder before attaching to grill and regulator (see Use & Care section).
DANGER: If a gas leak cannot be stopped, or a fire occurs due to gas leakage, call the fire department. Emergencies Possible Cause Prevention/Solution Gas leaking from • Damaged hose. • Turn off gas at LP cylinder or at source on natural gas systems. If cracked/cut/burned anything but burned, replace valve/hose/regulator.
Page 25
Troubleshooting (continued) Problem Possible Cause Prevention/Solution Burner(s) will not light ELECTRONIC IGNITION: using ignitor. • No spark, no ignition noise. • See Section I of Electronic Ignition System. (See Electronic Ignition Troubleshooting also) • No spark, some ignition noise. • See Section II of Electronic Ignition System. •...
Page 26
Troubleshooting - Electronic Ignition Problem (Ignition) Possible Cause Check Procedure Prevention/Solution SECTION I No sparks appear at • Battery not installed • Check battery orientation. • Install battery (make sure that “+” and “–” any electrodes when properly. connectors are oriented correctly, with “+” end up Electronic Ignition Button and “–”...
